YORK INTERNATIONAL
8
OPTIONAL SINGLE POINT POWER SUPPLY CONNECTION TO FACTORY CIRCUIT BREAKER
(One Field Provided Power Supply Circuit to the chiller. Field Connection to Circuit Breaker in Option Panel.
No internal Branch Circuit Protection per Motor Control Center.)
FIELD SUPPLIED WIRING SYSTEM #1 SYSTEM #2
MODEL
VOLTS
MCA
1
FACTORY SUPPLIED BREAKER COMPRESSOR FANS COMPRESSOR FANS
YCAS
RATING
2
WIRE RANGE
7
(LUGS) RLA X-LRA FLA (EA) RLA X-LRA FLA (EA)
0130EC
460 273 400 (2) 3/0-250 107 579 4.0 107 579 4.0
575 217 250 # 6 AWG - 350 86 463 3.1 86 463 3.1
0140EC
460 293 400 (2) 3/0-250 116 579 4.0 116 579 4.0
575 234 400 (2) 3/0-250 93 463 3.1 93 463 3.1
0150EC
460 307 400 (2) 3/0-250 128 856 4.0 115 579 4.0
575 246 400 (2) 3/0-250 103 715 3.1 92 463 3.1
0160EC
460 320 400 (2) 3/0-250 128 856 4.0 128 856 4.0
575 257 400 (2) 3/0-250 103 715 3.1 103 715 3.1
0170EC
460 335 400 (2) 3/0-250 140 856 4.0 128 856 4.0
575 268 400 (2) 3/0-250 112 715 3.1 103 715 3.1
0180EC
460 347 400 (2) 3/0-250 140 856 4.0 140 856 4.0
575 277 400 (2) 3/0-250 112 715 3.1 112 715 3.1
0200EC
460 375 630 (3) 2/0-400 149 856 4.0 149 856 4.0
575 299 400 (2) 3/0-250 119 715 3.1 119 715 3.1
0210EC
460 393 630 (3) 2/0-400 163 856 4.0 149 856 4.0
575 313 400 (2) 3/0-250 130 715 3.1 119 715 3.1
0230EC
460 407 630 (3) 2/0-400 163 856 4.0 163 856 4.0
575 324 400 (2) 3/0-250 130 715 3.1 130 715 3.1
NOTES (pages 2 - 7)
1. Minimum circuit ampacity (MCA) is based on 125% of the rated load amps for the largest motor plus 100% of the rated load amps for all
other loads included in the circuit, per N.E.C. Article 430-24. If a Factory Mounted Control Transformer is provided, add the following to
the system #2 MCA values in the YCAS Tables: -17, add 10 amps; -28, add 9 amps; -40, add 5 amps; -46, add 4 amps; -58, add 3 amps.
2. The recommendation disconnect switch is based on a minimum of 115% of the summation rated load amps of all the loads included in the
circuit, per N.E.C. 440 - 12A1.
3. Minimum fuse size is based on 150% of the largest motor RLA plus 100% of the remaining RLAs (U.L. Standard 1995, Section 36.1).
Minimum fuse rating = (1.5 x largest compressor RLA) + other compressor RLAs + (# fans x each fan motor FLA).
4. Maximum dual element fuse size is based on 225% maximum plus 100% of the rated load amps for all other loads included in the circuit,
per N.E.C. 440-22. Maximum fuse rating = (2.25 x largest compressor RLA) + other compressor RLAs + (# fans x each fan motor FLA).
5. Minimum circuit breaker is 150% maximum plus 100% of rated load amps included in the circuit, per circuit per U.L. 1995 Fig. 36.2.
Minimum circuit breaker rating = (1.5 x largest compressor RLA) + other compressor RLAs + (# fans x each fan motor FLA).
6. Maximum circuit breaker is based on 225% maximum plus 100% of the rated load amps for all loads included in the circuit, per circuit, per
U.L. 1995 Fig. 36.2. Maximum circuit breaker rating = (2.25 x largest compressor RLA) + other compressor RLAs + ( # fans x each fan
motor FLA).
7. The Incoming Wire Range is the minimum and maximum wire size that can be accommodated by unit wiring lugs. The (1), (2), or (3)
indicate the number of termination points or lugs which are available per phase. Actual wire size and number of wires per phase must be
determined based on ampacity and job requirements using N.E.C. wire sizing information. The above recommendations are based on the
National Electric Code and using copper connectors only. Field wiring must also comply with local codes.
8. A ground lug is provided for each compressor system to accommodate field grounding conductor per N.E.C. Article 250-54. A control
circuit grounding lug is also supplied. Incoming ground wire range is #6 - 350 MCM.
9. The field supplied disconnect is a Disconnecting Means as defined in N.E.C. 100.B, and is intended for isolating the unit from the
available power supply to perform maintenance and troubleshooting. This disconnect is not intended to be a Load Break Device.
10. Units equipped with Star-Delta compressor motor start must also include Factory provided circuit breakers in each motor control center.
11. The wiring recommendations are based on the National Electrical Code using copper connectors only. Field wiring must also comply with
local codes.
NOTE: Wye-Delta Compressor Start not available with this option.
ELECTRICAL DATA (Continued)
