SS-DSZC18 www.goodmanmfg.com 5/11
Supersedes 4/11
up to 18 SEER
R-410A
D S Z C 18
Split SyStem Heat pump
Cooling CapaCity: 35,000 - 56,500 Btu/H
Heating CapaCity: 33,600 - 56,400 Btu/H
Standard Features
• R-410Achlorine-freerefrigerant
• Two-StageCopeland®UltraTechscrollcompressor
• High-densityfoamcompressorsoundblanket
• ComfortNet™CommunicationsSystemcompatible
• ExpandedComfortAlertdiagnosticsbuiltin
• Set-upcapablewithtwolow-voltagewiresto
outdoorunit
• Diagnosticindicatorlightsandstorageofsixfaultcodes
• Color-codedterminalstripfornon-communicatingset-up
• SmartShift™technologywithshort-cycleprotectionto
ensurequiet,reliabledefrost
• Factory-installedbi-owliquidlinelterdryer
• Factory-installedsuctionlineaccumulator
• Factory-installedcompressorcrankcaseheater
• Factory-installedhigh-capacitymuer
• Factory-installedcoilandambienttemperaturesensors
• High-andlow-pressureswitches
• Fullychargedfor15’oftubinglength
• QuietECM-stylecondenserfanmotor
• Sweatconnectionservicevalveswitheasyaccess
togaugeports
• AHRICertied;ETLListed
Cabinet Features
• Goodmanbrandsoundcontroltopdesign
• Wire
fandischargegr
ille
• Steellouvercoilguard
• Baked-on
pow
der
paintnish
• Rust
-resistantcoatedscrews
• Compact
footpr
int
• Topandsidemaintenanceaccess
• Single
panelaccesstocontrolswithspace
pro
videdforeld-installedaccessories
• When
proper
ly
anchored
,
meetsthe2001Flor
ida
Building
Codeunitintegrityrequirementsforhurricane-typewinds
(Anchorbracketkitsavailable
.)
Contents
Nomenclature...................................................................................................2
ProductSpecications................................................................................. 3
ExpandedCoolingData.............................................................................. 4
ExpandedHeatingData...........................................................................20
AHRIRatings.....................................................................................................22
Dimensions......................................................................................................30
WiringDiagram..............................................................................................31
Accessories........................................................................................................32
*Completewarrantydetailsavailablefromyourlocaldealeroratwww.goodmamfg.com.ToreceivetheLifetimeCompressorLimitedWarranty(goodforaslongasyou
ownyourhome),10-YearUnitReplacementLimitedWarrantyand10-YearPartsLimitedWarranty,onlineregistrationmustbecompletedwithin60daysofinstallation.
OnlineregistrationisnotrequiredinCaliforniaorQuébec.
