360101-XTG-B-0508
Johnson Controls Unitary Products 9
ALL SENSIBLE CAPACITIES
TABLE 6: COOLING CAPACITIES - 4 TON (DEB048)
TEMPERATURE
OF AIR ON
OUTDOOR COIL
AIR ON INDOOR COIL
1200 CFM 1400 CFM 1600 CFM 1800 CFM 2000 CFM
WB °F WB °F WB °F WB °F WB °F
72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57 72 67 62 57
85 °F
Net Cap
MBH
49.2 46.1 41.6 41.3 50.6 47.4 42.9 42.5 52.1 48.8 44.1 43.7 52.8 49.4 44.7 44.2 53.4 50.1 45.2 44.8
Total Power
Input kW
4.47 4.44 4.35 4.33 4.59 4.57 4.47 4.45 4.72 4.69 4.59 4.57 4.78 4.76 4.66 4.63 4.85 4.83 4.72 4.70
Sensible Capacity
MBH
1
1. These are net capacity ratings. The indoor blower motor heat has already been subtracted from the gross cooling capacity
Entering Dry
Bulb °F
86 28.3 35.7 41.3 41.3 31.5 39.6 42.7 42.5 34.7 43.5 44.1 43.7 37.1 46.3 44.7 44.2 39.5 49.1 45.2 44.8
83 24.9 32.3 37.8 39.5 27.4 35.6 41.0 41.6 30.0 38.9
44.1 43.7 31.8 41.0 44.7 44.2 33.5 43.2 45.2 44.8
80 21.4 28.9 34.4 36.1 23.4 31.6 37.6 39.4 25.4 34.2 40.7 42.7 26.5 35.7 42.5 43.8 27.6 37.2 44.3
44.8
77 18.0 25.5 31.0 32.7 19.4 27.5 33.5 35.4 20.7 29.5 36.1 38.1 21.2 30.4 37.2 38.5 21.6 31.2 38.3 38.9
74 14.6 22.1 27.6 29.3 15.3 23.5 29.5 31.3 16.0 24.9 31.4 33.4 15.8 25.1 31.9 33.1 15.7 25.3 32.4 32.9
71 - 18.6 24.2 25.8 - 19.4 25.4 27.3 - 20.2 26.7 28.7 - 19.8 26.6 27.8 - 19.3 26.4 26.9
68 - 15.2 20.7 22.4 - 15.4 21.4 23.2 - 15.5 22.1 24.1 - 14.4 21.3 22.5 - 13.4 20.4 21.0
95 °F
Net Cap
MBH
47.2 43.4 39.3 38.8 48.6 44.7 40.5 40.0 50.0 46.0 41.7 41.1 48.9 45.0 40.8 40.2 47.8 44.0 39.9 39.3
Total Power
Input kW
4.88 4.85 4.74 4.74 5.00 4.97 4.86 4.86 5.13 5.09 4.98 4.98 5.23 5.20 5.09 5.08 5.34 5.31 5.19 5.19
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 27.7 34.7 39.3 38.8 30.6 38.3 40.5 40.0 33.6 41.9 41.7 41.1 35.3 42.9 40.8 40.2 37.0 44.0 39.9 39.3.
83 24.2 31.3 36.5 37.9 26.6 34.2 39.1 39.5 28.9 37.2
41.7 41.1 30.0 38.3 40.8 40.2 31.0 39.5 39.9 39.3
80 20.8 27.9 33.0 34.5 22.5 30.2 35.8 37.4 24.3 32.5 38.5 40.2 24.7 33.0 39.1 39.8 25.0 33.5 39.7
39.3
77 17.4 24.5 29.6 31.1 18.5 26.2 31.7 33.3 19.6 27.9 33.9 35.6 19.3 27.7 33.8 34.5 19.1 27.6 33.8 33.3
74 14.0 21.0 26.2 27.7 14.5 22.1 27.7 29.3 14.9 23.2 29.2 30.9 14.0 22.4 28.5 29.1 13.1 21.6 27.8 27.4
71 - 17.6 22.8 24.2 - 18.1 23.7 25.2 - 18.5 24.5 26.2 - 17.1 23.2 23.8 - 15.7 21.9 21.4
68 - 14.2 19.4 20.8 - 14.0 19.6 21.2 - 13.9 19.9 21.6 - 11.8 17.9 18.5 - 9.7 15.9 15.5
105 °F
Net Cap
MBH
45.5 40.1 37.8 37.4 46.1 40.6 38.3 37.9 46.7 41.1 38.8 38.3 46.3 40.8 38.5 38.0 46.0 40.4 38.2 37.7
Total Power
Input kW
5.37 5.30 5.21 5.21 5.49 5.43 5.34 5.33 5.62 5.55 5.46 5.45 5.72 5.66 5.56 5.55 5.83 5.76 5.66 5.65
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 27.0 33.2 37.8 37.4 29.6 36.1 38.3 37.9 32.3 39.1 38.8 38.3 34.3 39.7 38.5 38.0 36.4 40.4 38.2 37.7
83 23.6 29.8 35.7 36.3 25.6 32.2 37.3 37.3 37.6 34.7
38.8 38.3 29.0 36.3 38.5 38.0 30.4 38.0 38.2 37.7
80 20.1 26.4 32.3 32.9 21.5 28.2 34.6 35.2 22.9 30.0 36.8 37.5 23.7 31.0 37.5 37.6 24.5 32.0 38.1
37.7
77 16.7 22.9 28.9 29.5 17.5 24.2 30.5 31.2 18.3 25.4 32.1 32.8 18.4 25.7 32.1 32.3 18.5 26.0 32.1 31.8
74 13.3 19.5 25.5 26.1 13.5 20.1 26.5 27.1 13.6 20.7 27.5 28.2 13.1 20.4 26.8 27.0 12.5 20.1 26.2 25.8
71 - 16.1 22.0 22.7 - 16.1 22.4 23.1 - 16.0 22.8 23.5 - 15.1 21.5 21.7 - 14.1 20.2 19.8
68 - 12.7 18.6 19.2 - 12.0 18.4 19.0 - 11.6 18.1 18.8 - 9.8 16.2 16.4 - 8.1 14.3 13.9
115 °F
Net Cap
MBH
43.9 36.7 36.3 36.0 43.6 36.5 36.1 35.8 43.3 36.3 35.8 35.5 43.7 36.6 36.2 35.8 44.1 36.9 36.5 36.2
Total Power
Input kW
5.86 5.76 5.69 5.67 5.98 5.88 5.81 5.80 6.11 6.01 5.94 5.92 6.22 6.11 6.04 6.02 6.32 6.21 6.14 6.12
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 26.3 31.7 36.3 36.0 28.6 34.0 36.1 35.8 30.9 36.3 35.8 35.5 33.4 36.6 36.2 35.8 35.8 36.9 36.5 36.2
83 22.9 28.3 35.0 34.8 24.6 30.2 35.4 35.1 26.3 32.2
35.8 35.5 28.1 34.3 36.2 35.8 29.8 36.4 36.5 36.2
80 19.5 24.8 31.6 31.3 20.5 26.2 33.3 33.1 21.6 27.6 35.1 34.8 22.7 29.0 35.8 35.5 23.9 30.5
36.5 36.2
77 16.1 21.4 28.2 27.9 16.5 22.2 29.3 29.0 17.0 22.9 30.4 30.1 17.4 23.7 30.4 30.2 17.9 24.5 30.5 30.2
74 12.6 18.0 24.7 24.5 12.5 18.1 25.2 25.0 12.3 18.2 25.7 25.4 12.1 18.4 25.1 24.8 12.0 18.5 24.5 24.2
71 - 14.6 21.3 21.1 - 14.1 21.2 20.9 - 13.6 21.1 20.8 - 13.1 19.8 19.5 - 12.6 18.6 18.3
68 - 11.1 17.9 17.6 - 10.0 17.1 16.9 - 8.9 16.4 16.1 - 7.8 14.5 14.2 - 6.6 12.6 12.3
125 °F
Net Cap
MBH
42.2 33.4 34.8 34.6 41.1 32.4 33.8 33.7 40.0 31.4 32.9 32.7 41.1 32.4 33.8 33.7 42.2 33.4 34.8 34.6
Total Power
Input kW
6.3 6.2 6.2 6.1 6.5 6.3 6.3 6.3 6.6 6.5 6.4 6.4 6.7 6.6 6.5 6.5 6.8 6.7 6.6 6.6
Sensible Capacity
MBH
1
Entering Dry
Bulb °F
86 25.6 30.1 34.8 34.6 27.6 31.8 33.8 33.7 29.6 31.4 32.9 32.7 32.4 32.4 33.8 33.7 35.2 33.4 34.8 34.6
83 22.2 26.7 34.3 33.2 23.6 28.2 33.6 32.9 25.0 29.8
32.9 32.7 27.1 32.3 33.8 33.7 29.3 33.4 34.8 34.6
80 18.8 23.3 30.8 29.8 19.5 24.2 32.1 30.9 20.3 25.1
32.9 32.1 21.8 27.0 33.8 33.3 23.3 28.9 34.8 34.6
77 15.4 19.9 27.4 26.3 15.5 20.2 28.0 26.9 15.6 20.4 28.6 27.4 16.5 21.7 28.8 28.0 17.3 22.9 28.9 28.6
74 12.0 16.5 24.0 22.9 11.5 16.1 24.0 22.8 11.0 15.8 24.0 22.7 11.2 16.4 23.4 22.7 11.4 17.0 22.9 22.7
71 - 13.0 20.6 19.5 - 12.1 19.9 18.8 - 11.1 19.3 18.1 - 11.1 18.1 17.4 - 11.0 17.0 16.7
68 - 9.6 17.2 16.1 - 8.0 15.9 14.7 - 6.4 14.6 13.4 - 5.7 12.8 12.1 - 5.1 11.0 10.7
