Goodman Mfg SS-DSZC18 Air Conditioner User Manual


  Open as PDF
of 32

produCt SpeCifiCationS
produCt SpeCifiCationS
SS-DSZC18 www.goodmanmfg.com 15

65ºF 75ºF 85ºF 95ºF 105ºF 115ºF

  59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1969
MBh 57.3 58.6 62.6 66.9 56.0 57.2 61.1 65.3 54.6 55.8 59.6 63.8 53.3 54.5 58.2 62.2 50.6 51.7 55.3 59.1 46.9 47.9 51.2 54.7
S/T 0.90 0.84 0.69 0.51 0.93 0.88 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.75 0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59
∆T 24 23 20 16 24 23 20 16 24 23 20 16 25 24 20 16 24 23 20 16 22 22 19 15
kW 3.65 3.74 3.86 4.00 3.96 4.05 4.19 4.33 4.22 4.32 4.47 4.63 4.46 4.56 4.72 4.89 4.66 4.77 4.93 5.11 4.83 4.94 5.12 5.30
Amps 7.4 7.8 8.3 8.8 8.6 9.0 9.5 10.1 9.9 10.4 10.9 11.6 11.1 11.5 12.2 12.9 12.3 12.7 13.4 14.2 13.4 13.9 14.6 15.4
Hi PR 223 240 253 264 250 269 284 296 284 306 323 337 324 349 368 384 364 392 414 432 403 433 458 477
Lo PR 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159
1750
MBh 55.6 56.9 60.7 64.9 54.3 55.5 59.3 63.4 53.0 54.2 57.9 61.9 51.8 52.9 56.5 60.4 49.2 50.2 53.7 57.4 45.5 46.5 49.7 53.2
S/T 0.86 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.91 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.92 0.75 0.56
∆T 25 24 21 17 25 24 21 17 25 24 21 17 26 25 21 17 25 24 21 17 24 23 20 16
kW 3.62 3.71 3.83 3.96 3.92 4.01 4.15 4.29 4.19 4.28 4.43 4.59 4.42 4.52 4.68 4.85 4.62 4.73 4.89 5.06 4.79 4.90 5.07 5.25
Amps 7.3 7.7 8.1 8.7 8.5 8.8 9.4 10.0 9.8 10.2 10.8 11.4 10.9 11.4 12.0 12.7 12.1 12.6 13.2 14.0 13.2 13.7 14.4 15.2
Hi PR 221 237 251 262 248 266 281 293 282 303 320 334 321 345 364 380 361 388 410 428 399 429 453 472
Lo PR 102 108 118 126 108 114 125 133 112 119 130 138 117 125 136 145 123 131 143 152 127 135 148 157
1531
MBh 51.4 52.5 56.1 59.9 50.2 51.3 54.8 58.5 49.0 50.0 53.5
57.1 47.8 48.8 52.1 55.7 45.4 46.4 49.5 53.0 42.0 43.0 45.9 49.1
S/T 0.83 0.78 0.63 0.47 0.86 0.81 0.66 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.95 0.89 0.73 0.54
∆T 26 24 21 17 26 25 22 17 26 25 22 17 26 25 22 17 26 25 21 17 24 23 20 16
kW 3.53 3.61 3.73 3.86 3.82 3.91 4.04 4.18 4.08 4.17 4.31 4.47 4.30 4.40 4.56 4.72 4.49 4.60 4.76 4.93 4.66 4.77 4.94 5.11
Amps 6.9 7.3 7.7 8.3 8.0 8.4 8.9 9.5 9.3 9.7 10.3 10.9 10.4 10.9 11.5 12.2 11.6 12.0 12.6 13.4 12.7 13.1 13.8 14.6
Hi PR 214 230 243 254 240 258 273 285 273 294 310 324 311 335 354 369 350 377 398 415 387 416 439 458
Lo PR 99 105 115 122 104 111 121 129 108 115 126 134 114 121 132 141 119 127 139 148 123 131 143 153
85
1969
MBh 58.3 59.4 62.2 66.4 56.9 58.1 60.8 64.9 55.6 56.7 59.4 63.3 54.2 55.3 57.9 61.8 51.5 52.5 55.0 58.7 47.7 48.7 51.0 54.4
S/T 0.94 0.91 0.82 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.94 0.77
∆T 26 25 24 21 26 26 24 21 26 26 24 21 25 26 24 21 24 25 24 21 22 23 22 19
kW 3.69 3.77 3.90 4.03 3.99 4.08 4.22 4.37 4.26 4.36 4.51 4.67 4.50 4.60 4.76 4.93 4.70 4.81 4.98 5.16 4.87 4.99 5.16 5.35
Amps 7.6 7.9 8.4 9.0 8.7 9.1 9.7 10.3 10.1 10.5 11.1 11.8 11.3 11.7 12.3 13.1 12.4 12.9 13.6 14.4 13.6 14.1 14.8 15.6
Hi PR 225 242 256 267 253 272 287 299 287 309 326 340 327 352 372 388 368 396 418 436 407 438 462 482
Lo PR 104 111 121 128 110 117 127 136 114 121 132 141 120 127 139 148 126 134 146 155 130 138 151 161
1750
MBh 56.6 57.7 60.4 64.5 55.3 56.4 59.0 63.0 54.0 55.0 57.6 61.5 52.7 53.7 56.2 60.0 50.0 51.0 53.4 57.0 46.3 47.2 49.5 52.8
S/T 0.90 0.87 0.78 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.90 0.73
∆T 27 26 25 22 27 27 25 22
27 27 25 22 27 27 25 22 26 27 25 22 24 25 23 20
kW 3.65 3.74 3.86 4.00 3.96 4.05 4.19 4.33 4.22 4.32 4.47 4.63 4.46 4.56 4.72 4.89 4.66 4.77 4.93 5.11 4.83 4.94 5.12 5.30
Amps 7.4
7.8 8.3 8.8 8.6 9.0 9.5 10.1 9.9 10.4 10.9 11.6 11.1 11.5 12.2 12.9 12.3 12.7 13.4 14.2 13.4 13.9 14.6 15.4
Hi PR 223 240 253 264 250 269 284 296 284 306 323 337 324 349 368 384 364 392 414 432 403 433 458 477
Lo PR 103 109 119 127 109 116 126 134 113 120 131 140 119 126 138 147 124 132 144 154 129 137 149 159
1531
MBh 52.2 53.3 55.8 59.5 51.0 52.0 54.5 58.1 49.8 50.8 53.2 56.7 48.6 49.5 51.9 55.4 46.2 47.1 49.3 52.6 42.8 43.6 45.7 48.7
S/T 0.87 0.84 0.76 0.61 0.90 0.87 0.78 0.64 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.96 0.87 0.70
∆T 27 27 25 22 28 27 26 22 28 27 26 22 28 27 26 22 27 27 25 22 26 25 24 21
kW 3.56 3.64 3.76 3.89 3.85 3.94 4.08 4.22 4.11 4.21 4.35 4.50 4.34 4.44 4.60 4.76 4.53 4.64 4.80 4.97 4.70 4.81 4.98 5.16
Amps 7.1 7.4 7.9 8.4 8.2 8.5 9.1 9.6 9.5 9.9 10.4 11.1 10.6 11.0 11.6 12.3 11.7 12.2 12.8 13.6 12.8 13.3 14.0 14.8
Hi PR 216 233 246 256 243 261 276 287 276 297 313 327 314 338 357 372 353 380 402 419 391 420 444 463
Lo PR 100 106 116 123 105 112 122 130 110 117 127 135 115 122 134 142 121 128 140 149 125 133 145 154
IDB: Entering Indoor Dry Bulb Temperature Shaded area is AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
expanded Cooling data — dSZC180601a*/Ca*f3743*6**+txV/mBVC2000** — HigH Stage (Cont.)
