Using Your Duo
™
Steam Sweeper & Floor Sanitizer
5) Place the Steam Sweeper & Floor Sanitizer on
the black Floor Protector Resting Mat (be sure the
‘bumpy’ side is facing up). DO NOT attach the
Ultra-Microfiber Pad at this time. Unscrew the
cap on the water tank (Fig 4).
6) Using the provided fill cup, pour no more than
one fill cup of water (as indicated by the fill line
on the cup) into the tank. Do not overfill. There
is a TAN bar that cuts across the opening just inside
the water tank to show the correct water level.
Keep the water level below this bar. Replace the
cap when finished (Fig 5).
7) Plug the Steam Sweeper and Floor Sanitizer into
a standard 120-volt grounded wall receptacle.
8) Press the GREY STEAM power button to turn on
the STEAM function. The STEAM power indicator
light, on top of the unit, will illuminate RED.
Your Steam Sweeper & Floor Sanitizer is heated
and ready to use when the Thermal Indicator on
the tank cap changes from BLACK to ORANGE (Fig 6).
9) Place an Ultra-Microfiber Pad on the floor with
the WHITE ‘hook & loop’ side facing up. Lightly
press the Steam Sweeper and Floor Sanitizer onto
the pad, making sure the Ultra-Microfiber Pad is
positioned to the bottom of the tray correctly.
Position the pad towards the back of the base
of the unit so as not to cover the Power-Lift
™
Brush (Fig 7a & b). The specially-designed bottom
of the tray will grip the pad.
DO NOT attach the pad crossways to the bottom
of the unit or in any way that will interfere with
the Sweeper Brush (Fig 8).
10) Push and pull the Duo™ slowly across the floor to
thoroughly steam clean each section.
I
IMPORTANT: Never use your HAAN
®
Duo
™
on hard
surfaces without the Ultra-Microber Pad attached to
the tray. Always remove the pad from your Steam
Sweeper and Floor Sanitizer once you have nished
using the unit. Keep the Duo
™
on the Floor Protector
Resting Mat when not in use.
Operating Instructions:
Fig 4
Fig 5
Fig 7
b
a
Fig 6
Water Level Bar
Power Light
STEAM
Button
Yes
Remove
cap
Correct Pad
Placement
Steam Jets
Sweeper
Brush Clear
Fig 8
WRONG Pad
Placement
Sweeper
Brush
Covered
NO!
Thermal
Indicator
www.HAANUSA.com 877-HAAN DIRECT / 877-422-6347 pg 9
