SET-UP INSTRUCTIONS
Be sure you have access to water to fill the pool and chemicals for the water. A
small coin can be used to tighten the hose clamps (8).
IMPORTANT:This filter pump is shipped with the air release valve (1) open
(open the air release valve if necessary). DO NOT replace the air release valve
until you reach STEP #8. Failure to follow these instructions will result in air
trapped inside filter housing; the motor will run dry, be noisy and
malfunction.
1. Assemble above-ground-pool first. Carefully follow the pool’s installation
instructions.
2. Place the Filter-Pump the length of the hose away from the pool wall where the
lower black protruding hose connection is "sticking-out".
3. Remove wall plugs and then insert the strainers (6) into each of the protruding
hose connections. The hoses (7) fit over the strainers inserted into the
connections.
4. There are two hoses to be connected to the Filter-Pump hose connections.
With hose clamps (8), fasten one of the hoses (7) to the lower protruding hose
connection (marked "+" on the pool liner) and to the pump connection (marked
"+").
5. Connect the second hose to the remaining upper protruding hose connection
and to the lower pump connection. Make sure all the hose clamps (8) are tight.
6. Twist the Filter-Pump’s threaded cover (3) in a clock-wise direction to be sure it
is on "tight". Use only your hands to tighten the top. Do not tighten with tools
such as pliers.
7. Fill the pool to a level of at least 1-2 inches above the top connection. The
water will automatically flow down into the pump.
8. When water starts flowing out of the air release valve hole, screw in the air
release valve back into the filter housing cover. Do not over tighten the valve.
NOTE: Venting the system is necessary for air to escape as the filter
housing fills with water.
9. Connect the filter pump to the power outlet. The filter pump is now filtering the
water.
10. Operate the filter pump until the desired water clarity is obtained.
WARNING
Risk of electric shock. Connect this product only to a grounding
type receptacle protected by a ground-fault circuit interrupter
(GFCI) or residual current device (RCD). Contact a qualified
electrician if you cannot verify that the receptacle is protected by a
GFCI/RCD. Use a qualified electrician to install the GFCI/RCD,
which has a maximum rate of 30mA. Do not use a portable residual
current device (PRCD).
