GV100W BOILER
INSTALLATION & OPERATING INSTRUCTIONS
AVERTISSMENT. Assurez-vous de bien suivre les instructions données dans cette
notice pour réduire au minimum le risque d’incendie ou d’explosion ou pour éviter
tout dommoge matériel, toute blessure ou la mort
Ne pas entreposer ni utiliser d’essence ou ni d’autres vapeurs ou liquides inflammables
à proximité de cet appareil ou de tout autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d’allumer d’appareil.
• Ne touchez à aucun interrupteur; ne pas vous servir des téléphones se trouvant dans
le bâtiment.
• Appelez immédiatement votre fournisseur de gas depuis un voisin. Suivez les
intructions du fournisseur.
• Si vous ne purvez rejoindre le fournisseur, appelez le service des incendies.
L’installation et l’entretien doivent être assurés par un installateur ou un service
d’entretien qualifié ou par le fournisseur de gaz.
Table of Contents
Before You Start .................................................. 2
Boiler Ratings & Capacities................................. 3
Boiler Location .................................................... 3
Combustible Floor Option.................................... 4
Dimensions & Component Location .................... 5
Combustion Air.................................................... 6
Common Vent Systems ....................................... 6
Chimney & Vent Pipe Connection ....................... 7
Heating System Piping ........................................ 9
Gas Supply Piping............................................. 12
Electrical Wiring ................................................ 13
Lighting Instructions .......................................... 17
Boiler Operation ................................................ 19
Checking & Adjusting ........................................ 20
Boiler Maintenance ........................................... 21
Instructions to the Installer ................................ 22
Replacement Parts............................................ 23
Health Warnings ................................................ 24
BEFORE YOU START
WARNING : This manual must be read and fully
understood before installing, operating or servicing
this boiler! Failure to follow these instructions could
result in a fire or explosion causing extensive
property damage, personal injury or death!
These instructions cover the GV100W gas fired, induced draft
low pressure, sectional, cast iron hot water boiler. GV100W
boilers have been design certified by CSA for use with natural
and propane gas under the latest edition of ANSI-Z21.13, Gas-
Fired Low-Pressure Steam and Hot Water Boilers and CGA
4.9, Gas-Fired Steam and Hot Water Boilers.
Each unit has been constructed and hydrostatically tested for
a maximum working pressure of 50 psi,
345 kPa
in accor-
dance with the A.S.M.E. Boiler and Pressure Vessel
Code, Section IV for cast iron boilers. Each boiler has been
equipped with a 30 psi pressure relief valve.
This manual covers the application, installation, operation and
maintenance of a GV100W low pressure hot water boiler.
To obtain the safe, dependable, efficient operation and long life
for which this boiler was designed, these instructions must be
read, understood and followed.
Direct all questions to your Smith Cast Iron Boiler distributor
or write to the Customer Service Department, 260 North Elm
Street, Westfield, MA 01085. Always include the model and
serial numbers from the rating plate of the boiler in question.
