FORM 201.18-W1
9
YORK INTERNATIONAL
LEGEND
ACR-LINE ACROSS THE LINE START
C.B. CIRCUIT BREAKER
D.E. DUAL ELEMENT FUSE
DISC SW DISCONNECT SWITCH
FACT MOUNT CB FACTORY-MOUNTED CIRCUIT BREAKER
FLA FULL LOAD AMPS
HZ HERTZ
MAX MAXIMUM
MCA MINIMUM CIRCUIT AMPACITY
MIN MINIMUM
MIN NF MINIMUM NON-FUSED
RLA RUNNING LOAD AMPS
S.P. WIRE SINGLE-POINT WIRING
UNIT MTD SERV SW UNIT-MOUNTED SERVICE (NON-FUSED DISCONNECT SWITCH)
WYE-DELTA WYE-DELTA START
X-LRA ACROSS-THE-LINE INRUSH LOCKED ROTOR AMPS
Y-LRA WYE-DELTA INRUSH LOCKED ROTOR AMPS
VOLTAGE CODE
-17 = 200-3-60
-28 = 230-3-60
-40 = 380-3-60
-46 = 460-3-60
-58 = 575-3-60
CONTROL MIN MAX DUAL NON-FUSED
UNIT
POWER CIRCUIT ELEMENT DISC. SW.
VOLTAGE
SUPPLY AMPACITY FUSE SIZE SIZE
Standard
Models w/o 115-1-60 20A 20A 30A
Transformers
CONTROL POWER SUPPLY
OPTIONAL SINGLE POINT POWER SUPPLY CONNECTION WITH FIELD SUPPLIED CIRCUIT PROTECTION
(One Field Provided Power Supply Circuit to the chiller. Field Connection to Power Terminal Block or Disconnect Switch in the Option Panel.
No internal Branch Circuit Protection per Motor Control Center.)
FIELD SUPPLIED WIRING SYSTEM #1 SYSTEM #2
MODEL
VOLTS
FIELD PROVIDED POWER SUPPLY FACTORY PROVIDED (LUGS) WIRE RANGE COMPRESSOR FANS COMPRESSOR FANS
YCAS
MCA
1
MIN NF D.E. FUSE TERMINAL BLOCK NF SERV DISC SW DATA DATA DATA DATA
DISC SW
2
MIN
3
MAX
4
(LUGS) WIRE RANGE
7
RATING
2
(LUGS) WIRE RANGE
7
RLA X-LRA FLA (EA) RLA X-LRA FLA (EA)
0130EC
460 273 400 300 400 # 1 - 500 400 (2) 3/0-250 107 579 4.0 107 579 4.0
575 217 250 250 350 # 1 - 500 250 # 6 AWG - 350 86 463.2 3.1 86 463 3.1
0140EC
460 293 400 350 450 (2) # 2 - 300 400 (2) 3/0-250 116 579 4.0 116 579 4.0
575 234 250 300 350 # 1 - 500 250 # 6 AWG - 350 93 463.2 3.1 93 463 3.1
0150EC
460 307 400 350 450 (2) # 2 - 300 400 (2) 3/0-250 128 856 4.0 115 579 4.0
575 246 400 300 350 # 1 - 500 250 # 6 AWG - 350 103 715 3.1 92 463 3.1
0160EC
460 320 400 400 450 (2) # 2 - 300 400 (2) 3/0-250 128 856 4.0 128 856 4.0
575 257 400 300 400 # 1 - 500 400 (2) 3/0-250 103 715 3.1 103 715 3.1
0170EC
460 335 400 400 500 (2) # 2 - 300 400 (2) 3/0-250 140 856 4.0 128 856 4.0
575 268 400 300 400 # 1 - 500 400 (2) 3/0-250 112 715 3.1 103 715 3.1
0180EC
460 347 400 400 500 (2) # 2 - 300 400 (2) 3/0-250 140 856 4.0 140 856 4.0
575 277 400 350 400 (2) # 2 - 300 400 (2) 3/0-250 112 715 3.1 112 715 3.1
0200EC
460 375 400 450 600 (2) # 1 - 500 400 (2) 3/0-250 149 856 4.0 149 856 4.0
575 299 400 350 450 (2) # 2 - 300 400 (2) 3/0-250 119 715 3.1 119 715 3.1
0210EC
460 393 600 450 600 (2) # 1 - 500 400 (2) 3/0-250 163 856 4.0 149 856 4.0
575 313 400 350 450 (2) # 2 - 300 400 (2) 3/0-250 130 715 3.1 119 715 3.1
0230EC
460 407 600 450 600 (2) # 1 - 500 630 (3) 2/0-400 163 856 4.0 163 856 4.0
575 324 400 400 500 (2) # 2 - 300 400 (2) 3/0-250 130 715 3.1 130 715 3.1
