SPARE PARTS LIST
REF. No. DESCRIPTION PART No. Pcs/Set
MC-E761
REMARKS
1 HOSE UNIT AMC8A92T1034 1 • ✓
2 HOSE AMC8A01K0034 1 • ✓
3 HOSE CONNECTING TUBE AMC8A0281034 1 • ✓
4 CURVED TUBE UNIT AMC8A94P1034 1 • ✓
5 HOSE HOLDER AMC8A1125034 2 • ✓
6 CREVICE NOZZLE AMC8A13P1034 1 • ✓
7 EXTENSION WAND (METALLIC) AMC8A12P1000 2 • ✓
8 TELESCOPIC WAND AMC8A85P3100 1 • ✓ Optional
9 FLOOR NOZZLE AMC8A99T4034 1 • ✓
10 DUST COVER AMC8T01T40Z2 1 • ✓
11 DUST INDICATOR AMC8I99T1000 1 • ✓
12 VALVE AMC8I07A1000 1 • ✓
13 VALVE SPRING AMC8I09T1000 1 • ✓
14 VALVE SUPPORT AMC8I22E1061 1 • ✓
15 INDICATOR COVER AMC8I17T1164 1 • ✓
16 TAPPING SCREW XTN4+18B 1 • ✓
17 UPPER BODY AMC8C01T50Z2 1 • ✓
18 TAPPING SCREW XTN4+18B 4 • ✓
19 POTENTIOMETER BUTTON AMC8E17T1039 1 • ✓
20 BRAKE LEVER UNIT AMC8P96T1000 1 • ✓
21 BRAKE SPRING AMC8F30L1000 1 • ✓
22 SWITCH PEDAL AMC8T14T1039 1 • ✓
23 CORD REEL PEDAL AMC8T13T1039 1 • ✓
24 SPRING AMC8P2201000 2 • ✓
25 CLEAN AIR FILTER AMC8F28T1000 1 • ✓
26 EXHAUST COVER AMC8T07T40Z2 1 • ✓
27 LOWER BODY UNIT AMC8C99T0039 1 • ✓
28 CASTER AMC8R99V10G0 1 • ✓
29 WHEEL AMC8R01T1039 2 • ✓
30 DUST COVER SEAL AMC8T04T1034 1 • ✓
31 SUCTION PACKING AMC8T12T1000 1 • ✓
32 FRONT COVER AMC8T11T10Z2 1 • ✓
33 TAPPING SCREW XTN4+18B 2 • ✓
34 CENTRAL FILTER AMC8F03D1100 1 • ✓
35 PAPER BAG CLAMP AMC8F02E1164 1 • ✓
36 PAPER BAG CLAMP SPRING AMC8F30E1000 1 • ✓
37 MOTOR SDS-1504P 2 AMC81SF04P02 1 • ✓
38 CARBON BRUSH AMC8210C9801 2 • ✓
39 FRONT MOTOR SUPPORT AMC8E08T1000 1 • ✓
40 REAR MOTOR SUPPORT AMC8E09T0000 1 • ✓
41 MOTOR COVER AMC8E10T4000 1 • ✓
42 THERMAL CUT-OUT AMC8E14L1000 1 • ✓
43 POWER CONTROL CIRCUIT AMC8E91T4100 1 • ✓
44 SLIDING POTENTIOMTER AMC8E1693000 1 • ✓
45 ON/OFF SWITCH AMC8E01P1000 1 • ✓
46 REAR SUPPRESOR AMC8T09T4000 1 • ✓
47 CORD REEL UNIT AMC8PZ3P6000 1 • Applied to Australia and N.Zealand
48 CORD REEL UNIT AMC8PZ1P6000 1 • Applied to UK and Ireland
49 CORD REEL UNIT AMC8P88P6000 1 • Applied to Switzerland
Applied for
all countries (✓)
