Test the Silent Alert
Step 1 -
After the Silent Alert has been successfully
linked with the Control Center, press and hold the
Mute button on the Control Center for three seconds.
This action sends a test signal.
Step 2 - When the Silent Alert receives the test signal
from the Control Center, one LED indicator on the
Silent Alert will begin to flash once a second. It will
continue to flash for 30 seconds.
Alarm Siren
The Alarm Siren will increase your system’s sound. Use
in areas where Control Center Siren cannot be heard.
Adding a Alarm Siren
Step 1 - Remove cover
on top of the Alarm
Siren. Plug in the AC
adapter. Insert the
antenna and slide
mode switch to the
‘ON’ position.
Step 2 - Press and hold
the Learn button inside
the Alarm Siren. The ‘ON’ indicator on the front will
begin to flash and it will sound three beeps.
Step 3
- While continuing to press the Learn button,
press and hold the Mute button on the side of the
Control Center for three seconds. The Control Center
will send a test signal to the Alarm Siren.
When the Alarm Siren receives the test signal it will
sound a long tone and the ‘ON’ indicator will stop
flashing. This indicates the Alarm Siren has been linked
with the Control Center. Replace cover to Alarm Siren.
Test the Alarm Siren
Step 1 - After the Alarm Siren has been successfully
linked with the Control Center press and hold the
Mute button on the Control Center for three seconds.
Step 2 - When the Alarm Siren receives the test
signal from the Control Center, one LED indicator
on the Alarm Siren will begin to flash. It will continue
to flash for 30 seconds. This indicates it has received
the test signal.
The Signal Repeater will
extend the range of the
Choice Alert system up to
150 feet from its location
– Effectively repeating the
signal from any Sensor
back to the Control Center
should a Sensor be located
out of range. The Signal Repeater does not send or
receive signals to the Silent Alert or Alarm Siren.
Adding a Signal Repeater
Step 1 - Find an electric outlet near the Sensor
having trouble communicating with the Control
Center. Make certain the location is between the
Sensor and Control Center. Plug the Signal Repeater
into the outlet and press the ‘Test’ button on the side
of Signal Repeater. It will send a test signal out to
the Control Center and the LED indicator on the
Signal Repeater will flash rapidly for about one
second, then go out.
Test
Low BattOn Armed
ON/OFF LEARN
Low BattOn Armed
ON/OFF LEARN
45129
45132
Motion
Sensor
45133
Water Leak
Sensor
45131
Window/Door
Sensor
45136
Alarm Siren
45138
Signal
Repeater
45132
Silent alert
45130
Garage
Door Sensor
