18 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160601B* / CA*f4961*6A*+tXV / mBVC2000**-1** high StAge
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
2025
MBh 55.9 57.9 63.4 - 54.6 56.5 62.0 - 53.3 55.2 60.5 - 52.0 53.9 59.0 - 49.4 51.2 56.1 - 45.7 47.4 51.9 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
∆T 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 16 12 - 18 15 12 -
kW 3.57 3.65 3.77 - 3.86 3.95 4.09 - 4.12 4.22 4.36 - 4.35 4.45 4.61 - 4.55 4.65 4.82 - 4.71 4.83 4.99 -
Amps 14.1 14.4 14.9 - 15.2 15.6 16.2 - 16.6 17.0 17.6 - 17.8 18.2 18.9 - 19.0 19.4 20.1 - 20.1 20.6 21.3 -
HI PR 231 248 262 - 259 279 294 - 295 317 335 - 336 361 381 - 377 406 429 - 417 449 474 -
LO PR 104 111 121 - 110 117 128 - 114 122 133 - 120 128 140 - 126 134 146 - 130 139 151 -
1800
MBh 54.2 56.2 61.6 - 53.0 54.9 60.1 - 51.7 53.6 58.7 - 50.4 52.3 57.3 - 47.9 49.7 54.4 - 44.4 46.0 50.4 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.43 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
∆T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
kW 3.54 3.62 3.74 - 3.83 3.92 4.05 - 4.09 4.18 4.33 - 4.31 4.41 4.57 - 4.51 4.61 4.77 - 4.67 4.78 4.95 -
Amps 13.9 14.3 14.8 - 15.1 15.5 16.0 - 16.5 16.9 17.4 - 17.6 18.1 18.7 - 18.8 19.2 19.9 - 19.9 20.4 21.1 -
HI PR 229 246 260 - 256 276 291 - 292 314 331 - 332 357 377 - 374 402 425 - 413 444 469 -
LO PR 103 110 120 - 109 116 127 - 113 120 132 - 119 127 138 - 125 133 145 - 129 137 150 -
1575
MBh 50.1 51.9 56.8 - 48.9 50.7 55.5 - 47.7 49.5 54.2
- 46.6 48.3 52.9 - 44.2 45.8 50.2 - 41.0 42.5 46.5 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.66 0.45 -
∆T 20 17 13 - 20 17 13 - 20 18 13 - 20 18 13 - 20 17 13 - 19 16 12 -
kW 3.45 3.53 3.65 - 3.73 3.82 3.95 - 3.98 4.07 4.21 - 4.20 4.30 4.45 - 4.39 4.49 4.65 - 4.55 4.66 4.82 -
Amps 13.6
13.9 14.4 - 14.7 15.0 15.6 - 16.0 16.4 16.9 - 17.1 17.5 18.1 - 18.2 18.7 19.3 - 19.4 19.8 20.5 -
HI PR 222 239 252 - 249 268 283 - 283 304 321 - 322 347 366 - 363 390 412 - 401 431 455 -
LO PR 100 106 116 - 106 112 123 - 110 117 128 - 115 123 134 - 121 129 140 - 125 133 145 -
75
2025
MBh 56.80 58.48 63.30 67.94 55.48 57.12 61.83 66.36 54.16 55.76 60.36 64.78 52.84 54.40 58.89 63.20 50.20 51.68 55.94 60.04 46.50 47.87 51.82 55.62
S/T 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
∆T 22 20 16 11 22 20 17 11 22 20 17 12 22 20 17 12 22 20 17 11 20 19 15 11
kW 3.60 3.68 3.81 3.94 3.90 3.99 4.12 4.27 4.16 4.26 4.40 4.56 4.39 4.49 4.65 4.81 4.59 4.70 4.86 5.03 4.76 4.87 5.04 5.22
Amps 14.2 14.6 15.0 15.6 15.4 15.8 16.3 16.9 16.8 17.2 17.8 18.5 18.0 18.4 19.0 19.8 19.1 19.6 20.3 21.1 20.3 20.8 21.5 22.4
HI PR 233 251 265 276 262 282 297 310 298 320 338 353 339 365 385 402 381 410 433 452 421 453 479 499
LO PR 105 112 122 130 111 118 129 138 116 123 134 143 121 129 141 150 127 135 148 157 132 140 153 163
1800
MBh 55.1 56.8 61.5 66.0 53.9 55.5 60.0 64.4 52.6 54.1 58.6 62.9 51.3 52.8 57.2 61.4 48.7 50.2 54.3 58.3 45.1 46.5 50.3 54.0
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.93 0.83 0.63 0.40
∆T 23 21 17 12 23 21 17 12
23 21 17 12 23 21 17 12 23 21 17 12 21 20 16 11
kW 3.57 3.65 3.78 3.90 3.87 3.95 4.09 4.23 4.12 4.22 4.36 4.52 4.35 4.45 4.61 4.77 4.55 4.65 4.82 4.99 4.71 4.83 5.00 5.17
Amps 14.1
14.4 14.9 15.5 15.3 15.6 16.2 16.8 16.6 17.0 17.6 18.3 17.8 18.2 18.9 19.6 19.0 19.4 20.1 20.9 20.1 20.6 21.3 22.2
HI PR 231 248 262 274 259 279 294 307 295 317 335 349 336 361 381 398 378 406 429 447 417 449 474 494
LO PR 104 111 121 129 110 117 128 136 114 122 133 142 120 128 140 149 126 134 146 156 130 139 151 161
1575
MBh 50.9 52.4 56.7 60.9 49.7 51.2 55.4 59.5 48.5 50.0 54.1 58.1 47.3 48.8 52.8 56.6 45.0 46.3 50.1 53.8 41.7 42.9 46.4 49.8
S/T 0.78 0.69 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.39 0.89 0.80 0.60 0.39
∆T 23 21 17 12 23 22 18 12 23 22 18 12 24 22 18 12 23 21 18 12 22 20 16 11
kW 3.48 3.56 3.68 3.80 3.77 3.85 3.98 4.12 4.02 4.11 4.25 4.40 4.24 4.34 4.49 4.64 4.43 4.53 4.69 4.85 4.59 4.70 4.86 5.03
Amps 13.7 14.0 14.5 15.0 14.8 15.2 15.7 16.3 16.1 16.5 17.1 17.8 17.3 17.7 18.3 19.0 18.4 18.9 19.5 20.3 19.5 20.0 20.7 21.5
HI PR 224 241 254 265 251 270 286 298 286 308 325 339 326 350 370 386 366 394 416 434 405 435 460 480
LO PR 101 108 117 125 107 114 124 132 111 118 129 137 117 124 135 144 122 130 142 151 126 134 147 156
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
