Step 3:
Carefully turn the ends (A) over so the side without the hidden cams is facing up.
Use a Phillips screwdriver to screw eight black 9/16" flat head screws (FF) (four per end) into the ends (A) until
the shoulders of the screws rest on the surface of the ends. Do not screw the screws in all the way.
Align the groove on a top rail (O) over the top screw head on one of the ends (A), then slide the rail over the
other screw head. Make sure that the ends of the rail are flush with the edges of the end. Repeat to attach the
other top rail (O) to the other end (A).
Align the groove on a bottom rail (P) over the bottom screw head on one of the ends (A), then slide the rail
over the other screw head. Make sure that the ends of the rail are flush with the edges of the end. Repeat to
attach the other bottom rail (P) to the other end (A).
Yo u’ l l n ee d :
Apply pressure with your hand as you
guide the rails over the screws on the
ends.
Screw head
FF (8)Phillips screwdriver
