13
DX-WD1202
Need help? Call 800-305-2204
Step 7:
Fasten the shelf (F) to the left end (A). Use a flatblade screwdriver to tighten the two hidden cams. See
“Tightening hidden cams” on page 7.
Fasten the shelf (F) to the upright (B). Use a Phillips screwdriver and two black 1 7/8" flat head screws (DD).
Fasten the lower upright (C) to the shelf (F). Use a flatblade screwdriver to tighten the two hidden cams.
You’ll need:
fi nie
fi cie sin acabado
Chant fi ni
Surface without
hidden cams
Finished
edge
Unfinished
surface
Arrow
210°
Flatblade screwdriver
Phillips screwdriver
DD (2)
