9
Step 9: Installing Deluxe Wireless Wall Station (if included)
Install all wall controls out of the reach of children and in a
location where the door can be seen before activating. Do
not mount push buttons near or next to garage door.
Locate a convenient place to mount wall station. To keep wall station out of
the reach of children, measure at least five feet up from the floor and secure
wall station base into wood wall framing using (2) Phillips head screws. Pilot
drill mounting holes using a 3/32" bit. Use 2 of 3 holes that best align with
wood framing.
CAUTION: Over tightening the screws could deform plastic base and
interfere with circuit board snaps.
NOTE: Insert bottom of circuit board behind bottom snap of wall sta-
tion base. Pivot circuit board up until board snaps into place. For
best results, press on circuit board between battery terminals.
Insert battery onto circuit board being careful to match (+) positive
battery marking with (+) circuit board marking. Align wall station
cover/button assembly with base. Press cover assembly over base
until cover snaps into place. A uniform seam between the cover and
base indicates a proper installation.
Step 10: Install Entrapment Warning Label
Install Entrapment Warning Label next to
wall station in a prominent location
Install Entrapment Warning Label next to Wall Station as
illustrated. If label adhesive will not adhere to the sur-
face, secure the label by additional mechanical means
such as staples, nails or screws.
