SS-DSXC16 www.goodmanmfg.com 13
Product SPecificationS
eXpAnDeD Cooling DAtA — DSXC160481B* / CA*f4860*6**+tXV/mBVC2000** low StAge (Cont.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1238
MBh 35.5 36.3 38.8 41.4 34.7 35.4 37.9 40.5 33.8 34.6 37.0 39.5 33.0 33.7 36.1 38.5 31.4 32.1 34.2 36.6 29.1 29.7 31.7 33.9
S/T 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.92 0.75 0.56 1.00 0.95 0.78 0.58 1.00 1.00 0.81 0.60 1.00 1.00 0.81 0.61
∆T 24 23 20 16 25 24 21 16 25 24 21 16 25 24 21 17 23 24 20 16 22 22 19 15
kW 2.07 2.12 2.19 2.26 2.24 2.28 2.36 2.44 2.38 2.43 2.51 2.60 2.50 2.56 2.65 2.74 2.61 2.67 2.76 2.85 2.70 2.77 2.86 2.96
Amps 9.9 10.1 10.4 10.7 10.6 10.8 11.1 11.5 11.4 11.6 11.9 12.3 12.0 12.3 12.7 13.1 12.7 13.0 13.4 13.8 13.4 13.7 14.1 14.6
HI PR 220 237 250 261 247 266 281 293 281 302 319 333 320 344 364 379 360 387 409 427 398 428 452 471
LO PR 109 116 126 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 168
1100
MBh 34.5 35.2 37.6 40.2 33.7 34.4 36.8 39.3 32.9 33.6 35.9 38.4 32.1 32.8 35.0 37.4 30.5 31.1 33.3 35.5 28.2 28.8 30.8 32.9
S/T 0.88 0.83 0.67 0.50 0.92 0.86 0.70 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
∆T 25 24 21 17 26 25 21 17 26 25 21 17 26 25 22 17 25 25 21 17 24 23 20 16
kW 2.06 2.10 2.17 2.24 2.22 2.27 2.34 2.42 2.36 2.41 2.49 2.57 2.48 2.54 2.62 2.71 2.59 2.65 2.74 2.83 2.68 2.74 2.83 2.93
Amps 9.9 10.0 10.3 10.6 10.5 10.7 11.0 11.4 11.3 11.5 11.8 12.2 12.0 12.2 12.6 13.0 12.6 12.9 13.3 13.7 13.3 13.6 14.0 14.4
HI PR 218 235 248 258 245 263 278 290 278 299 316 330 317 341 360 375 356 384 405 422 394 424 447 467
LO PR 108 115 125 133 114 121 132 141 118 126 137 146 124 132 144 154 130 139 151 161 135 143 157 167
963
MBh 31.8 32.5 34.7 37.1 31.1 31.7 33.9 36.3 30.3 31.0 33.1
35.4 29.6 30.2 32.3 34.5 28.1 28.7 30.7 32.8 26.0 26.6 28.4 30.4
S/T 0.85 0.80 0.65 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.93 0.88 0.71 0.53 0.97 0.91 0.74 0.55 0.98 0.92 0.75 0.56
∆T 26 25 22 17 26 25 22 17 26 25 22 17 26 25 22 18 26 25 22 17 24 23 20 16
kW 2.01 2.05 2.11 2.18 2.16 2.21 2.28 2.36 2.30 2.35 2.43 2.51 2.42 2.48 2.56 2.64 2.52 2.58 2.67 2.76 2.61 2.67 2.76 2.86
Amps 9.6
9.8 10.1 10.4 10.3 10.5 10.8 11.1 11.0 11.2 11.6 11.9 11.7 11.9 12.3 12.7 12.3 12.6 12.9 13.4 12.9 13.2 13.6 14.1
HI PR 211 228 240 251 237 255 270 281 270 290 307 320 307 331 349 364 346 372 393 410 382 411 434 453
LO PR 105 111 121 129 110 118 128 137 115 122 133 142 121 128 140 149 126 134 147 156 131 139 152 162
85
1238
MBh 36.1 36.8 38.6 41.1 35.3 36.0 37.7 40.2 34.4 35.1 36.8 39.2 33.6 34.2 35.9 38.3 31.9 32.5 34.1 36.4 29.6 30.1 31.6 33.7
S/T 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
∆T 26 26 24 21 26 26 25 21 26 26 25 21 25 25 25 21 24 24 24 21 22 22 23 20
kW 2.09 2.13 2.20 2.28 2.25 2.30 2.38 2.46 2.40 2.45 2.53 2.62 2.53 2.58 2.67 2.76 2.63 2.69 2.78 2.88 2.73 2.79 2.88 2.98
Amps 10.0 10.2 10.5 10.8 10.7 10.9 11.2 11.6 11.5 11.7 12.0 12.4 12.1 12.4 12.8 13.2 12.8 13.1 13.5 13.9 13.5 13.8 14.2 14.7
HI PR 222 239 253 264 249 268 284 296 284 305 322 336 323 348 367 383 364 391 413 431 402 432 456 476
LO PR 110 117 128 136 116 124 135 144 121 128 140 149 127 135 147 157 133 141 154 164 137 146 160 170
1100
MBh 35.1 35.7 37.4 39.9 34.3 34.9 36.6 39.0 33.4 34.1 35.7 38.1 32.6 33.3 34.8 37.2 31.0 31.6 33.1 35.3 28.7 29.3 30.6 32.7
S/T 0.93 0.89 0.81 0.65 0.96 0.93 0.84 0.68 0.98 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.92 0.75 1.00 1.00 0.93 0.75
∆T 27 27 25 22 27 27 26 22
28 27 26 22 27 27 26 22 26 26 25 22 24 24 24 21
kW 2.07 2.12 2.19 2.26 2.24 2.28 2.36 2.44 2.38 2.43 2.51 2.60 2.50 2.56 2.65 2.74 2.61 2.67 2.76 2.85 2.70 2.77 2.86 2.96
Amps 9.9
10.1 10.4 10.7 10.6 10.8 11.1 11.5 11.4 11.6 11.9 12.3 12.0 12.3 12.7 13.1 12.7 13.0 13.4 13.8 13.4 13.7 14.1 14.6
HI PR 220 237 250 261 247 266 281 293 281 302 319 333 320 344 364 379 360 387 409 427 398 428 452 471
LO PR 109 116 126 135 115 122 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 168
963
MBh 32.4 33.0 34.6 36.9 31.6 32.2 33.8 36.0 30.9 31.5 32.9 35.1 30.1 30.7 32.1 34.3 28.6 29.2 30.5 32.6 26.5 27.0 28.3 30.2
S/T 0.89 0.86 0.78 0.63 0.93 0.89 0.81 0.65 0.95 0.92 0.83 0.67 0.98 0.95 0.85 0.69 1.00 0.98 0.89 0.72 1.00 0.99 0.89 0.72
∆T 28 27 26 22 28 27 26 22 28 28 26 23 28 28 26 23 27 27 26 22 25 26 24 21
kW 2.02 2.07 2.13 2.20 2.18 2.23 2.30 2.38 2.32 2.37 2.45 2.53 2.44 2.50 2.58 2.67 2.55 2.60 2.69 2.78 2.64 2.69 2.79 2.88
Amps 9.7 9.9 10.2 10.5 10.4 10.6 10.9 11.2 11.1 11.3 11.7 12.0 11.8 12.0 12.4 12.8 12.4 12.7 13.0 13.5 13.1 13.3 13.7 14.2
HI PR 214 230 243 253 240 258 272 284 273 293 310 323 310 334 353 368 349 376 397 414 386 415 438 457
LO PR 106 112 123 131 112 119 130 138 116 123 135 143 122 130 141 151 128 136 148 158 132 140 153 163
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
