Multipliers for determining the performance with other indoor sections.
* = Single-phase outdoor units only.
* = Single-phase outdoor units only.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO EABD-F030S, EABD-(T,W)030S**
EVAPORATOR COIL MODEL NO FC/MC/PC35
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
800 1000 1200
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 33.3 2.4 4.1 32.4 1.2 8.1 31.6 2.9 3.1
70 32.2 2.4 3.9 31.9 1.8 5.9 31.5 2.7 3.5
80 31.1 2.5 3.6 31.3 2.5 3.7 31.4 2.4 3.8
47
60 29.2 2.1 4.1 28.8 2.1 4.1 28.4 2.0 4.1
70 28.0 2.2 3.8 27.9 1.6 5.6 27.8 2.1 3.9
80 26.7 2.2 3.5 27.0 1.1 7.1 27.3 2.2 3.7
40
60 25.9 2.0 3.8 26.1 1.9 3.9 26.2 1.9 4.0
70 24.6 2.1 3.5 25.0 2.0 3.6 25.5 2.0 3.8
80 23.2 2.1 3.2 24.0 2.1 3.4 24.8 2.1 3.5
30
60 22.9 1.9 3.6 22.8 1.8 3.7 22.7 1.8 3.7
70 21.2 1.9 3.3 21.5 1.9 3.3 21.8 1.9 3.4
80 19.6 2.0 2.9 20.3 2.0 3.0 20.9 1.9 3.2
17
60 17.1 1.7 2.9 17.2 1.7 2.9 17.4 1.7 3.0
70 15.1 1.8 2.5 15.6 1.8 2.6 16.1 1.8 2.7
80 13.2 1.9 2.0 14.0 1.9 2.2 14.7 1.9 2.3
10
60 14.9 1.7 2.5 14.9 1.7 2.6 14.9 1.7 2.6
70 12.9 1.8 2.1 13.2 1.8 2.2 13.4 1.8 2.2
80 10.9 1.8 1.8 11.4 1.8 1.8 11.9 1.8 1.9
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
** For three-phase, decrease T.C. by 1.0 and S.C. by 0.7.
Air Handler Coil
T.C. S.C. KW
MA12B FC/MC35B 1.00 1.00 1.00
MA12B FC/MC42B 1.00 1.00 1.00
AHP30 – 0.99 1.00 1.00
F*FP040 – 1.00 1.00 1.00
MV12B* FC/MC35B 1.01 0.95 0.93
MV16C* FC/MC35C 1.01 0.94 0.91
MV12B* FC/MC42B 1.01 0.95 0.93
MV16C* FC/MC42C 1.01 0.94 0.91
AV36* – 1.01 0.95 0.93
– FC/MC/PC/UC42 1.00 1.00 1.00
– HC36 1.00 1.00 1.00
– HD36 1.00 1.00 1.00
Variable Speed
Furnace *
Coil
T.C. S.C. KW
(F,L)L8VB16 FC/MC/PC35B 0.99 0.95 0.93
FL9(C,V)B12 FC/MC/PC35B 0.99 0.97 0.96
(F,L)L8VC16 FC/MC/PC35C 0.99 0.95 0.92
FL9(C,V)C16 FC/MC/PC35C 0.99 0.96 0.94
(F,L)L8VB16 FC/MC/PC42B 0.99 0.95 0.93
FL9(C,V)B12 FC/MC/PC42B 0.99 0.97 0.96
(F,L)L8VC16 FC/MC/PC42C 0.99 0.95 0.92
FL9(C,V)C16 FC/MC/PC42C 0.99 0.96 0.94
(F,L)L8VB16 HC36 0.99 0.95 0.90
FL9(C,V)B12 HC36 0.99 0.94 0.92
(F,L)L8VB16 HD36 0.99 0.94 0.92
FL9(C,V)B12 HD36 0.99 0.96 0.94
