246814-YTG-D-0606
Unitary Products Group 15
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO.
AY036MA321
INDOOR COIL MODEL NO.
G2FD042S21
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM
1000 1200 1400
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65
T.C. 32.8 38.1 37.1 40.4 46.6 35.6 38.7 37.7 41.4 46.9 38.3 39.3 38.4 42.3 47.2
S.C. 32.8 30.6 25.5 25.6 21.0 35.4 33.3 27.6 27.8 22.0 37.5 36.0 29.8 29.9 22.9
KW 2.5 2.5 2.5 2.5 2.6 2.5 2.5 2.5 2.5 2.6 2.5 2.5 2.5 2.5 2.6
75
T.C. 32.0 35.9 35.4 38.5 43.7 34.2 36.6 35.9 39.4 44.1 36.4 37.2 36.4 40.3 44.4
S.C. 32.0 29.6 24.8 24.8 20.5 33.8 32.3 26.9 27.0 21.7 35.6 34.9 29.0 29.2 22.9
KW 2.7 2.7 2.7 2.7 2.8 2.7 2.7 2.7 2.8 2.8 2.7 2.7 2.7 2.8 2.8
85
T.C. 31.2 33.8 33.7 36.6 40.9 32.9 34.5 34.1 37.4 41.3 34.5 35.2 34.5 38.2 41.6
S.C. 30.7 28.6 24.1 23.9 20.0 32.2 31.2 26.2 26.2 21.4 33.6 33.9 28.2 28.5 22.8
KW 2.9 2.9 2.9 3.0 3.0 2.9 2.9 2.9 3.0 3.1 3.0 3.0 2.9 3.0 3.1
95
T.C. 30.4 31.6 32.0 34.7 38.0 31.5 32.3 32.3 35.4 38.4 32.6 33.1 32.5 36.1 38.9
S.C. 29.3 27.6 23.4 23.1 19.5 30.5 30.2 25.4 25.4 21.1 31.7 32.8 27.4 27.7 22.7
KW 3.1 3.1 3.1 3.2 3.3 3.1 3.2 3.1 3.2 3.3 3.2 3.2 3.2 3.2 3.3
105
T.C. 28.7 29.5 29.8 32.5 35.7 29.9 30.4 30.2 33.1 36.1 31.0 31.2 30.5 33.6 36.6
S.C. 27.8 26.5 22.5 22.4 18.6 28.9 28.8 24.4 24.6 20.1 30.0 31.0 26.4 26.8 21.6
KW 3.3 3.3 3.3 3.4 3.5 3.4 3.4 3.3 3.4 3.5 3.4 3.4 3.4 3.5 3.6
115
T.C. 27.1 27.6 27.7 30.4 33.5 28.3 28.5 28.2 30.8 33.9 29.4 29.4 28.6 31.2 34.3
S.C. 26.2 25.4 21.6 21.7 17.7 27.2 27.4 23.5 23.8 19.1 28.3 29.3 25.3 25.9 20.5
KW 3.5 3.5 3.5 3.6 3.7 3.6 3.6 3.5 3.7 3.8 3.6 3.6 3.6 3.7 3.8
125
T.C. 25.4 25.6 25.6 28.2 31.3 26.6 26.6 26.1 28.5 31.7 27.8 27.6 26.7 28.8 32.0
S.C. 24.7 24.3 20.7 21.0 16.8 25.6 25.9 22.5 23.0 18.1 26.6 27.5 24.3 24.9 19.4
KW 3.7 3.7 3.7 3.8 4.0 3.8 3.8 3.7 3.9 4.0 3.9 3.9 3.8 3.9 4.0
NOTE: ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
MV12B FC/MC42B 1.01 1.02 1.01
MV12B G4FD046H17T2A 1.01 1.02 1.01
MV16C FC/MC42C 1.02 1.02 0.97
MV16C FC/MC48C 1.02 1.02 0.97
MV16C G4FD042H21T2A 1.02 1.02 0.97
MV16C G4FD048H21T2A 1.02 1.02 0.97
MV20D FC/MC48D 1.02 1.02 0.97
MV20D G4FD048H24T2A 1.02 1.02 0.97
AHP42 — 1.00 1.00 1.00
F4FP042H06T2A — 1.00 1.00 1.00
— FC/MC/PC42 1.00 1.00 1.00
— FC/MC/PC48 1.00 1.00 1.00
— G4FA048S17T2A 1.00 1.00 1.00
— G4FA048S21T2A 1.00 1.00 1.00
— G4FD042H21T2A 1.00 1.00 1.00
— G4FD046H17T2A 1.00 1.00 1.00
— G4FD048H21T2A 1.00 1.00 1.00
— G4FD048H24T2A 1.00 1.00 1.00
— HC48 1.00 1.00 1.00
— UC42 1.00 1.00 1.00
— UC48 1.00 1.00 1.00
Variable Speed
Furnace
Coil T.C. S.C. KW
PV8*B16 FC/MC/PC42B 1.01 1.02 0.97
PV8*C16 FC/MC/PC42C 1.02 1.02 0.97
PV8*C20 FC/MC/PC42C 1.02 1.02 0.97
PV9*B12 FC/MC/PC42B 1.01 1.01 1.01
PV9*C16 FC/MC/PC42C 1.01 1.02 1.01
PV9*C20 FC/MC/PC42C 1.01 1.02 1.01
PV8*C16 FC/MC/PC48C 1.02 1.02 0.97
PV8*C20 FC/MC/PC48C 1.02 1.02 0.97
PV9*C16 FC/MC/PC48C 1.01 1.02 0.97
PV9*C20 FC/MC/PC48C 1.01 1.02 0.97
PV9*D20 FC/MC/PC48D 1.01 1.02 0.97
PV8*B16 G4FA048S17T2A 1.01 1.02 0.97
PV9*B12 G4FA048S17T2A 1.01 1.01 1.01
PV8*C16 G4FA048S21T2A 1.02 1.02 0.97
PV8*C20 G4FA048S21T2A 1.02 1.02 0.97
PV9*C16 G4FA048S21T2A 1.01 1.02 1.01
PV9*C20 G4FA048S21T2A 1.01 1.02 1.01
PV8*C16 G4FD042H21T2A 1.02 1.02 0.97
PV8*C20 G4FD042H21T2A 1.02 1.02 0.97
PV9*C16 G4FD042H21T2A 1.01 1.02 1.01
PV9*C20 G4FD042H21T2A 1.01 1.02 1.01
PV8*B16 G4FD046H17T2A 1.01 1.02 0.97
PV9*B12 G4FD046H17T2A 1.01 1.01 1.01
PV8*C16 G4FD048H21T2A 1.02 1.02 0.97
PV8*C20 G4FD048H21T2A 1.02 1.02 0.97
PV9*C16 G4FD048H21T2A 1.01 1.02 0.97
PV9*C20 G4FD048H21T2A 1.01 1.02 0.97
PV9*D20 G4FD048H24T2A 1.01 1.02 0.97
PV8*C16 HC48 1.02 1.02 0.97
PV8*C20 HC48 1.02 1.02 0.97
PV9*C16 HC48 1.01 1.02 1.01
