CLEARANCE TO COMBUSTIBLES
The following clearances meet the minimum requirements for a safe
installation:
Side wall:
17” (324 mm) measured from the fireplace side.
Ceiling: 6’ 8” (2,032 mm) measured from the base of the fireplace.
Fireplace enclosure:
Bottom: 0”
Side: 0” to spacer
Back: 0” to spacer
Top: Do not fill the space above the fireplace with any material
(Except the wood framing. See Page 9, Figure 8).
Chimney: 2” (50 mm)
Mantel: 45” (1143 mm) measured from the base of the fireplace.
Brentwood™ Replacement Parts
Description Cat./Part No.
Baffle Refractory (2 Pieces) PR-ISO2205
Back Refractory PR-SR2203
Right Side Refractory PR-SR2204D
Left Side Refractory PR-SR2204G
Bottom Refractory PR-SR2201
Front Refractory, Right Side - Ash Lip PR-SR2202D
Front Refractory, Left Side - Ash Lip PR-SR2202G
Door Handle PR-SR2325
Ceramic Glass Panel PR-SR2222-1
Secondary Air Tube PR-SR2271
Cast-iron Log Retainer Supports - Grate (2) PR-SR2324
Cast Iron Log Retainer Bar (w/Lennox Logo) PR-SR2323
Touch-up Paint, Aerosol, Black Metallic SBMB6309 70K99
Louvers, Upper and Lower PR-SR2218-1
Snap Disc, Blower VTU
Bracket, Secondary Air Tube SR2214
Hinge Assembly, Fireplace and Door PR-SR2395UL
Handle, Door Rod SR2395
Gasket, Door, 73” (5/8” dia.) SR1823G
Gasket, Glass, 69” (5/16” dia.) SR1823H
Door Handle Brass Cap POIGNE002
REPLACEMENT PARTS LIST
SPECIFICATIONS
Cat. No. Model
H4825 Brentwood SP
Product Reference Information
Weight 385 lbs
Height 36”
Width 36”
Depth 24-1/2”
Firebox W x H x D - measured in front 22” x 11-3/4” x 12”
Chimney weight ASHT (6” dia) 6.25 lb/ft.
Chimney weight AC (6” dia) 3.25 lb/ft.
23
