Inserting the bobbin
1 Place the Bobbin in the Bobbin Holder with the
thread running off in the counterclockwise
direction.
1 Thread
2 Bobbin holder
2 Guide the thread into front notch on the front of
the bobbin holder.
Draw the thread to the left, sliding it between the
tension spring blades.
3 Front notch
3Continue to draw the thread lightly until the
thread slips into side notch.
Pull out about 10 cm (4") of thread to the rear.
4 Side notch
4 Refer to the threading chart shown on the hook
cover plate.
Reattach the hook cover plate.
4 Hook cover plate
5 Threading chart
1
2
3
4
1
2
3
4
4
5
