YORK INTERNATIONAL
4
ELECTRICAL DATA
MULTIPLE POINT POWER SUPPLY CONNECTION
(Each of Two Field Provided Power Supply Circuits individually protected with Branch Circuit Protection.
Field Connections to Factory provided Terminal Block (Std), Disconnects (Opt), or Breakers(Opt) in each of the two Motor Control Centers.)
SYSTEM #1 FIELD-SUPPLIED WIRING
MODEL
VOLTS MIN NF
D.E. FUSE C.B. FACTORY PROVIDED (LUGS) WIRE RANGE
7
COMPRESSOR FANS
YCAS MCA
1
DISC SW
2
MIN.
3
MAX.
4
MIN.
5
MAX.
6
STD. TERMINAL OPT. NF SVC.
OPT. C.B. RLA Y-LRA X-LRA FLA (EA)
BLOCK DISC SW.
200 340 400 450 600 450 600 (2) # 2 - 300 (2) 3/0-250 (3) 2/0-400 246 444 1332 8.2
230 299 400 400 600 400 600 (2) # 2 - 300 (2) 3/0-250 (2) 3/0-250 214 386 1158 7.8
0130EC 380 181 200 225 350 225 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 130 234 701 4.8
460 150 150 200 300 200 300 # 2 - 4/0 # 6 AWG - 350 # 6 AWG - 350 107 193 579 4.0
575 119 150 150 225 150 225 # 2 - 4/0 # 6 AWG - 350 # 6 AWG - 350 86 154 463 3.1
200 366 400 450 700 450 700 (2) # 2 - 300 (2) 3/0-250 (3) 2/0-400 267 444 1332 8.2
230 321 400 400 600 400 600 (2) # 2 - 300 (2) 3/0-250 (2) 3/0-250 232 386 1158 7.8
0140EC 380 195 200 250 350 250 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 140 234 701 4.8
460 161 200 200 300 200 300 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 116 193 579 4.0
575 128 150 175 225 175 225 # 2 - 4/0 # 6 AWG - 350 # 6 AWG - 350 93 154 463 3.1
200 402 400 500 700 500 700 (2) # 1 - 500 (2) 3/0-250 (3) 2/0-400 295 656 1969 8.2
230 351 400 450 700 450 700 (2) # 2 - 300 (2) 3/0-250 (3) 2/0-400 256 571 1712 7.8
0150EC 380 213 250 300 400 300 400 # 1 - 500 # 6 AWG - 350 (2) 3/0-250 155 360 1081 4.8
460 176 200 225 350 225 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 128 285 856 4.0
575 141 150 175 250 175 250 # 2 - 4/0 # 6 AWG - 350 # 6 AWG - 350 103 238 715 3.1
200 402 400 500 700 500 700 (2) # 1 - 500 (2) 3/0-250 (3) 2/0-400 295 656 1969 8.2
230 351 400 450 700 450 700 (2) # 2 - 300 (2) 3/0-250 (3) 2/0-400 256 571 1712 7.8
0160EC 380 213 250 300 400 300 400 # 1 - 500 # 6 AWG - 350 (2) 3/0-250 155 360 1081 4.8
460 176 200 225 350 225 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 128 285 856 4.0
575 141 150 175 250 175 250 # 2 - 4/0 # 6 AWG - 350 # 6 AWG - 350 103 238 715 3.1
200 434 600 600 800 600 800 (2) # 1 - 500 (3) 2/0-400 (3) 2/0-400 321 656 1969 8.2
230 380 400 450 700 450 700 (2) # 1 - 500 (2) 3/0-250 (3) 2/0-400 279 571 1712 7.8
0170EC 380 230 250 300 400 300 400 # 1 - 500 # 6 AWG - 350 (2) 3/0-250 169 360 1081 4.8
460 191 200 250 350 250 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 140 285 856 4.0
575 152 150 200 300 200 300 # 2 - 4/0 # 6 AWG - 350 # 6 AWG - 350 112 238 715 3.1
200 434 600 600 800 600 800 (2) # 1 - 500 (3) 2/0-400 (3) 2/0-400 321 656 1969 8.2
230 380 400 450 700 450 700 (2) # 1 - 500 (2) 3/0-250 (3) 2/0-400 279 571 1712 7.8
0180EC 380 230 250 300 400 300 400 # 1 - 500 # 6 AWG - 350 (2) 3/0-250 169 360 1081 4.8
460 191 200 250 350 250 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 140 285 856 4.0
575 152 150 200 300 200 300 # 2 - 4/0 # 6 AWG - 350 # 6 AWG - 350 112 238 715 3.1
200 469 600 600 1000 600 1000 (2) # 1 - 500 (3) 2/0-400 (3) 2/0-400 342 656 1969 8.2
230 412 400 500 800 500 800 (2) # 1 - 500 (2) 3/0-250 (3) 2/0-400 298 571 1712 7.8
0200EC 380 250 250 300 450 300 450 # 1 - 500 # 6 AWG - 350 (2) 3/0-250 181 360 1081 4.8
460 206 200 250 400 250 400 # 1 - 500 # 6 AWG - 350 # 6 AWG - 350 149 285 856 4.0
575 164 200 200 300 200 300 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 119 238 715 3.1
200 509 600 700 1000 700 1000 (2) # 1 - 500 (3) 2/0-400 (3) 2/0-400 374 656 1969 8.2
230 445 600 600 800 600 800 (2) # 1 - 500 (3) 2/0-400 (3) 2/0-400 325 571 1712 7.8
0210EC 380 270 400 350 500 350 500 # 1 - 500 (2) 3/0-250 (2) 3/0-250 197 360 1081 4.8
460 224 250 300 400 300 400 # 1 - 500 # 6 AWG - 350 (2) 3/0-250 163 285 856 4.0
575 178 200 225 350 225 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 130 238 715 3.1
200 509 600 700 1000 700 1000 (2) # 1 - 500 (3) 2/0-400 (3) 2/0-400 374 656 1969 8.2
230 445 600 600 800 600 800 (2) # 1 - 500 (3) 2/0-400 (3) 2/0-400 325 571 1712 7.8
0230EC 380 270 400 350 500 350 500 # 1 - 500 (2) 3/0-250 (2) 3/0-250 197 360 1081 4.8
460 224 250 300 400 300 400 # 1 - 500 # 6 AWG - 350 (2) 3/0-250 163 285 856 4.0
575 178 200 225 350 225 350 # 2 - 300 # 6 AWG - 350 # 6 AWG - 350 130 238 715 3.1
See page 6 for notes.
