10 www.goodmanmfg.com SS-DSXC16
Product SPecificationS
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
1356
MBh 33.9 35.1 38.5 - 33.1 34.3 37.6 - 32.3 33.5 36.7 - 31.5 32.7 35.8 - 30.0 31.1 34.0 - 27.8 28.8 31.5 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
∆T 17 14 11 - 17 14 11 - 17 14 11 - 17 15 11 - 17 14 11 - 16 13 10 -
kW 2.14 2.18 2.25 - 2.31 2.36 2.43 - 2.45 2.51 2.59 - 2.58 2.64 2.73 - 2.69 2.76 2.85 - 2.79 2.85 2.95 -
Amps 8.1 8.3 8.6 - 8.8 9.0 9.3 - 9.5 9.7 10.0 - 10.1 10.4 10.7 - 10.8 11.1 11.4 - 11.4 11.7 12.1 -
HI PR 232 249 253 - 262 282 286 - 298 321 325 - 340 365 370 - 367 394 400 - 435 467 474 -
Lo PR 116 120 131 - 119 123 135 - 124 127 139 - 127 131 143 - 129 133 146 - 133 137 149 -
1200
MBh 32.9 34.1 37.4 - 32.2 33.3 36.5 - 31.4 32.5 35.6 - 30.6 31.7 34.8 - 29.1 30.2 33.0 - 26.9 27.9 30.6 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.79 0.66 0.45 -
∆T 17 15 11 - 17 15 11 - 18 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
kW 2.12 2.17 2.24 - 2.29 2.34 2.41 - 2.43 2.49 2.57 - 2.56 2.62 2.71 - 2.67 2.73 2.82 - 2.77 2.83 2.93 -
Amps 8.0 8.2 8.5 - 8.7 8.9 9.2 - 9.4 9.6 10.0 - 10.1 10.3 10.6 - 10.7 11.0 11.3 - 11.3 11.6 12.0 -
HI PR 230 247 250 - 260 279 283 - 295 317 322 - 336 362 367 - 363 390 396 - 430 463 469 -
Lo PR 115 119 129 - 118 122 133 - 122 126 138 - 126 130 141 - 128 132 144 - 131 135 148 -
1043
MBh 30.4 31.5 34.5 - 29.7 30.8 33.7 - 29.0 30.0 32.9
- 28.3 29.3 32.1 - 26.9 27.8 30.5 - 24.9 25.8 28.2 -
S/T 0.66 0.55 0.38 - 0.68 0.57 0.40 - 0.70 0.59 0.41 - 0.72 0.61 0.42 - 0.75 0.63 0.44 - 0.76 0.63 0.44 -
∆T 18 15 12 - 18 15 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
kW 2.10 2.15 2.22 - 2.27 2.32 2.39 - 2.41 2.47 2.55 - 2.54 2.60 2.68 - 2.65 2.71 2.80 - 2.74 2.81 2.90 -
Amps 8.0
8.2 8.4 - 8.6 8.8 9.1 - 9.3 9.6 9.9 - 10.0 10.2 10.5 - 10.6 10.9 11.2 - 11.2 11.5 11.9 -
HI PR 227 244 248 - 257 276 280 - 292 314 319 - 333 358 363 - 360 387 392 - 426 458 465 -
Lo PR 114 117 128 - 117 121 132 - 121 125 136 - 124 128 140 - 127 131 143 - 130 134 146 -
75
1356
MBh 34.5 35.5 38.4 41.2 33.7 34.7 37.5 40.3 32.9 33.8 36.6 39.3 32.1 33.0 35.7 38.4 30.5 31.4 34.0 36.4 28.2 29.1 31.5 33.8
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
∆T 19 18 14 10 19 18 15 10 19 18 15 10 19 18 15 10 19 18 14 10 18 17 14 9
kW 2.14 2.18 2.25 2.33 2.31 2.36 2.43 2.51 2.45 2.51 2.59 2.68 2.58 2.64 2.73 2.82 2.69 2.76 2.85 2.95 2.79 2.85 2.95 3.05
Amps 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.6 9.5 9.7 10.0 10.4 10.1 10.4 10.7 11.1 10.8 11.1 11.4 11.9 11.4 11.7 12.1 12.6
HI PR 232 249 253 259 262 282 286 292 298 321 325 332 340 365 370 379 367 394 400 409 435 467 474 484
Lo PR 116 120 131 139 119 123 135 143 124 127 139 148 127 131 143 152 129 133 146 155 133 137 149 159
1200
MBh 33.5 34.5 37.3 40.0 32.7 33.7 36.4 39.1 31.9 32.9 35.6 38.2 31.1 32.1 34.7 37.2 29.6 30.5 33.0 35.4 27.4 28.2 30.5 32.8
S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.89 0.79 0.60 0.39 0.89 0.80 0.61 0.39
∆T 20 18 15 10 20 19 15 11
20 19 15 11 20 19 15 11 20 19 15 10 19 17 14 10
kW 2.12 2.17 2.24 2.31 2.29 2.34 2.41 2.49 2.43 2.49 2.57 2.66 2.56 2.62 2.71 2.80 2.67 2.73 2.82 2.92 2.77 2.83 2.93 3.03
Amps 8.0
8.2 8.5 8.8 8.7 8.9 9.2 9.5 9.4 9.6 10.0 10.3 10.1 10.3 10.6 11.0 10.7 11.0 11.3 11.7 11.3 11.6 12.0 12.4
HI PR 230 247 250 256 260 279 283 289 295 317 322 329 336 362 367 375 363 390 396 405 430 463 469 480
Lo PR 115 119 129 138 118 122 133 142 122 126 138 147 126 130 141 151 128 132 144 154 131 135 148 157
1043
MBh 30.9 31.8 34.4 37.0 30.2 31.1 33.6 36.1 29.5 30.3 32.8 35.2 28.7 29.6 32.0 34.4 27.3 28.1 30.4 32.7 25.3 26.0 28.2 30.3
S/T 0.75 0.67 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.86 0.77 0.58 0.38
∆T 20 19 15 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 14 10
kW 2.10 2.15 2.22 2.29 2.27 2.32 2.39 2.47 2.41 2.47 2.55 2.63 2.54 2.60 2.68 2.78 2.65 2.71 2.80 2.90 2.74 2.81 2.90 3.00
Amps 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.6 9.9 10.2 10.0 10.2 10.5 10.9 10.6 10.9 11.2 11.6 11.2 11.5 11.9 12.3
HI PR 227 244 248 253 257 276 280 286 292 314 319 326 333 358 363 371 360 387 392 401 426 458 465 475
Lo PR 114 117 128 136 117 121 132 140 121 125 136 145 124 128 140 149 127 131 143 152 130 134 146 156
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects ACCA (TVA) condions kW = Total system power
High and low pressures are measured at the liquid and sucon service valves. Amps = outdoor unit amps (comp.+fan)
eXpAnDeD Cooling DAtA — DSXC160361** / CA*f3743*6A* +tXV / mBVC1600** high StAge
