SAVE THESE INSTRUCTIONS
Page 9
(58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.5” PANTONE 295U 01/19/2007
MMAAIINNTTEENNAANNCCEE
It is recommended that the filter cartridge be replaced at least
every 2 weeks.
1. Make sure filter pump is not operating. Disconnect line cord.
2. To prevent water from escaping the pool, unscrew the strainer grids from the
strainer connectors and insert the hat-like plugs into the strainer connectors.
3. In a counter-clockwise motion, remove threaded cover (3) and cover seal (4).
Be careful not to lose the cover seal (4).
4. Remove filter cartridge (5) to clean it. The filter may be cleaned from the spray
from a water hose.
5. Use judgement as to whether cartridge needs to be replaced.
6. Return cartridge to filtering position.
7. Return the seal (4) and threaded cover (3) to their original positions. Tighten
the threaded cover (3) by hand only, twisting it in a clock-wise direction.
8. After service, open the air release valve, remove the plugs, allow any air to
escape through the valve before tightening the valve again and replace the
strainer grids. The pump is now primed with water again and may be turned on.
FILTER CARTRIDGE CLEANING OR REPLACEMENT
