14 Unitary Products Group
66297-YIM-C-0205
FIG. 4 - DIMENSIONS
OUTDOOR
COIL
15
4
BACK
SIDE RETURN
AIR OPENING
SIDE SUPPLY
AIR OPENING
BOTTOM RETURN
AIR OPENING
15
15
BOTTOM SUPPLY
AIR OPENING
LOW VOLTAGE CONN.
“ DIA. KNOCKOUT
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
FRONT
ELECTRICAL/FILTER
SERVICE ACCESS
COMPARTMENT PANEL
(OVERALL)
(OVERALL)
All dimensions are in inches. They are
subject to change without notice. Certified
dimensions will be provided upon request.
UNIT CONDENSATE
CONNECTION
“ NPTI
(TRAP REQUIRED)
(OVERALL)
SIDE SUPPLY
AIR OPENING
SIDE RETURN
AIR OPENING
COMPRESSOR
SERVICE ACCESS
COMPARTMENT PANEL
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
HIGH VOLTAGE CONN.
" DIA. KNOCKOUT
REFRIGERANT
CONNECTIONS
“A”
UNIT SIZE
DIMENSION
“A”
018 - 036 33-1/2
042 - 060 41-1/2
CONDENSATE
DRAIN
“ NPTI
LOW VOLTAGE CONN.
“ DIA. KNOCKOUT
HIGH VOLTAGE
CONN.
“ x " DIA.
KNOCKOUT
FRONT
6
