Bryant 265A Heat Pump User Manual



24
DETAILED COOLING CAPACITIES CONTINUED
EVAPORATOR
AIR
CONDENSERENTERINGAIRTEMPERATURESdegF
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys-
tem
KW*
*
Capacity
MBtuh†
Total
Sys-
tem
KW*
*
Capacity
MBtuh†
Total
Sys-
tem
KW*
*
Capacity
MBtuh†
Total
Sys-
tem
KW*
*
Capacity
MBtuh†
Total
Sys-
tem
KW*
*
Capacity
MBtuh†
Total
Sys-
tem
KW*
*
Total
Sens
Total
Sens
Total
Sens
Total
Sens
Total
Sens
Total
Sens
265ANA060---BOutdoorSectionWithFX4CNF060IndoorSection
1750
72 71.33 36.68 4.31 67.94 35.37 4.75 64.29 33.97 5.23 60.48 32.53 5.76 56.36 31.00 6.34 51.80 29.32 6.95
67 65.68 45.79 4.24 62.55 44.44 4.68 59.19 43.00 5.17 55.69 41.53 5.70 51.91 39.96 6.27 47.75 38.25 6.89
63 61.47 44.48 4.19 58.52 43.11 4.63 55.39 41.68 5.12 52.12 40.20 5.65 48.60 38.63 6.22 44.75 36.92 6.84
62 60.32 54.79 4.18 57.45 53.36 4.62 54.41 51.84 5.11 51.27 50.21 5.64 48.05 48.05 6.22 44.86 44.86 6.84
57 58.31 58.31 4.16 55.99 55.99 4.61 53.53 53.53 5.10 50.90 50.90 5.63 48.05 48.05 6.22 44.86 44.86 6.84
2000
72 72.40 38.30 4.40 68.88 36.98 4.84 65.09 35.56 5.33 61.15 34.10 5.86 56.89 32.55 6.43 52.19 30.86 7.04
67 66.76 48.55 4.34 63.50 47.18 4.78 60.00 45.72 5.26 56.37 44.22 5.79 52.46 42.62 6.36 48.17 40.87 6.98
63 62.55 47.09 4.29 59.48 45.70 4.73 56.22 44.24 5.21 52.82 42.73 5.74 49.18 41.12 6.31 45.20 39.37 6.93
62 61.49 58.54 4.28 58.54 57.01 4.72 55.41 55.41 5.20 52.57 52.57 5.74 49.53 49.53 6.32 46.13 46.13 6.95
57 60.49 60.49 4.27 58.02 58.02 4.71 55.37 55.37 5.20 52.58 52.58 5.74 49.53 49.53 6.32 46.13 46.13 6.95
2250
72 73.17 39.84 4.49 69.54 38.50 4.93 65.65 37.08 5.42 61.60 35.61 5.94 57.24 34.04 6.51 52.42 32.34 7.12
67 67.52 51.19 4.43 64.16 49.81 4.87 60.56 48.32 5.35 56.83 46.79 5.88 52.83 45.15 6.45 48.44 43.34 7.07
63 63.34 49.57 4.38 60.17 48.16 4.82 56.81 46.67 5.30 53.32 45.13 5.83 49.59 43.48 6.40 45.51 41.66 7.02
62 62.50 61.84 4.37 59.65 59.65 4.81 56.86 56.86 5.31 53.91 53.91 5.84 50.70 50.70 6.42 47.12 47.12 7.05
57 62.26 62.26 4.37 59.66 59.66 4.81 56.86 56.86 5.31 53.92 53.92 5.84 50.71 50.71 6.42 47.12 47.12 7.05
CoolingIndoor Model Capacity Power FurnaceModel
*FX4CN(B,F)060 1.00 1.00
FE4ANB006 0.99 0.99
FV4BNB006 0.99 0.99
FY4ANB060 0.99 1.06
CAP**6021A** 0.97 0.99
CAP**6024A** 0.98 1.03
CNPH*6024A** 0.98 1.03
CNPV*6024A** 0.98 1.03
CSPH*6012A** 0.98 1.02
CoolingIndoor Model Capacity Power FurnaceModel
CAP**6021A** 0.97 0.99 315(A,J)AV060110
CNPH*6024A** 0.98 1.00 315(A,J)AV060110
CSPH*6012A** 0.98 1.00 315(A,J)AV060110
CAP**6024A** 0.98 1.00 315(A,J)AV066135
CNPH*6024A** 0.98 1.00 315(A,J)AV066135
CNPV*6024A** 0.98 1.00 315(A,J)AV066135
CSPH*6012A** 0.98 1.00 315(A,J)AV066135
CAP**6024A** 0.98 1.01 315(A,J)AV066155
CNPH*6024A** 0.98 1.00 315(A,J)AV066155
CNPV*6024A** 0.98 1.00 315(A,J)AV066155
CSPH*6012A** 0.98 1.01 315(A,J)AV066155
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
* Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per ARI standard 210/240---94. If additional tubing length and/or
indoor unit is located above outdoor unit, a slight variation in capacity may occur.
{ Total and sensible capacities are net capacities. Blower motor heat has been subtracted.
} Sensible capacities shown are based on 80_F(27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C), deduct 835 Btuh
(245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80_F(27_C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air
per degree above 80_F(27_C).
** System kw is total of indoor and outdoor unit kilowatts.
{{ At TVA rating indoor condition (75_F edb/63_F ewb). All other indoor air temperatures are at 80_F edb.
EWB — Entering Wet Bulb
265A
