246723-YTG-J-1006
Unitary Products Group 17
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. CZB06011
INDOOR COIL MODEL NO. G1FA060S24
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM
1600 1800 2000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 51.8 52.8 50.6 57.9 61.8 52.8 54.2 52.5 58.6 63.1 53.8 55.6 54.3 59.3 64.4
S.C. 39.4 48.8 44.1 39.1 30.3 42.1 52.3 44. 41.1 31.7 44.7 55.9 48.5 43.2 33.1
K.W. 4.6 4.6 4.5 4.7 4.8 4.6 4.6 4.6 4.7 4.8 4.6 4.7 4.6 4.8 4.8
75
T.C. 55.1 56.9 53.6 61.5 65.7 56.1 58.3 55.4 62.6 66.5 57.0 59.7 57.3 63.7 67.2
S.C. 41.1 50.2 44.4 40.8 31.3 43.4 53.1 46.0 43.1 32.6 45.6 56.0 49.3 45.5 33.9
K.W. 4.0 4.0 3.9 4.0 4.1 4.0 4.0 3.9 4.0 4.1 4.0 4.0 3.9 4.0 4.1
85
T.C. 53.5 54.8 52.1 59.7 63.8 54.5 56.2 54.0 60.6 64.8 55.4 57.7 55.8 61.5 65.8
S.C. 40.3 49.5 44.0 39.9 30.8 42.7 52.7 45.9 42.1 32.2 45.2 55.9 48.7 44.3 33.5
K.W. 4.3 4.3 4.2 4.4 4.4 4.3 4.3 4.3 4.4 4.5 4.3 4.3 4.3 4.4 4.5
95
T.C. 49.9 51.3 49.3 56.1 59.7 50.8 52.6 51.0 57.0 60.6 51.6 53.9 52.7 57.9 61.5
S.C. 38.6 47.0 43.1 38.5 29.3 40.8 49.9 44.1 40.8 30.6 43.1 52.8 48.4 43.1 31.9
K.W. 5.0 5.0 4.9 5.1 5.2 5.0 5.0 5.0 5.1 5.2 5.0 5.0 5.0 5.1 5.2
105
T.C. 46.4 47.7 46.5 52.4 55.6 47.1 48.9 48.1 53.4 56.4 47.8 50.1 49.6 54.4 57.2
S.C. 36.9 44.6 40.7 37.2 27.8 39.0 47.1 41.7 39.5 29.1 41.0 49.7 43.6 41.8 30.4
K.W. 5.7 5.7 5.7 5.8 5.9 5.7 5.7 5.7 5.8 5.9 5.7 5.7 5.7 5.8 5.9
115
T.C. 42.9 44.3 43.8 48.9 51.7 43.5 45.3 45.2 49.9 52.3 44.2 46.4 46.6 50.9 52.9
S.C. 35.2 42.2 37.9 35.8 26.4 37.1 44.4 39.0 38.2 27.6 39.0 46.6 40.2 40.5 28.8
K.W. 6.4 6.4 6.3 6.5 6.6 6.4 6.4 6.4 6.5 6.6 6.4 6.4 6.4 6.5 6.6
125
T.C. 39.5 40.8 41.1 45.4 47.7 40.0 41.8 42.3 46.4 48.2 40.5 42.7 43.5 47.5 48.7
S.C. 33.6 39.9 36.0 34.5 25.0 35.3 41.7 35.4 36.9 26.1 37.0 43.6 36.6 39.3 27.3
K.W. 7.1 7.1 7.0 7.1 7.3 7.1 7.1 7.1 7.2 7.3 7.1 7.1 7.1 7.2 7.3
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
MA20D FC/MC60D 1.00 1.00 1.00
MA20D G*FD060H24 1.00 1.00 1.00
MA20D G*FD061H24 1.00 1.00 1.00
MA20D MC61 1.00 1.00 1.00
MV20D MC60D 1.00 1.00 1.00
MV20D MC61D 1.03 1.03 1.00
AHP/SHP60 – 1.00 1.00 1.00
AV/SV60 – 1.02 1.02 0.98
F*FV060 – 1.02 1.02 1.00
– FC/MC/PC/UC60 1.00 1.00 1.00
– G*FD060H24 1.00 1.00 1.00
– G*FD061H24 1.00 1.00 1.00
– HC60 1.00 1.00 1.00
– HD60 1.00 1.00 1.00
– MC61 1.00 1.00 1.00
Variable Speed
Furnace
Coil
T.C. S.C. KW
PV9*D20 FC/MC/PC60D 0.99 0.98 1.00
PV8*C20 FC/PC60C 1.00 1.00 1.00
PV9*C20 FC/PC60C 0.99 0.98 1.00
PV8*C20 HC60 0.99 0.98 1.00
PV9*D20 HC60 0.99 0.98 1.00
PV8*C20 HD60 0.99 0.98 1.00
PV9*D20 HD60 0.99 0.98 1.00
PV8*C20 MC60D 1.00 1.00 1.00
PV9*C20 MC60D 0.99 0.98 1.00
PV8*C20 MC61D 1.01 1.01 1.00
PV9*C20 MC61D 1.01 1.01 1.00
PV9*D20 MC61D 1.01 1.01 1.00
