66297-YIM-C-0205
INDOOR DB
TEMPERATURE,
°F
HEATING SUPERHEAT AT COMPRESSOR SUCTION, °F
-100 102030405060
55 4.4 4.4 4.6 4.9 5.6 7.1 10.2 16.6
70 ——————5.912.3
80 ———————9.3
TABLE 9 - HEATING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 800 CFM (B1HH024)
TABLE 8 - COOLING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 800 CFM (B1HH024)
OUTDOOR
TEMPERATURE,
°F
INDOOR WB TEMPERATURE, °F
55 57 59 61 63 65 67 69 71 73 75
65 18.8 20.7 22.6 24.5 26.4 28.3 30.2 30.6 31.0 31.4 31.8
70 15.7 17.5 19.3 21.1 22.9 24.7 26.5 27.5 28.6 29.7 30.8
75 12.5 14.2 15.9 17.6 19.3 21.0 22.7 24.5 26.2 28.0 29.7
80 9.4 11.0 12.6 14.2 15.8 17.4 19.0 21.4 23.8 26.3 28.7
85 6.2 7.7 9.2 10.7 12.2 13.7 15.2 18.3 21.4 24.6 27.7
90 — — 5.9 7.2 8.7 10.1 11.5 15.3 19.1 22.9 26.7
95 ————5.16.47.712.2 16.7 21.1 25.6
100 —————5.36.210.0 13.9 17.7 21.5
105 ———————7.911.114.2 17.4
110 ———————5.88.310.8 13.3
115 ————————5.57.39.2
INDOOR DB
TEMPERATURE,
°F
OUTDOOR TEMPERATURE, °F
-100 102030405060
55 3.1 3.5 4.0 4.7 5.8 7.3 9.4 12.4
70 ————3.55.07.110.1
80 —————3.65.78.7
TABLE 6 - COOLING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 600 CFM (B1HH018)
OUTDOOR
TEMPERATURE,
°F
INDOOR WB TEMPERATURE, °F
55 57 59 61 63 65 67 69 71 73 75
65 5.5 5.8 6.1 6.4 6.7 7.0 7.3 13.0 18.7 24.5 30.2
70 — 5.1 5.5 5.9 6.3 6.7 7.1 12.4 17.8 23.1 28.5
75 — — — 5.4 5.8 6.3 6.8 11.8 16.8 21.8 26.8
80 ————5.46.06.611.215.8 20.5 25.1
85 —————5.66.310.6 14.9 19.1 23.4
90 —————5.36.110.0 13.9 17.8 21.7
95 ——————5.89.412.9 16.5 20.0
100 ———————7.911.014.1 17.2
105 ———————6.59.111.814.4
110 ———————5.07.29.411.6
115 ————————5.37.18.8
TABLE 7 - HEATING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 600 CFM (B1HH018)
