SC & SI Remote Interface Description en | 22
Bosch Security Systems B.V. | 2003 December | SC & SI Remote Interface Description
6 System Installation notifications
6.1 Introduction
This chapter defines the set of update notifications concerning SI send by the CCU. Each description is
according to the definition given in section 4.1.1.
6.1.1 Unit/user event relations
As for the SC application, update notifications for SI are also the results of user actions done on the actual
units. This section gives a unit/user event matrix for the SI application in which the possible user events are
linked with the corresponding update notification(s). For some events also the required remote functions to
continue the System Installation process are given.
The update notifications themselves are described in the remaining sections of this chapter.
UNIT-EVENT MATRIX
Event Update Notification Continue with remote function
Installation not yet started
Press a Soft-key on
a unit
<None>
Started Installation with SI_C_START_INSTALL (SI_C_GLOBAL_INSTALL_MODE)
Press a Soft-key on
a unit
SI_C_REGISTER_UNIT SI_C_SELECT_UNIT
See example-1 in Appendix Appendix
C
Started Installation with SI_C_START_INSTALL (SI_C_OPERATIONAL_INSTALL_MODE)
Press a Soft-key on
a unit
<None>
6.2 SI_C_REGISTER_UNIT
Purpose
Notifies the remote controller that during global installation (which implies that the CCU is in config mode, see
SI_C_START_INSTALL section 5.2) a soft key is pressed on a installable unit. A installable unit is a unit
which can be assigned with a seat number.
An overview of installable unit types is given in section 5.4.
The remote controller should use this update to assign a seat number to the unit identifier given with this
update notification.
Notify structure with this update
The update comes with the following structure:
typedef struct
{
WORD wUnitId;
BYTE byUnitType;
} SI_T_UNIT_STRUCT;
where:
wUnitId
The unit identifier of a unit. Also called unit-number.
byUnitType
The type of the unit. The different unit types possible are given
in section 3.6.
