Do not install and use your air conditioner before completely reading these instructions.
This will help you optimize the operation of your air conditioner. Make sure that you haven’t
lost the small box placed on the top of the unit; it contains all accessories, which are
essential for use.
Each person present in a room provides
between 100 Watts and 150 Watts of heat.
Consequently, the more people there are in a
room, the less effective the unit will be in
cooling.
Blocking of the filter reduces the efficiency
of the air and increases its power
consumption by up to 6%.
Avoid opening doors frequently.
1. Your unit must always be used in an
upright position because it contains a
cooling agent.
2. After unpacking, place the unit upright to
allow the cooling agent to stabilize, and wait
3 hours before use.
Failure to comply with these instructions
may damage the unit and will invalidate the
warranty.
Using your unit in wine cellars or in any
room with a temperature under 61°F is not
recommended.
The following advice and instructions should be followed closely:
IMPORTANT INSTRUCTIONS
ENERGY SAVING TIPS
TECHNICAL SPECIFICATIONS
Cooling Capacity
Power Input
Coolant
Moisture Removal
Airflow Volume
Temperature Range
Voltage/Frequency
Product Dimension (WxHxD)
Product Measurement
Product Weight
Drain Hose Length
Exhaust Hose Length
Exhaust Hose Diameter
Condensation Tank Capacity
12,000 BTU/Hour
1200 Watts / 10Amps
R-22
3 1/2 Pints / Hour (40 Liters / Day)
247 CFM (Cubic Feet / Minute)
61
o
-
90
o
F (16
o
-
32
o
C)
120V/60Hz
18 in (W) x 16 1/2 in (D) x 35 in (H)
460mm(W) x 420mm(D) x 880mm(H)
6 Cubic Feet
Net Weight: 97 lbs. / 44 kgs.
Gross Weight: 118 / 54 kgs.
9 1/2 feet
11 1/2 inches (compressed); Extends up to 5 feet
Inside: 4 3/8 inches / Outside: 5 1/8 inches
2 3/4 Cups (0.65 Liters)
