39
Edit
Edit
A Z
B: 140x200mm
Mode
Cancel
OK
Size
(1)
Edit
Edit
A Z
B: 140x200mm
Mode
Cancel
OK
Size
(2)
(3)
Edit
Edit
A Z
A(F): 126x110mm
Mode
Cancel
OK
Size
C
A(F)
B
Cancel
OK
A(F): 126x110mm
OK
Cancel
1
2
(1) Layout keys
You can move the selected pattern also by pressing
layout keys
Press the Layout Keys to move the pattern to the
desired position on the Edit screen.
The carriage will not move when you are pressing the
layout keys since pattern position will move relatively to
the hoop, not to the machine.
NOTES:
The appearance of the layout keys is the same as the
jog keys but their function is different.
Use the jog keys to move the carriage.
When you press the cancel key, any changes that have
been made to the selected pattern will be cancelled.
(2) Cancel key
Selecting the hoop size
In the editing window, you need to select the
appropriate size of the embroidery hoop by pressing the
hoop selection key.
There are two hoop size selections:
Embroidery Hoop A, 12.6 cm (4 3/8”) by 11 cm (4 3/8”)
Embroidery Hoop B, 20 cm (8”) by 14 cm (5 1/2”)
(3) Hoop Selection Key
Press the OK key and the Editing window for the
selected hoop will appear.
1 OK key
Pres the Cancel key to return to the default setting
(Hoop B).
2 Cancel key
