4 www.goodmanmfg.com SS-GSC13
Product SPecificationS
expAnded rAtinGS — GSC130181G*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
525
MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
∆T 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
kW 1.01 1.03 1.07 - 1.10 1.12 1.16 - 1.17 1.20 1.25 - 1.24 1.27 1.32 - 1.30 1.33 1.38 - 1.35 1.38 1.43 -
Amps 4.2 4.3 4.5 - 4.6 4.7 4.8 - 4.9 5.0 5.2 - 5.2 5.4 5.5 - 5.5 5.7 5.9 - 5.9 6.0 6.2 -
HI PR 130 140 148 - 146 157 166 - 166 179 189 - 189 203 215 - 213 229 242 - 235 253 267 -
LO PR 59 63 68 - 62 66 72 - 65 69 75 - 68 72 79 - 71 76 83 - 74 78 86 -
600
MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 16 12 - 18 15 12 -
kW 1.04 1.06 1.10 - 1.13 1.15 1.20 - 1.21 1.24 1.28 - 1.28 1.31 1.36 - 1.34 1.37 1.42 - 1.39 1.42 1.47 -
Amps 4.3 4.4 4.6 - 4.7 4.8 4.9 - 5.0 5.2 5.3 - 5.4 5.5 5.7 - 5.7 5.8 6.0 - 6.0 6.2 6.4 -
HI PR 134 144 152 - 150 162 171 - 171 184 194 - 195 210 221 - 219 236 249 - 242 261 275 -
LO PR 61 65 71 - 64 68 75 - 67 71 77 - 70 75 81 - 73 78 85 - 76 81 88 -
675
MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1
- 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.86 0.72 0.50 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
kW 1.05 1.07 1.11 - 1.14 1.17 1.21 - 1.22 1.25 1.29 - 1.29 1.32 1.37 - 1.35 1.38 1.43 - 1.40 1.44 1.49 -
Amps
4.4 4.5 4.6 - 4.7 4.8 5.0 - 5.1 5.2 5.4 - 5.4 5.5 5.7 - 5.7 5.9 6.1 - 6.1 6.2 6.4 -
HI PR 135 146 154 - 152 164 173 - 173 186 196 - 197 212 224 - 221 238 252 - 245 263 278 -
LO PR 61 65 71 - 65 69 75 - 67 72 78 - 71 75 82 - 74 79 86 - 77 82 89 -
75
525
MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.4 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
∆T 22 20 17 12 22 21 17 12 22 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11
kW 1.02 1.04 1.08 1.12 1.11 1.13 1.17 1.22 1.19 1.21 1.26 1.30 1.25 1.28 1.33 1.38 1.31 1.34 1.39 1.44 1.36 1.40 1.45 1.50
Amps 4.3 4.4 4.5 4.7 4.6 4.7 4.8 5.0 5.0 5.1 5.2 5.4 5.3 5.4 5.6 5.8 5.6 5.7 5.9 6.1 5.9 6.0 6.2 6.5
HI PR 131 141 149 156 147 159 168 175 168 180 191 199 191 206 217 226 215 231 244 255 237 255 270 281
LO PR 59 63 69 74 63 67 73 78 65 70 76 81 69 73 80 85 72 77 84 89 74 79 86 92
600
MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2 16.7 18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
∆T 22 20 16 11 22 20 17 11
22 20 17 12 22 20 17 12 22 20 17 11 20 19 15 11
kW 1.05 1.07 1.11 1.15 1.14 1.17 1.21 1.25 1.22 1.25 1.29 1.34 1.29 1.32 1.37 1.42 1.35 1.38 1.43 1.49 1.40 1.44 1.49 1.54
Amps
4.4 4.5 4.6 4.8 4.7 4.8 5.0 5.1 5.1 5.2 5.4 5.6 5.4 5.5 5.7 5.9 5.7 5.9 6.1 6.3 6.1 6.2 6.4 6.6
HI PR 135 146 154 161 152 164 173 180 173 186 196 205 197 212 224 233 222 238 252 263 245 263 278 290
LO PR 61 65 71 76 65 69 75 80 67 72 78 83 71 75 82 88 74 79 86 92 77 82 89 95
675
MBh 17.9 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.7 17.2 18.6 20.0 15.9 16.3 17.7 19.0 14.7 15.1 16.4 17.6
S/T 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.67 0.43
∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
kW 1.06 1.08 1.12 1.16 1.15 1.18 1.22 1.26 1.23 1.26 1.30 1.35 1.30 1.33 1.38 1.43 1.36 1.39 1.45 1.50 1.41 1.45 1.50 1.56
Amps 4.4 4.5 4.7 4.8 4.8 4.9 5.0 5.2 5.1 5.3 5.4 5.6 5.5 5.6 5.8 6.0 5.8 5.9 6.1 6.3 6.1 6.3 6.5 6.7
HI PR 137 147 155 162 154 165 174 182 175 188 198 207 199 214 226 236 224 241 254 265 247 266 281 293
LO PR 62 66 72 77 65 70 76 81 68 72 79 84 71 76 83 88 75 80 87 93 77 82 90 96
IDB: Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions Amps = outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and sucon service valves. kW = Total system power Design Subcooling 9 ±3 °F @ the liquid service valve, ARI 95 test condions
