DUAL FUNCTIONALITY
Your vacuum cleaner can easily be configured
into two different cleaning modes:
• Upright vacuum A for floors and carpets.
• Lift Away canister
˜
B which can be carried
with you whilst cleaning hard to reach places.
You can carry your vacuum cleaner in both
modes by the carry handle
„
located on top
of the dust canister
Ê
.
UPRIGHT VACUUMING
Assembly
1 Place the motorised
floor brush nozzle
on a level surface and
align the floor brush
nozzle tube
Ó
with
the tube on the Lift
Away canister
˜
and
lower until you hear
the two pieces click
into place C1 .
NOTE: The motorised
floor brush nozzle
must be fully locked
in place to ensure the
electrical connection
is made.
2 Attach the end of the
extension tube
·
to
the tube on the back
of the Lift Away
canister
˜
until it
clicks in to place C2 .
3 Slide the accessory
holder
fi
in to
position opposite the
upper cord wrap, over
the extension tube
·
.
Align the tab and
groove and push
down C3 .
4 Store the dusting brush
ı
and the crevice tool
Û
/
Ù
on the mounts of the accessory holder
C4.
5 Push the handle ⁄ onto the top of the
extension tube · until you hear it click into
place C5.
6 Insert the end of the stretch hose ¤ into the
connector on the back of the Lift Away canister
C6.
Using in upright mode
1 Rotate the
upper cord wrap fl
to quickly
release the power cord.
2 Secure the power cord in the cord hook
‡
D .
3 Press the On/Off
3-position
switch
‰
to the
“I” position to vacuum hard floors (suction only)
or to the “II” position to engage the motorised
floor brush nozzle
(for vacuuming carpets
and rugs) E.
4 NOTE: The rotating brush bar
Ú
on the
motorised floor brush nozzle
will not spin
unless the nozzle is flat against the floor and
the handle ⁄ is tilted back.
Gently press the motorised floor brush nozzle
down with your foot while you grasp the
handle ⁄ and tilt it back towards you F.
