246819-BTG-H-0208
Unitary Products Group 29
Multipliers for determining the performance with other indoor sections.
* = Single-phase outdoor units only.
* = Single-phase outdoor units only.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO EABD-F042S, EABD-(T,W)042S**
EVAPORATOR COIL MODEL NO FC/MC/PC/UC48
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
1200 1400 1600
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 51.7 3.1 4.3 52.6 3.0 4.4 53.4 2.9 4.5
70 49.6 3.2 3.9 50.4 3.2 4.0 51.3 3.1 4.1
80 47.4 3.4 3.6 48.3 3.3 3.7 49.2 3.3 3.8
47
60 40.4 2.8 3.6 42.2 2.7 3.8 44.0 2.7 4.0
70 39.7 3.0 3.4 42.0 2.9 3.6 42.5 2.8 3.6
80 39.1 3.1 3.2 40.1 3.1 3.3 41.1 3.0 3.4
40
60 38.4 2.7 3.6 39.1 2.6 3.7 39.8 2.6 3.7
70 35.7 2.8 3.3 36.9 2.7 3.3 38.1 2.7 3.4
80 33.1 2.9 2.9 34.8 2.9 3.0 36.5 2.9 3.1
30
60 33.5 2.5 3.3 33.4 2.5 3.3 33.3 2.4 3.3
70 31.0 2.6 3.0 31.7 2.6 3.0 32.3 2.5 3.0
80 28.6 2.7 2.7 30.0 2.7 2.8 31.3 2.7 2.8
17
60 27.1 2.3 2.9 27.4 2.3 2.9 27.7 2.3 2.9
70 25.2 2.4 2.6 25.0 2.4 2.6 26.4 2.4 2.6
80 23.3 2.5 2.4 24.1 2.5 2.4 25.0 2.4 2.4
10
60 24.1 2.2 2.7 24.3 2.2 2.7 24.6 2.1 2.6
70 22.6 2.3 2.5 22.9 2.2 2.4 23.2 2.2 2.4
80 21.2 2.3 2.2 21.5 2.3 2.2 21.9 2.3 2.2
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
** For three-phase, decrease T.C. by 1.0 and S.C. by 0.7.
Air Handler Coil
T.C. S.C. KW
MA14D FC/MC48D 1.00 1.00 1.00
MA16C FC/MC48C 1.00 1.00 1.00
AHP/SHP48 – 1.00 1.02 1.02
MV16C* FC/MC48C 0.99 0.97 0.96
MV20D* FC/MC48D 0.99 0.97 0.96
AV/SV48* – 0.99 0.97 0.96
– HD48 0.99 1.00 0.99
Variable Speed
Furnace *
Coil
T.C. S.C. KW
(F,L)L8VC20 FC/MC/PC48C 0.99 0.98 0.97
FL9(C,V)C16 FC/MC/PC48C 0.99 0.98 0.97
FL9(C,V)C20 FC/MC/PC48C 0.98 0.96 0.94
FL9(C,V)D20 FC/MC/PC48D 0.98 0.95 0.93
(F,L)L8VC20 HD48 0.99 0.97 0.96
FL9(C,V)C16 HD48 0.99 0.98 0.97
FL9(C,V)C20 HD48 0.99 0.98 0.97
