SAVE THESE INSTRUCTIONS
Page 11
(58) MODEL 604 FILTER PUMP ENGLISH 7.5” X 10.5” PANTONE 295U 01/19/2007
TROUBLESHOOTING GUIDE
TTRROOUUBBLLEESSHHOOOOTTIINNGG GGUUIIDDEE
FILTER MOTOR
FAILS TO START
FILTER DOESN’T
CLEAN POOL
FILTER DOESN’T
PUMP WATER OR
FLOW IS VERY
SLOW
PUMP DOESN’T
WORK
TOP COVER
LEAKING
HOSE LEAKING
AIR LOCK
• Not plugged in.
• Fuse box needs checking.
• GFCI/RCD circuit breaker
tripped.
• Improper chlorine or pH
levels.
• Filter cartridge dirty.
• Cartridge damaged.
• Excessively dirty pool.
• Strainer screen restricting
flow.
• Inlet/discharge clogged.
• Air leak on intake line.
• Scale or buildup on cartridge.
• Excessively dirty pool.
• Filter cartridge dirty.
• Low water level.
• Strainer screen plugged up.
• Air leak on intake hose.
• Faulty motor or impeller
jammed.
• Air lock inside cartridge
chamber.
• O-ring missing.
• Cover not tight.
• Filter cartridge dirty.
• Hose clamps.
• Pump housing and inlet hose
air trapped.
TROUBLE CHECK POSSIBLE SOLUTIONS
•
Filter cord must be plugged into a 3 wire
outlet that is protected by a Class A
Ground Fault Circuit Interrupter, or RCD.
• Reset circuit breaker. If circuit breaker
trips repeatedly, your electrical system
may have a defect.Turn off circuit
breaker and call an electrician to
correct the problem.
• Motor too hot and overload protection
shut motor off. Let motor cool down.
•
Adjust chlorine and pH level. Consult
your local swimming pool supply stores.
• Clean or replace cartridge.
• Check for holes in cartridge. Replace
if damaged.
• Operate filter for longer periods.
• Clean strainer screen at pool wall inlet.
• Look for obstructions in intake hose or
discharge hose inside pool wall.
• Tighten hose clamps, check hoses for
damage, check pool water level.
• Replace cartridge.
• Clean cartridge more often.
• Fill pool to correct water level.
• Clean strainer screens at pool inlet.
• Tighten hose clamps, check hose for
damage.
• Check & clear any sticks or leaves in
intake to pump.
• Open release valve at top of pump.
• Remove cover & check for O-ring.
• Tighten cover (Manually).
• Replace or clean cartridge.
• Tighten/change hose clamps.
• Open air release valve, lift and lower
the inlet hose until water starts to flow
out of the air release valve, close air
release valve.
• To facilitate the connection of the hoses into the black protruding hose connectors on
the liner, you may use soapy water solution (mix 6 drops of dish washing liquid in 1/2 a
cup of water) to lubricate the hoses and the black protruding hose connectors. Continue
per owner's manual.
• Do not use lubricants such as machine or industrial oil or grease.
