255027-YTG-B-0507
20 Unitary Products Group
TABLE 13: SUPPLY AIR BLOWER PERFORMANCE (BP060 BELT DRIVE) - BOTTOM DUCT APPLICATION
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
1
0.2 0.3 0.4 0.5 0.6 0.7
RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP
1000 - - - - - - - - - - - - 862 453 0.49 901 498 0.53
1100 - - - - - - - - - - - - 883 494 0.53 922 539 0.58
1200 - - - - - - - - - 866 489 0.53 904 536 0.58 943 581 0.62
1300 - - - - - - 850 488 0.52 889 535 0.57 928 581 0.62 967 627 0.67
1400 - - - 836 491 0.53 875 537 0.58 913 584 0.63 952 631 0.68 991 676 0.73
1500 - - - 862 545 0.58 901 591 0.63 940 638 0.68 978 685 0.73 1017 730 0.78
1600 851 559 0.60 890 604 0.65 928 650 0.70 967 697 0.75 1006 744 0.80 1045 789 0.85
1700 880 624 0.67 919 668 0.72 958 714 0.77 996 761 0.82 1035 808 0.87 1074 853 0.92
1800 911 694 0.74 949 738 0.79 988 785 0.84 1027 832 0.89 1066 878 0.94 1105 923 0.99
1900 942 770 0.83 981 814 0.87 1020 860 0.92 1059 907 0.97 1097 954 1.02 1136 999 1.07
2000 976 851 0.91 1014 895 0.96 1053 941 1.01 1092 989 1.06 1130 1035 1.11 1169 1080 1.16
2100 1010 938 1.01 1049 982 1.05 1087 1028 1.10 1126 1075 1.15 1165 1122 1.20 1204 1167 1.25
2200 1046 1030 1.11 1084 1075 1.15 1123 1121 1.20 1162 1168 1.25 1200 1215 1.30 - - -
2300 1082 1128 1.21 1121 1172 1.26 1160 1219 1.31 1198 1266 1.36 - - - - - -
2400 1120 1231 1.32 1159 1276 1.37 1198 1322 1.42 - - - - - - - - -
2500 1159 1340 1.44 1198 1384 1.48 - - - - - - - - - - - -
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
1
0.8 0.9 1.0 1.1 1.2 1.3
RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP
1000 940 541 0.58 980 579 0.62 1019 613 0.66 1059 641 0.69 1099 662 0.71 1140 674 0.72
1100 961 582 0.62 1000 621 0.67 1040 654 0.70 1080 682 0.73 1120 703 0.75 1161 715 0.77
1200 983 624 0.67 1022 663 0.71 1062 697 0.75 1101 725 0.78 1142 745 0.80 1182 758 0.81
1300 1006 669 0.72 1045 708 0.76 1085 742 0.80 1125 770 0.83 1165 791 0.85 - - -
1400 1030 718 0.77 1070 757 0.81 1109 791 0.85 1149 819 0.88 1190 840 0.90 - - -
1500 1057 772 0.83 1096 811 0.87 1136 845 0.91 1176 873 0.94 - - - - - -
1600 1084 831 0.89 1124 870 0.93 1163 904 0.97 1203 932 1.00 - - - - - -
1700 1113 896 0.96 1153 935 1.00 1192 969 1.04 - - - - - - - - -
1800 1144 966 1.04 1183 1005 1.08 - - - - - - - - - - - -
1900 1175 1042 1.12 - - - - - - - - - - - - - - -
2000 1209 1123 1.20 - - - - - - - - - - - - - - -
2100 - - - - - - - - - - - - - - - - - -
2200 - - - - - - - - - - - - - - - - - -
2300 - - - - - - - - - - - - - - - - - -
2400 - - - - - - - - - - - - - - - - - -
2500 - - - - - - - - - - - - - - - - - -
1. Blower performance includes 1” filters. See STATIC RESISTANCE table for additional applications.
Factory Installed AK56 blower sheave and A36 belt.
