360101-XTG-B-0508
Johnson Controls Unitary Products 13
* = KW listed is for 240 volts, use table on previous page for 208 or 230 volts.
** = KW listed is for 480 volts, use table on previous page for 460 volts.
*** = KW listed is for 600 volts, use table on previous page for 575 volts.
042 208/230-3-60 11.5 88.0 1.1 3.5
2NH04501025 1 7.5/10.0* 20.8/24.1 30.4/34.4 35/35 35/35
2NH04501525 1 11.3/15.0* 31.3/36.1 43.5/49.5 45/50 45/50
048 208/230-3-60 14.1 105.0 0.7 4.0
2NP04501025 1 7.5/10.0* 20.8/24.1 31.1/35/1 35/40 35/40
2NP04501525 1 11.3/15.0* 31.3/36.1 44.1/50.1 45/60 45/60
2NP04502025 2 15.0/20.0* 41.7/48.1 57.1/65.1 60/70 60/70
2NH04502525 2 18.8/25.0* 52.1/60.1 70.2/80.2 80/90 80/90
060 208/230-3-60 16.0 125.0 1.3 7.0
2NH04501025 1 7.5/10.0* 20.8/24.1 34.8/38.8 40/40 40/40
2NH04501525 1 11.3/15.0* 31.3/36.1 47.8/53.9 50/60 50/60
2NH04502025 2 15.0/20.0* 41.7/48.1 60.9/68.9 70/70 70/70
2NH04502525 2 18.8/25.0* 52.1/60.1 73.9/83.9 80/90 80/90
036 460-3-60 5.8 40.0 0.6 1.8
2NH04501046 1 10.0** 12 17.3 20 20
2NH04501546 1 15.0** 18 24.8 25 25
042 460-3-60 5.8 42.0 0.6 1.8
2NH04501046 1 10.0** 12 17.3 20 20
2NH04501546 1 15.0** 18 24.8 25 25
048 460-3-60 7.1 55.0 0.8 2.0
2NP04501046 1 10.0** 12 17.5 20 20
2NH04501546 1 15.0** 18 25.1 30 30
2NH04502046 2 20.0** 24.1 32.6 35 35
2NH04502546 2 25.0** 30.1 40.1 45 45
060 460-3-60 8.0 67.0 0.7 3.5
2NH04501046 1 10.0** 12 19.4 20 20
2NH04501546 1 15.0** 18 26.9 30 30
2NP04502046 2 20.0** 24.1 34.4 35 35
2NP04502546 2 25.0** 30.1 42 45 45
036 575-3-60 4.5 32.0 0.4 1.5
2NH04501058 1 10.0*** 9.6 13.9 15 15
2NH04501558 1 15.0*** 14.4 19.9 20 20
042 575-3-60 5.8 44.0 0.4 1.5
2NH04501058 1 10.0*** 9.6 13.9 15 15
2NH04501558 1 15.0*** 14.4 19.9 20 20
048 575-3-60 5.6 44.0 0.6 1.6
2NH04501058 1 10.0*** 9.6 14 15 15
2NH04501558 1 15.0*** 14.4 20 25 25
2NH04502058 2 20.0*** 19.2 26.1 30 30
2NH04502558 2 25.0*** 24.1 32.1 35 35
060 575-3-60 6.4 50.0 0.6 2.8
2NH04501058 1 10.0*** 9.6 15.5 20 20
2NH04501558 1 15.0*** 14.4 21.5 25 25
2NP04502058 2 20.0*** 19.2 27.6 30 30
2NP04502558 2 25.0*** 24.1 33.6 35 35
1. Dual element, time delay type.
2. Standard circuit breakers may be used in Canada and on applications over 60 amps where the heaters are separately fused.
TABLE 11: ELECTRICAL DATA (COOLING / ELECTRIC HEAT) (CONTINUED)
MODEL
DEB
POWER
SUPPLY
COMPRESSOR
COND. FAN
MOTORS
SUPPLY
AIR
BLOWER
MOTOR
ELECTRIC HEAT ACCESSORY
MCA
(AMPS)
MAX FUSE/
SIZE
1
(AMPS)
MAX HACR
2
BREAKER SIZE
RLA LRA FLA FLA MODEL NO. STAGE KW TOTAL AMPS
