FORM 150.63-EG1
Ratings - R22 (English Units)
NOTES:
1. SST = Saturated Suction Temperature
2. kW = Compressors Input Power
3. EER = Condensing Unit EER (includes power from compressors, fans and the control panel)
YCUL0016EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
14.0 10.9 12.2 13.6 11.5 11.4 13.3 12.2 10.6 13.0 12.9 9.9 12.6 13.6 9.2 12.3 14.5 8.5
37.0
14.5 11.0 12.6 14.2 11.6 11.8 13.8 12.3 11.0 13.5 13.0 10.2 13.1 13.7 9.5 12.8 14.5 8.8
39.0
15.1 11.1 13.0 14.7 11.7 12.2 14.3 12.3 11.4 14.0 13.0 10.6 13.6 13.8 9.8 13.3 14.6 9.1
41.0
15.6 11.1 13.5 15.2 11.7 12.6 14.9 12.4 11.7 14.5 13.1 10.9 14.1 13.9 10.2 13.8 14.7 9.4
43.0
16.2 11.2 13.9 15.8 11.8 13.0 15.4 12.5 12.1 15.0 13.2 11.3 14.7 14.0 10.5 14.3 14.8 9.7
45.0
16.8 11.3 14.3 16.4 11.9 13.4 16.0 12.6 12.5 15.6 13.3 11.6 15.2 14.1 10.8 14.8 14.9 10.1
47.0
17.4 11.4 14.7 17.0 12.0 13.8 16.6 12.7 12.9 16.2 13.4 12.0 15.8 14.1 11.2 15.4 15.0 10.4
49.0
18.1 11.5 15.2 17.6 12.1 14.2 17.2 12.8 13.3 16.8 13.5 12.4 16.3 14.2 11.5 15.9 15.1 10.7
51.0
18.7 11.6 15.6 18.2 12.2 14.6 17.8 12.9 13.6 17.4 13.6 12.7 16.9 14.4 11.9 16.5 15.2 11.0
53.0
19.4 11.7 16.1 18.9 12.3 15.0 18.5 13.0 14.0 18.0 13.7 13.1 17.6 14.5 12.2 17.1 15.3 11.3
55.0
20.1 11.8 16.5 19.6 12.4 15.5 19.1 13.1 14.5 18.7 13.8 13.5 18.2 14.6 12.6 17.7 15.4 11.7
YCUL0026EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
19.4 15.6 12.7 19.0 16.5 11.8 18.5 17.5 10.9 18.0 18.5 10.1 17.4 19.6 9.3 16.9 20.7 8.6
37.0
20.2 15.7 13.1 19.7 16.6 12.1 19.1 17.6 11.2 18.6 18.7 10.4 18.1 19.7 9.6 17.6 20.9 8.9
39.0
20.9 15.8 13.4 20.4 16.8 12.5 19.8 17.8 11.6 19.3 18.8 10.7 18.8 19.9 9.9 18.2 21.0 9.2
41.0
21.6 16.0 13.8 21.1 16.9 12.9 20.6 17.9 11.9 20.0 18.9 11.0 19.4 20.0 10.2 18.9 21.2 9.4
43.0
22.4 16.1 14.2 21.9 17.0 13.2 21.3 18.0 12.3 20.7 19.1 11.4 20.1 20.2 10.5 19.5 21.3 9.7
45.0
23.2 16.2 14.6 22.6 17.2 13.6 22.0 18.2 12.6 21.4 19.2 11.7 20.8 20.3 10.8 20.2 21.5 10.0
47.0
24.0 16.4 15.0 23.4 17.3 14.0 22.8 18.3 12.9 22.2 19.4 12.0 21.6 20.5 11.1 20.9 21.7 10.3
49.0
24.8 16.5 15.4 24.2 17.5 14.3 23.6 18.5 13.3 22.9 19.5 12.3 22.3 20.7 11.4 21.6 21.8 10.5
51.0
25.6 16.7 15.8 25.0 17.6 14.7 24.4 18.6 13.6 23.7 19.7 12.6 23.0 20.8 11.7 22.4 22.0 10.8
53.0
26.5 16.9 16.2 25.8 17.8 15.1 25.2 18.8 14.0 24.5 19.9 13.0 23.8 21.0 12.0 23.1 22.2 11.1
55.0
27.4 17.0 16.5 26.7 18.0 15.4 26.0 19.0 14.3 25.3 20.0 13.3 24.6 21.2 12.3 23.9 22.4 11.4
YCUL0030EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
23.9 19.7 12.7 23.3 20.7 11.9 22.8 21.9 11.1 22.2 23.0 10.3 21.6 24.3 9.6 21.0 25.6 8.9
37.0
24.8 19.9 13.1 24.2 20.9 12.3 23.7 22.0 11.4 23.1 23.2 10.6 22.4 24.5 9.9 21.8 25.8 9.1
39.0
25.7 20.0 13.5 25.1 21.1 12.6 24.5 22.2 11.8 23.9 23.4 11.0 23.3 24.6 10.2 22.6 26.0 9.4
41.0
26.6 20.2 13.9 26.0 21.2 13.0 25.4 22.3 12.1 24.8 23.5 11.3 24.1 24.8 10.5 23.4 26.2 9.7
43.0
27.6 20.4 14.3 26.9 21.4 13.4 26.3 22.5 12.5 25.7 23.7 11.6 25.0 25.0 10.8 24.3 26.4 10.0
45.0
28.5 20.6 14.7 27.9 21.6 13.7 27.2 22.7 12.8 26.6 23.9 12.0 25.9 25.2 11.1 25.1 26.5 10.3
47.0
29.5 20.8 15.0 28.9 21.8 14.1 28.2 22.9 13.2 27.5 24.0 12.3 26.8 25.3 11.4 26.0 26.7 10.6
49.0
30.6 21.0 15.4 29.9 21.9 14.5 29.2 23.0 13.5 28.4 24.2 12.6 27.7 25.5 11.7 26.9 26.9 10.9
51.0
31.6 21.2 15.8 30.9 22.1 14.9 30.1 23.2 13.9 29.4 24.4 13.0 28.6 25.7 12.0 27.8 27.1 11.2
53.0
32.7 21.4 16.2 31.9 22.3 15.2 31.2 23.4 14.3 30.4 24.6 13.3 29.6 25.9 12.4 28.8 27.3 11.5
55.0
33.7 21.6 16.6 33.0 22.6 15.6 32.2 23.6 14.6 31.4 24.8 13.6 30.6 26.1 12.7 29.7 27.5 11.8
YCUL0036EC
AIR TEMPERATURE ON CONDENSER (°F)
SST
(°F)
75°F 80°F 85°F 90°F 95°F 100°F
TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER TONS KW EER
35.0
28.9 23.9 13.0 28.2 25.3 12.0 27.5 26.8 11.2 26.8 28.3 10.3 26.1 30.0 9.5 25.4 31.7 8.8
37.0
29.9 24.1 13.3 29.2 25.5 12.4 28.5 27.0 11.5 27.8 28.5 10.6 27.1 30.2 9.8 26.3 32.0 9.1
39.0
31.0 24.3 13.7 30.3 25.7 12.7 29.6 27.2 11.8 28.8 28.8 11.0 28.1 30.4 10.1 27.3 32.2 9.4
41.0
32.1 24.6 14.1 31.4 26.0 13.1 30.6 27.4 12.2 29.9 29.0 11.3 29.1 30.7 10.4 28.3 32.4 9.6
43.0
33.2 24.8 14.4 32.5 26.2 13.4 31.7 27.7 12.5 30.9 29.2 11.6 30.1 30.9 10.7 29.3 32.7 9.9
45.0
34.4 25.1 14.8 33.6 26.4 13.8 32.8 27.9 12.8 32.0 29.5 11.9 31.2 31.2 11.0 30.3 32.9 10.2
47.0
35.5 25.3 15.2 34.7 26.7 14.1 33.9 28.2 13.2 33.1 29.7 12.2 32.3 31.4 11.3 31.4 33.2 10.5
49.0
36.7 25.6 15.5 35.9 27.0 14.5 35.1 28.4 13.5 34.2 30.0 12.5 33.4 31.7 11.6 32.5 33.5 10.7
51.0
37.9 25.9 15.9 37.1 27.2 14.8 36.2 28.7 13.8 35.4 30.3 12.8 34.5 32.0 11.9 33.6 33.8 11.0
53.0
39.2 26.2 16.2 38.3 27.5 15.2 37.4 29.0 14.1 36.6 30.6 13.1 35.6 32.3 12.2 34.7 34.1 11.3
55.0
40.4 26.5 16.6 39.5 27.8 15.5 38.6 29.3 14.4 37.7 30.9 13.4 36.8 32.6 12.5 35.8 34.4 11.6
