271457-YTG-B-0908
Johnson Controls Unitary Products 33
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
OUTDOOR UNIT MODEL NO. YZB02411
INDOOR COIL MODEL NO. AHP24
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
600 800 1000
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 29.0 2.2 3.8 30.7 2.0 4.5 32.5 1.8 5.4
70 28.2 2.6 3.2 29.7 2.3 3.8 31.2 2.0 4.5
80 27.5 2.9 2.8 28.7 2.6 3.2 29.8 2.3 3.8
47
60 24.0 2.0 3.5 24.6 1.8 3.9 25.3 1.7 4.4
70 23.1 2.2 3.1 24.0 2.0 3.4 24.9 1.9 3.9
80 22.1 2.4 2.7 23.4 2.2 3.0 24.6 2.1 3.5
40
60 21.3 1.9 3.3 21.9 1.7 3.7 22.5 1.6 4.2
70 20.6 2.1 2.9 21.3 1.9 3.2 22.0 1.8 3.6
80 20.0 2.3 2.5 20.8 2.2 2.8 21.6 2.0 3.1
30
60 17.1 1.9 2.7 18.0 1.7 3.1 19.0 1.6 3.6
70 16.6 1.9 2.6 17.4 1.8 2.9 18.2 1.6 3.3
80 16.1 2.0 2.4 16.7 1.8 2.7 17.3 1.7 3.0
17
60 14.1 1.7 2.4 14.5 1.6 2.7 14.9 1.4 3.0
70 13.8 1.9 2.2 14.2 1.7 2.4 14.6 1.6 2.6
80 13.4 2.0 1.9 13.9 1.9 2.1 14.4 1.8 2.3
10
60 12.6 1.6 2.3 12.8 1.5 2.5 13.1 1.4 2.8
70 12.1 1.9 1.9 12.5 1.7 2.1 12.9 1.6 2.3
80 11.7 2.1 1.6 12.2 2.0 1.8 12.7 1.8 2.0
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil MBH KW COP
MA08B FC/MC24B 1.00 1.00 1.00
MA08B FC/MC30B 1.00 1.00 1.00
MV12B FC/MC24B 0.98 0.98 1.00
MV12B FC/MC30B 0.98 0.98 1.00
AV24 – 0.97 0.90 1.07
F*FP30 – 0.99 0.99 1.00
– FC/MC/PC/UC24 1.00 1.00 1.00
– FC/MC/PC/UC30 1.00 1.00 1.00
– HC30 1.00 1.00 1.00
– HD24 1.00 1.00 1.00
Variable Speed
Furnace
Coil MBH KW COP
PV8*A12 FC/MC/PC24A 0.97 0.97 1.00
PV8*A12 FC/MC/PC30A 0.97 0.97 1.00
PV8*A12 HC30 0.97 0.97 1.00
PV8*A12 HD24 0.97 0.97 1.00
PV9*A12 FC/MC/PC24A 0.97 0.92 1.05
PV9*A12 FC/MC/PC30A 0.97 0.92 1.05
Y*(8,L)C*A12 FC/MC/PC24A 0.98 1.08 0.91
Y*(8,L)C*B12 FC/MC/PC24B 0.98 1.09 0.90
Y*9C*B12 FC/MC/PC24B 0.98 1.08 0.91
Y*(8,L)C*A12 FC/MC/PC30A 0.98 1.08 0.91
Y*(8,L)C*B12 FC/MC/PC30B 0.98 1.09 0.90
Y*9C*B12 FC/MC/PC30B 0.98 1.08 0.91
Y*(8,L)C*A12 FC/MC/PC32A 0.98 1.07 0.92
Y*(8,L)C*A12 HC30 0.98 1.04 0.94
Y*(8,L)C*A12 HD24 0.98 1.04 0.94
Y*(8,L)C*B12 HD24 0.98 1.05 0.93
Y*9C*B12 HD24 0.98 1.04 0.94
Y*(8,L)C*A12 UC24A 0.98 1.09 0.90
Y*(8,L)C*B12 UC24B 0.98 1.10 0.89
Y*9C*B12 UC24B 0.98 1.09 0.90
Y*(8,L)C*A12 UC30A 0.98 1.09 0.90
Y*(8,L)C*B12 UC30B 0.98 1.10 0.89
Y*9C*B12 UC30B 0.98 1.09 0.90
G*9V*A12 FC/MC/PC24A 0.98 1.07 0.92
G*9V*B12 FC/MC/PC24B 0.98 1.08 0.91
G*9V*A12 FC/MC/PC30A 0.98 1.07 0.92
G*9V*B12 FC/MC/PC30B 0.98 1.08 0.91
G*9V*A12 FC/MC/PC32A 0.99 1.06 0.93
G*9V*A12 HC30 0.98 1.05 0.94
G*9V*A12 HD24 0.98 1.03 0.96
G*9V*B12 HD24 0.98 1.04 0.94
G*9V*A12 UC24A 0.98 1.08 0.91
G*9V*B12 UC24B 0.98 1.09 0.90
G*9V*A12 UC30A 0.98 1.08 0.91
G*9V*B12 UC30B 0.98 1.09 0.90
Variable Speed
Furnace
Coil MBH KW COP
