TABLE 9: SUPPLY AIR BLOWER PERFORMANCE (BP036 BELT DRIVE) - BOTTOM DUCT APPLICATION
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
1
0.2 0.3 0.4 0.5 0.6
RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP
800 - - - - - - - - - 749 384 0.41 791 422 0.45
900 - - - - - - 720 364 0.39 764 404 0.43 806 443 0.47
1000 - - - 690 346 0.37 739 388 0.42 783 429 0.46 824 467 0.50
1100 657 334 0.36 711 376 0.40 760 417 0.45 804 458 0.49 845 497 0.53
1200 681 369 0.40 735 410 0.44 784 452 0.49 828 493 0.53 869 532 0.57
1300 707 409 0.44 761 451 0.48 809 493 0.53 854 534 0.57
895 572 0.61
1400 735 456 0.49 789 498 0.53 837 540 0.58 882 581 0.62
923 619 0.66
1500 765 509 0.55 819 550 0.59 867 592 0.64
911 633 0.68 953 672 0.72
1600 796 567 0.61 850 609 0.65
899 651 0.70 943 692 0.74 984 730 0.78
1700 829 631 0.68 883 673 0.72
932 715 0.77 976 756 0.81 1017 794 0.85
1800 863 701 0.75
918 743 0.80 966 785 0.84 1010 826 0.89 1051 864 0.93
1900
899 776 0.83 953 818 0.88 1001 860 0.92 1045 901 0.97 1087 939 1.01
2000
936 857 0.92 990 899 0.96 1038 941 1.01 1082 981 1.05 - - -
AIR
FLOW
CFM
AVAILABLE EXTERNAL STATIC PRESSURE - IWG
1
0.7 0.8 0.9 1.0 1.1
RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP RPM WATTS BHP
800 831 456 0.49
871 486 0.52 914 509 0.55 961 525 0.56 1012 532 0.57
900 846 477 0.51
886 507 0.54 929 530 0.57 976 546 0.59 1027 553 0.59
1000
864 502 0.54 905 531 0.57 947 555 0.60 994 571 0.61 1046 578 0.62
1100
885 531 0.57 926 561 0.60 969 584 0.63 1015 600 0.64 1067 607 0.65
1200
909 566 0.61 950 596 0.64 992 619 0.66 1039 635 0.68 1091 642 0.69
1300
935 607 0.65 976 636 0.68 1018 660 0.71 1065 676 0.72 - - -
1400
963 654 0.70 1004 683 0.73 1046 707 0.76 1093 722 0.77 - - -
1500
993 706 0.76 1033 736 0.79 1076 759 0.81 - - - - - -
1600
1024 765 0.82 1065 794 0.85 1108 818 0.88 - - - - - -
1700
1057 829 0.89 1098 859 0.92 - - - - - - - - -
1800
1091 899 0.96 - - - - - - - - - - - -
1900 - - - - - - - - - - - - - - -
2000 - - - - - - - - - - - - - - -
1. Blower performance includes 1” filters. See STATIC RESISTANCE table for additional applications.
Factory Installed AK74 blower sheave and A39 belt.
AK61 blower sheave and A36 belt - Field installation required.
