6
Diagram shows
minimum
clearances from
combustible
materials
of the control system and any gas control
which has been under water.
17 Adequate clearances for accessibility for
purposes of servicing and proper
operation should be provided.
18 Adequate clearances around air
openings into the combustion chamber
should be provided.
19 Do not install in areas where curtains,
drapes, clothing, or other moving
flammables are within 15 inches of this
unit.
24 The draft hood on the appliance should
be installed in the same atmospheric
pressure zone as the combustion air inlet
to the appliance and shall be located so
that the relief opening is accessible for
checking vent operation.
25 The appliance, when installed, must be
electrically grounded in accordance with
local codes or, in the absence of local
codes, with the National Electrical
Code, ANSI/NFPA 70, or the Canadian
Electrical Code, CSA C22.1
26 A gas appliance must not be connected
to a chimney flue serving a solid fuel
burning appliance.
27 Do not restrict the warm air discharge
by placing articles in front of heater.
28 This appliance must not be used for any
purpose other than heating.
29 Do not allow anyone to post articles
through the louvres.
30 Do not allow anyone to sit or lean
against the appliance.
31 DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
32 CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF
HIGH SURFACE TEMPERATURES
AND SHOULD STAY AWAY TO AVOID
BURNS OR CLOTHING IGNITION.
33 CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
34 INSTALLATION AND REPAIR SHOULD
BE DONE BY A QUALIFIED SERVICE
PERSON. THE APPLIANCE SHOULD
BE INSPECTED BEFORE USE AND
AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING BEDDING
MATERIAL, ET CETERA. IT IS
IMPERATIVE THAT CONTROL
20 Periodic examination of the venting
system is required.
21 The flow of combustion and ventilation
air should not be obstructed.
22 A manufactured home (USA only) or
mobile home OEM installation must
conform with the Manufactured Home
Construction and Safety Standard, Title
24CFR, Part 3280, or, when such a
standard is not applicable, the Standard
for Manufactured Home Installations,
ANSI/NCSBCS A225.1 or Standard for
Gas Equipped Recreational Vehicles
and Mobile Housing, CSA Z240.4.
23 The appliance and its appliance main
gas valve must be disconnected from the
gas supply piping system during any
pressure testing of that system at test
pressures in excess of 1/2 psi (3.5 kPa).
The appliance must be isolated from the
gas supply piping system by closing its
equipment shutoff valve during any
pressure testing of the gas supply piping
system at pressures equal to or less than
½ psi (3.5 kPa).
15”
ABOVE
15”
RIGHT
15”
LEFT
15”
FRONT
