Page 22
506510−01
Main Control Jumpers and Terminals
MAIN CONTROL Ċ AIR CONDITIONER Ċ ONE STAGE
TABLE 3 PROVIDES ADDITIONAL INFORMATION CONCERNING JUMPERS, LOOP, AND CONNECTIONS
FOR THE MAIN CONTROL.
DS13 and DS15
DS11 and DS14
LED ALERT CODES
LED ALERT CODES
CUT FOR HUMIDITROL Ċ ENHANCED
DEHUMIDIFICATION ACCESSORY (EDA)
APPLICATIONS.
W1
E12
E16
E33
TEST PINS
Figure 8. Control Jumpers, Loop and Terminals
