YORK INTERNATIONAL
28
YORK INTERNATIONAL
29
FORM 150.63-EG1
NOTES:
1. SST = Saturated Suction Temperature
2. kWo = Unit kW Cooling Capacity Output
3. kWi = Compressors kW Input
4. COP = Coefcient of Performance (based on compressor and fan input kW)
YCUL0040EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
123.8 31.6 3.6 118.3 34.8 3.2 112.5 38.3 2.7 106.2 42.3 2.4 99.4 46.6 2.0 64.4 31.4 1.9
3.0
127.8 31.9 3.7 122.2 35.1 3.2 116.2 38.6 2.8 109.8 42.6 2.4 102.9 46.9 2.1 66.7 31.5 1.9
4.0
131.9 32.1 3.8 126.1 35.3 3.3 120.0 38.9 2.9 113.4 42.9 2.5 106.3 47.3 2.1 69.1 31.7 2.0
5.0
136.2 32.4 3.9 130.1 35.6 3.4 123.8 39.2 3.0 117.1 43.2 2.6 109.9 47.6 2.2 71.5 31.8 2.1
6.0
140.4 32.7 4.0 134.2 35.9 3.5 127.7 39.4 3.0 120.8 43.5 2.6 113.5 47.9 2.2 73.9 32.0 2.1
7.0
144.8 32.9 4.1 138.4 36.1 3.6 131.7 39.8 3.1 124.6 43.8 2.7 117.1 48.3 2.3 76.4 32.1 2.2
8.0
149.3 33.2 4.1 142.6 36.4 3.6 135.7 40.1 3.2 128.5 44.1 2.7 120.8 48.6 2.4 79.0 32.3 2.3
9.0
153.8 33.5 4.2 147.0 36.7 3.7 139.8 40.4 3.2 132.4 44.4 2.8 124.6 49.0 2.4 81.6 32.4 2.3
10.0
158.4 33.8 4.3 151.4 37.0 3.8 144.0 40.7 3.3 136.4 44.8 2.9 128.4 49.3 2.5 84.2 32.6 2.4
11.0
163.1 34.1 4.4 155.8 37.3 3.9 148.3 41.0 3.4 140.5 45.1 2.9 132.3 49.7 2.5 86.9 32.7 2.5
12.0
167.9 34.4 4.5 160.4 37.6 4.0 152.6 41.3 3.5 144.6 45.5 3.0 136.3 50.0 2.6 89.6 32.9 2.5
YCUL0046EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
137.3 31.3 3.7 131.4 34.7 3.3 125.2 38.5 2.8 118.8 42.7 2.5 112.2 47.2 2.1 105.3 52.2 1.8
3.0
142.0 31.4 3.8 135.9 34.9 3.4 129.5 38.7 2.9 122.8 42.9 2.5 116.1 47.4 2.2 109.1 52.4 1.9
4.0
146.7 31.6 4.0 140.4 35.0 3.5 133.9 38.9 3.0 127.0 43.1 2.6 120.0 47.7 2.3 112.9 52.7 1.9
5.0
151.6 31.8 4.1 145.1 35.2 3.6 138.3 39.0 3.1 131.3 43.3 2.7 124.1 47.9 2.3 116.7 52.9 2.0
6.0
156.6 31.9 4.2 149.9 35.4 3.7 142.9 39.2 3.2 135.6 43.5 2.8 128.2 48.1 2.4 120.7 53.1 2.1
7.0
161.7 32.1 4.3 154.8 35.6 3.8 147.5 39.4 3.3 140.1 43.7 2.8 132.5 48.3 2.5 124.7 53.4 2.1
8.0
166.9 32.3 4.4 159.7 35.8 3.9 152.3 39.6 3.4 144.6 43.9 2.9 136.8 48.6 2.5 128.7 53.7 2.2
9.0
172.2 32.5 4.5 164.8 36.0 4.0 157.2 39.8 3.5 149.2 44.1 3.0 141.2 48.8 2.6 132.9 53.9 2.2
10.0
177.6 32.7 4.6 170.0 36.2 4.1 162.1 40.0 3.6 154.0 44.3 3.1 145.7 49.0 2.7 71.0 24.1 2.4
11.0
183.2 32.9 4.8 175.3 36.4 4.2 167.2 40.2 3.7 158.8 44.5 3.2 150.3 49.2 2.7 73.3 24.1 2.5
12.0
188.8 33.2 4.9 180.7 36.6 4.3 172.4 40.5 3.7 163.8 44.8 3.3 155.0 49.5 2.8 75.7 24.2 2.5
YCUL0050EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
152.8 36.5 3.6 146.3 40.3 3.2 139.4 44.5 2.8 132.1 49.3 2.4 124.4 54.4 2.1 116.2 60.1 1.8
3.0
157.9 36.7 3.7 151.2 40.5 3.3 144.1 44.8 2.9 136.6 49.5 2.5 128.7 54.7 2.1 120.4 60.4 1.8
4.0
163.2 37.0 3.8 156.2 40.7 3.4 148.9 45.0 2.9 141.2 49.8 2.6 133.1 55.0 2.2 92.5 41.7 2.0
5.0
168.5 37.2 3.9 161.4 41.0 3.5 153.8 45.3 3.0 145.9 50.0 2.6 137.6 55.3 2.3 95.7 41.9 2.0
6.0
174.0 37.4 4.0 166.6 41.2 3.6 158.8 45.5 3.1 150.7 50.3 2.7 142.2 55.6 2.3 98.9 42.1 2.1
7.0
179.6 37.7 4.2 172.0 41.5 3.7 163.9 45.8 3.2 155.6 50.6 2.8 146.8 55.9 2.4 71.8 27.3 2.2
8.0
185.3 38.0 4.3 177.4 41.7 3.8 169.2 46.0 3.3 160.5 50.9 2.8 151.6 56.2 2.5 74.2 27.4 2.3
9.0
191.2 38.2 4.4 183.0 42.0 3.8 174.5 46.3 3.4 165.6 51.1 2.9 156.4 56.5 2.5 76.7 27.5 2.3
10.0
197.1 38.5 4.5 188.7 42.3 3.9 179.9 46.6 3.5 170.8 51.4 3.0 161.4 56.8 2.6 79.2 27.5 2.4
11.0
203.2 38.8 4.6 194.5 42.6 4.0 185.4 46.9 3.5 176.1 51.7 3.1 166.4 57.1 2.7 81.8 27.6 2.5
12.0
209.4 39.1 4.7 200.4 42.9 4.1 191.1 47.2 3.6 181.5 52.0 3.2 171.5 57.4 2.7 84.4 27.7 2.5
YCUL0056EC
AIR TEMPERATURE ON - CONDENSER (°C)
LCWT
(°C)
25°C 30°C 35°C 40°C 45°C 50°C
KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP KWo KWi COP
2.0
168.5 41.0 3.6 161.5 45.1 3.2 153.9 49.7 2.8 145.7 54.9 2.4 136.9 60.6 2.1 127.3 66.8 1.8
3.0
174.1 41.3 3.7 166.8 45.4 3.3 159.0 50.0 2.9 150.7 55.2 2.5 141.6 60.9 2.1 132.0 67.2 1.8
4.0
179.9 41.6 3.8 172.3 45.7 3.4 164.3 50.3 2.9 155.7 55.5 2.6 146.5 61.3 2.2 136.6 67.6 1.9
5.0
185.8 41.9 3.9 177.9 46.0 3.5 169.7 50.6 3.0 160.8 55.8 2.6 151.4 61.6 2.3 74.2 30.0 2.1
6.0
191.8 42.2 4.0 183.7 46.3 3.5 175.1 50.9 3.1 166.1 56.1 2.7 156.4 62.0 2.3 76.8 30.1 2.2
7.0
197.9 42.5 4.1 189.5 46.6 3.6 180.7 51.2 3.2 171.4 56.5 2.8 161.5 62.3 2.4 79.4 30.2 2.2
8.0
204.1 42.9 4.2 195.5 46.9 3.7 186.3 51.6 3.3 176.8 56.8 2.8 166.7 62.7 2.4 82.1 30.3 2.3
9.0
210.5 43.2 4.3 201.5 47.2 3.8 192.1 51.9 3.3 182.3 57.2 2.9 172.0 63.1 2.5 84.8 30.4 2.4
10.0
217.0 43.6 4.4 207.7 47.6 3.9 198.0 52.2 3.4 188.0 57.5 3.0 177.4 63.4 2.6 87.6 30.5 2.4
11.0
223.6 43.9 4.5 214.0 47.9 4.0 204.0 52.6 3.5 193.7 57.9 3.1 182.9 63.8 2.6 90.4 30.6 2.5
12.0
230.3 44.3 4.6 220.4 48.3 4.1 210.2 52.9 3.6 199.5 58.2 3.1 188.4 64.2 2.7 93.4 30.6 2.6
