produCt SpeCifiCationS
produCt SpeCifiCationS
6 www.goodmanmfg.com SS-DSZC18
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1406
MBh 34.5 35.8 39.2 - 33.7 34.9 38.3 - 32.9 34.1 37.4 - 32.1 33.3 36.5 - 30.5 31.6 34.6 - 28.3 29.3 32.1 -
S/T 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -
∆T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
kW 2.10 2.14 2.21 - 2.26 2.31 2.39 - 2.41 2.47 2.55 - 2.54 2.60 2.69 - 2.65 2.71 2.81 - 2.75 2.81 2.91 -
Amps 7.8 8.0 8.2 - 8.4 8.6 8.9 - 9.2 9.4 9.7 - 9.8 10.1 10.4 - 10.5 10.7 11.1 - 11.1 11.4 11.8 -
Hi PR 219 235 249 - 245 264 279 - 279 300 317 - 318 342 361 - 358 385 406 - 395 425 449 -
Lo PR 107 114 124 - 113 120 131 - 117 125 136 - 123 131 143 - 129 137 150 - 134 142 155 -
1250
MBh 33.5 34.7 38.1 - 32.7 33.9 37.2 - 32.0 33.1 36.3 - 31.2 32.3 35.4 - 29.6 30.7 33.6 - 27.4 28.4 31.2 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
kW 2.08 2.13 2.19 - 2.25 2.30 2.37 - 2.39 2.45 2.53 - 2.52 2.58 2.67 - 2.63 2.69 2.78 - 2.73 2.79 2.88 -
Amps 7.7 7.9 8.1 - 8.3 8.5 8.8 - 9.1 9.3 9.6 - 9.7 10.0 10.3 - 10.4 10.6 11.0 - 11.0 11.3 11.7 -
Hi PR 217 233 246 - 243 261 276 - 276 297 314 - 315 339 358 - 354 381 402 - 391 421 445 -
Lo PR 106 113 123 - 112 119 130 - 116 124 135 - 122 130 142 - 128 136 149 - 132 141 154 -
1094
MBh 30.9 32.1 35.1 - 30.2 31.3 34.3 - 29.5 30.6 33.5
- 28.8 29.8 32.7 - 27.3 28.3 31.0 - 25.3 26.2 28.8 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
kW 2.03 2.07 2.14 - 2.19 2.24 2.31 - 2.33 2.38 2.46 - 2.46 2.51 2.60 - 2.56 2.62 2.71 - 2.66 2.72 2.81 -
Amps 7.5 7.7 7.9 - 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.4 9.7 10.0 - 10.1 10.3 10.7 - 10.7 10.9 11.3 -
Hi PR 210 226 239 - 236 254 268 - 268 288 305 - 305 329 347 - 343 370 390 - 379 408 431 -
Lo PR 103 109 119 - 108 115 126 - 113 120 131 - 118 126 138 - 124 132 144 - 128 137 149 -
75
1406
MBh 35.1 36.1 39.1 42.0 34.3 35.3 38.2 41.0 33.5 34.5 37.3 40.0 32.7 33.6 36.4 39.1 31.0 31.9 34.6 37.1 28.7 29.6 32.0 34.4
S/T 0.86 0.77 0.58 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.89 0.67 0.43
∆T 20 18 15 10 20 18 15 10 20 18 15 10 20 19 15 11 20 18 15 10 19 17 14 10
kW 2.11 2.16 2.23 2.31 2.28 2.33 2.41 2.49 2.43 2.49 2.57 2.66 2.56 2.62 2.71 2.81 2.68 2.74 2.83 2.93 2.77 2.84 2.94 3.04
Amps 7.8 8.0 8.3 8.6 8.5 8.7 9.0 9.3 9.2 9.5 9.8 10.2 9.9 10.2 10.5 10.9 10.6 10.8 11.2 11.6 11.2 11.5 11.9 12.3
Hi PR 221 238 251 262 248 267 282 294 282 303 320 334 321 346 365 381 361 389 411 428 399 430 454 473
Lo PR 108 115 125 134 114 121 133 141 119 126 138 147 125 133 145 154 131 139 152 161 135 144 157 167
1250
MBh 34.1 35.1 38.0 40.8 33.3 34.3 37.1 39.8 32.5 33.5 36.2 38.9 31.7 32.6 35.3 37.9 30.1 31.0 33.6 36.0 27.9 28.7 31.1 33.4
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41
∆T 21 19 16 11 21 19 16
11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
kW 2.10 2.14 2.21 2.29 2.26 2.32 2.39 2.47 2.41 2.47 2.55 2.64 2.54 2.60 2.69 2.78 2.65 2.72 2.81 2.91 2.75 2.81 2.91 3.01
Amps 7.8
8.0 8.2 8.5 8.4 8.6 8.9 9.3 9.2 9.4 9.7 10.1 9.8 10.1 10.4 10.8 10.5 10.7 11.1 11.5 11.1 11.4 11.8 12.2
Hi PR 219 235 249 259 245 264 279 291 279 300 317 331 318 342 361 377 358 385 406 424 395 425 449 468
Lo PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 153 129 138 150 160 134 142 155 165
1094
MBh 31.5 32.4 35.1 37.6 30.7 31.6 34.2 36.8 30.0 30.9 33.4 35.9 29.3 30.1 32.6 35.0 27.8 28.6 31.0 33.3 25.8 26.5 28.7 30.8
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40
∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
kW 2.04 2.09 2.16 2.23 2.21 2.26 2.33 2.41 2.35 2.40 2.48 2.57 2.48 2.53 2.62 2.71 2.59 2.64 2.73 2.83 2.68 2.74 2.83 2.93
Amps 7.5 7.7 8.0 8.3 8.2 8.4 8.7 9.0 8.9 9.1 9.4 9.8 9.5 9.8 10.1 10.5 10.2 10.4 10.8 11.2 10.8 11.1 11.4 11.9
Hi PR 212 228 241 251 238 256 271 282 271 291 308 321 308 332 350 366 347 373 394 411 383 413 436 454
Lo PR 104 110 120 128 110 117 127 136 114 121 132 141 120 127 139 148 125 133 146 155 130 138 151 160
IDB: Entering Indoor Dry Bulb Temperature Shaded area is ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
expanded Cooling data — dSZC180361a*/Ca*f3743*6**+txV/mBVC1600** — HigH Stage
