26 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO EABD-F024S
EVAPORATOR COIL MODEL NO FC/MC/PC/UC24
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
600 800 1000
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 26.5 2.1 3.7 21.7 0.7 8.8 25.5 1.9 3.9
70 25.6 2.1 3.5 20.7 1.1 6.3 25.4 2.0 3.7
80 24.6 2.2 3.3 19.7 1.6 3.7 25.2 2.1 3.5
47
60 23.4 1.8 3.7 18.4 1.3 4.1 22.4 1.7 3.8
70 22.3 1.9 3.5 17.3 1.0 5.6 22.3 1.8 3.6
80 21.1 1.9 3.2 16.3 0.7 7.0 22.2 1.9 3.5
40
60 20.4 1.7 3.5 16.4 1.2 3.9 20.7 1.6 3.7
70 19.3 1.8 3.2 15.3 1.3 3.5 20.4 1.7 3.5
80 18.2 1.8 2.9 14.1 1.3 3.1 20.2 1.8 3.4
30
60 18.8 1.6 3.4 13.8 1.2 3.4 19.0 1.5 3.6
70 16.9 1.6 3.0 12.7 1.2 3.1 17.8 1.6 3.3
80 15.0 1.7 2.6 11.7 1.2 2.8 16.6 1.6 3.0
17
60 13.3 1.5 2.6 10.0 1.1 2.6 15.3 1.4 3.1
70 11.4 1.5 2.2 9.0 1.1 2.3 13.0 1.5 2.6
80 9.5 1.6 1.8 8.0 1.2 2.0 10.8 1.5 2.0
10
60 12.0 1.5 2.4 8.9 1.1 2.3 11.8 1.4 2.5
70 9.6 1.5 1.9 8.0 1.1 2.1 10.0 1.5 2.0
80 7.2 1.6 1.4 7.0 1.2 1.8 8.2 1.5 1.6
NOTE:
ALL CAPACITIES ARE NET WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
MBH KW COP
MA08B FC/MC24B 1.00 1.00 1.00
MA08B FC/MC30B 1.00 1.00 1.00
AHP24 – 1.00 1.00 1.00
F*FP030 – 1.00 1.00 1.00
MV12B FC/MC24B 0.97 0.93 0.90
MV12B FC/MC30B 0.97 0.93 0.90
AV24 – 0.97 0.93 0.90
– FC/MC/PC/UC30 1.00 1.00 1.00
– HC30 1.00 1.01 1.01
– HD24 1.00 1.00 1.00
Variable Speed
Furnace
Coil
MBH KW COP
(F,L)L8VA12 FC/MC/PC24A 0.97 0.96 0.93
FL9VA12 FC/MC/PC24A 0.97 0.96 0.93
FL9(C,V)B12 FC/MC/PC24B 0.97 0.96 0.93
(F,L)L8VA12 FC/MC/PC30A 0.97 0.96 0.93
FL9VA12 FC/MC/PC30A 0.97 0.96 0.93
FL9(C,V)B12 FC/MC/PC30B 0.97 0.96 0.93
(F,L)L8VA12 HC30 1.00 1.01 1.01
FL9VA12 HC30 1.00 1.01 1.01
(F,L)L8VA12 HD30 0.97 0.96 0.93
FL9VA12 HD30 0.97 0.96 0.93
