YORK INTERNATIONAL
46
YORK INTERNATIONAL
47
FORM 150.63-EG1
NOTES:
1. SST = Saturated Suction Temperature
2. kWo = Unit kW Cooling Capacity Output
3. kWi = Compressors kW Input
4. COP = Coefcient of Performance (based on compressor and fan input kW)
YCUL0086EB
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
269.6 72.4 3.4 255.0 80.5 2.9 240.0 89.4 2.5 224.8 99.2 2.1 174.4 85.6 1.9 135.1 74.1 1.7
3.0
279.2 73.0 3.5 264.2 81.1 3.0 248.7 90.1 2.6 233.0 99.9 2.2 181.0 86.2 2.0 140.3 74.6 1.7
4.0
289.0 73.7 3.6 273.5 81.8 3.1 257.6 90.8 2.6 241.4 100.7 2.2 187.8 86.7 2.0 145.6 75.0 1.8
5.0
299.0 74.4 3.7 283.1 82.5 3.2 266.7 91.6 2.7 250.0 101.6 2.3 194.8 87.3 2.1 151.1 75.5 1.8
6.0
309.3 75.0 3.8 292.9 83.2 3.3 276.0 92.4 2.8 258.8 102.4 2.4 202.0 87.9 2.1 156.4 76.2 1.9
7.0
319.9 75.8 3.9 302.8 84.0 3.3 285.5 93.2 2.9 267.8 103.3 2.4 174.2 69.2 2.3 162.2 76.6 1.9
8.0
330.6 76.5 4.0 313.0 84.8 3.4 295.2 94.1 2.9 277.1 104.2 2.5 180.5 69.6 2.4 168.2 77.1 2.0
9.0
341.5 77.3 4.1 323.5 85.7 3.5 305.1 94.9 3.0 286.4 105.2 2.6 187.0 70.0 2.4 174.4 77.5 2.1
10.0
352.7 78.2 4.2 334.2 86.5 3.6 315.3 95.8 3.1 296.0 106.2 2.6 193.7 70.4 2.5 180.7 78.0 2.1
11.0
364.2 79.0 4.2 345.1 87.4 3.7 325.6 96.8 3.1 256.4 82.6 2.9 200.5 70.9 2.6 187.2 78.5 2.2
12.0
375.8 79.9 4.3 356.2 88.3 3.7 336.2 97.8 3.2 265.1 83.3 2.9 207.5 71.4 2.7 193.8 79.0 2.3
YCUL0090EB
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
292.1 79.9 3.4 276.6 88.9 2.9 260.7 98.7 2.5 244.5 109.6 2.1 158.6 73.7 2.0 147.4 81.8 1.7
3.0
302.2 80.8 3.5 286.4 89.7 3.0 270.0 99.6 2.5 253.2 110.5 2.2 164.5 74.1 2.0 152.9 82.2 1.7
4.0
312.7 81.5 3.5 296.4 90.5 3.1 279.4 100.5 2.6 262.1 111.4 2.2 170.6 74.5 2.1 158.6 82.8 1.8
5.0
323.4 82.3 3.6 306.5 91.3 3.1 289.1 101.4 2.7 271.2 112.4 2.3 176.9 75.0 2.2 164.5 83.2 1.8
6.0
334.4 83.1 3.7 317.0 92.1 3.2 298.9 102.3 2.7 280.5 113.4 2.3 183.3 75.4 2.2 170.5 83.7 1.9
7.0
345.5 83.9 3.8 327.4 93.1 3.3 309.0 103.2 2.8 290.0 114.5 2.4 189.8 75.9 2.3 176.7 84.2 1.9
8.0
356.9 84.7 3.9 338.2 94.1 3.4 319.3 104.2 2.9 299.7 115.5 2.5 196.5 76.4 2.4 183.0 84.7 2.0
9.0
368.5 85.6 4.0 349.2 95.0 3.4 329.7 105.2 2.9 309.5 116.6 2.5 203.4 76.9 2.4 189.5 85.2 2.1
10.0
380.3 86.5 4.1 360.5 96.0 3.5 340.4 106.3 3.0 319.7 117.7 2.6 210.4 77.4 2.5 196.1 85.8 2.1
11.0
392.3 87.4 4.2 371.9 97.0 3.6 351.1 107.5 3.1 330.0 118.9 2.6 217.6 77.9 2.6 203.0 86.3 2.2
12.0
404.5 88.4 4.3 383.6 98.0 3.7 362.2 108.6 3.1 239.8 70.7 3.1 225.0 78.4 2.6 209.9 86.9 2.2
YCUL0096EB
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
282.1 71.9 3.4 267.8 79.1 3.0 252.8 87.1 2.6 236.9 96.4 2.2 221.8 105.8 1.9 203.5 118.0 1.6
3.0
292.8 72.4 3.5 278.1 79.6 3.1 262.6 87.7 2.7 246.2 96.9 2.3 230.5 106.4 2.0 211.7 118.6 1.6
4.0
303.9 73.0 3.6 288.7 80.2 3.2 272.8 88.3 2.8 255.8 97.5 2.4 239.4 107.0 2.0 220.2 119.1 1.7
5.0
315.1 73.5 3.7 299.5 80.8 3.3 283.0 88.9 2.8 265.7 98.1 2.4 247.1 108.6 2.1 228.8 119.7 1.8
6.0
326.6 74.1 3.9 310.5 81.5 3.4 293.6 89.6 2.9 275.7 98.7 2.5 257.9 108.5 2.2 237.7 120.4 1.8
7.0
338.4 74.8 4.0 321.8 82.2 3.5 304.4 90.3 3.0 286.0 99.4 2.6 267.6 109.2 2.2 246.9 121.0 1.9
8.0
350.3 75.5 4.1 333.3 82.9 3.6 315.4 91.0 3.1 296.5 100.1 2.7 276.4 110.5 2.3 255.1 122.5 1.9
9.0
362.5 76.2 4.2 345.1 83.6 3.7 326.7 91.8 3.2 307.2 100.9 2.8 286.6 111.3 2.4 264.7 123.2 2.0
10.0
375.1 76.8 4.3 357.1 84.4 3.8 338.2 92.6 3.3 318.2 101.7 2.8 297.1 112.1 2.4 274.7 123.9 2.0
11.0
388.0 77.5 4.4 369.3 85.2 3.9 349.9 93.4 3.4 329.4 102.5 2.9 307.8 112.9 2.5 212.1 87.0 2.2
12.0
401.1 78.3 4.5 381.9 86.0 4.0 362.0 94.2 3.5 340.9 103.4 3.0 318.7 113.7 2.6 220.1 87.4 2.2
YCUL0100EB
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
304.9 79.0 3.4 290.0 86.8 3.0 274.6 95.2 2.6 258.2 104.7 2.2 240.6 115.5 1.9 221.6 127.9 1.6
3.0
316.3 79.7 3.5 300.9 87.5 3.1 284.8 96.0 2.7 268.0 105.5 2.3 250.0 116.2 2.0 230.4 128.5 1.7
4.0
328.0 80.4 3.6 312.0 88.2 3.2 295.5 96.8 2.8 278.1 106.3 2.4 259.5 117.0 2.0 239.5 129.2 1.7
5.0
339.9 81.0 3.7 323.3 89.0 3.2 306.3 97.6 2.8 288.3 107.1 2.5 269.3 117.8 2.1 248.8 129.9 1.8
6.0
352.1 81.7 3.8 334.9 89.8 3.3 317.3 98.4 2.9 298.8 108.0 2.5 279.2 118.7 2.2 258.2 130.7 1.8
7.0
364.5 82.4 3.9 346.8 90.6 3.4 328.6 99.3 3.0 309.6 108.9 2.6 289.4 119.6 2.2 267.9 131.6 1.9
8.0
377.0 83.3 4.0 359.0 91.4 3.5 340.2 100.2 3.1 320.6 109.8 2.7 299.9 120.5 2.3 277.8 132.5 1.9
9.0
390.1 84.0 4.1 371.5 92.2 3.6 352.1 101.0 3.2 331.8 110.7 2.7 310.5 121.5 2.4 288.0 133.4 2.0
10.0
403.4 84.7 4.2 384.0 93.1 3.7 364.1 102.0 3.2 343.4 111.7 2.8 321.5 122.4 2.4 298.3 134.3 2.1
11.0
417.1 85.4 4.3 397.0 93.9 3.8 376.6 102.9 3.3 355.1 112.7 2.9 332.7 123.4 2.5 163.5 60.0 2.3
12.0
431.1 86.1 4.5 410.3 94.8 3.9 389.3 103.8 3.4 367.2 113.6 3.0 344.1 124.4 2.5 169.5 60.3 2.4
