TABLE 16 - COOLING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 1,600 CFM (B1HH048)
TABLE 15 - HEATING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 1,400 CFM (B1HH042)
INDOOR DB
TEMPERATURE,
°F
HEATING SUPERHEAT AT COMPRESSOR SUCTION, °F
-100 102030405060
55 — — — 4.0 6.2 9.0 12.5 16.6
70 ————4.47.210.7 14.8
80 ——————3.37.4
OUTDOOR
TEMPERATURE,
°F
INDOOR WB TEMPERATURE, °F
55 57 59 61 63 65 67 69 71 73 75
65 19.6 22.0 24.4 26.8 29.2 31.6 34.0 34.8 35.6 36.4 37.2
70 19.1 21.5 23.9 26.2 28.6 31.0 33.3 34.2 35.0 35.9 36.7
75 18.7 21.0 23.4 25.7 28.0 30.3 32.7 33.6 34.5 35.4 36.2
80 18.2 20.5 22.8 25.1 27.4 29.7 32.0 32.9 33.9 34.8 35.8
85 17.8 20.0 22.3 24.6 26.8 29.1 31.3 32.3 33.3 34.3 35.3
90 15.5 17.5 19.5 21.5 23.5 25.5 27.5 29.3 31.0 32.8 34.6
95 13.2 14.9 16.7 18.4 20.2 21.9 23.7 26.2 28.8 31.3 33.9
100 10.2 11.7 13.3 14.8 16.4 17.9 19.5 22.4 25.3 28.2 31.2
105 7.2 8.5 9.9 11.2 12.6 13.9 15.3 18.6 21.9 25.1 28.4
110 — 5.3 6.5 7.6 8.8 9.9 11.1 14.7 18.4 22.1 25.7
115 —————5.96.910.9 14.9 19.0 23.0
OUTDOOR
TEMPERATURE,
°F
INDOOR WB TEMPERATURE, °F
55 57 59 61 63 65 67 69 71 73 75
65 18.5 20.8 23.1 25.4 27.7 30.3 32.3 33.0 33.8 34.6 35.3
70 15.2 17.4 19.6 21.7 23.9 26.1 28.3 29.9 31.6 33.2 34.8
75 11.8 13.9 16.0 18.1 20.2 22.3 24.3 26.8 29.3 31.8 34.3
80 8.5 10.4 12.4 14.4 16.4 18.4 20.4 23.7 27.1 30.4 33.8
85 5.1 7.0 8.9 10.88 12.6 14.5 16.4 20.6 24.8 29.0 33.2
90 5.6 6.6 7.6 8.6 9.7 10.7 11.7 16.4 21.1 25.8 30.5
95 6.1 6.3 6.4 6.5 6.7 6.8 7.0 12.2 17.3 22.5 27.7
100 5.9 6.0 6.1 6.2 6.3 6.4 6.4 10.7 14.9 19.1 23.3
105 5.7 5.7 5.8 5.8 5.8 5.9 5.9 9.2 12.4 15.7 18.9
110 5.5 5.5 5.5 5.4 5.4 5.4 5.4 7.7 10.0 12.2 14.5
115 5.3 5.2 5.1 5.1 5.0 — — 6.2 7.5 8.8 10.1
INDOOR DB
TEMPERATURE,
°F
HEATING SUPERHEAT AT COMPRESSOR SUCTION, °F
-100 102030405060
55 — 3.0 3.5 4.2 5.1 6.5 8.5 11.3
70 ————3.14.56.59.3
80 ———————4.8
TABLE 14 - COOLING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 1,400 CFM (B1HH042)
TABLE 17 - HEATING SUPERHEAT AT COMPRESSOR SUCTION, AIRFLOW = 1,600 CFM (B1HH048)
