PARTS ILLUSTRATION
Front View
1. Control Panel
2. Cold Air Outlet
3. Adjustable Louvers
Rear View
4. Air Filter
5. Rating Plate
6. Drain Hose (A)
7. Drain Hose (B)
8. Exhaust Air Outlet
Control Panel
1. Power ON/OFF Button
2. Function Button
3. Timer Setting Button
4. A/C Fan Speed Button
5. Sleep Function Button
1
2
3
4
5
6
7
8
6. LED Display
7. Alarm Indicator Light
8. Thermostat Temperature Setting Buttons
9. Air Conditioner Indicator Light
10. Dehumidifier Indicator Light
