COOLING PERFORMANCE DATA
CKF36-2*
MODEL: CKF36-2* / A36-00-2 COOLING OPERATION
Outdoor Ambient Temperature
65°F 75°F 85°F 95°F 105°F 115°F 118°F 125°F
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 53 67 71 59 63 67 71
MBh 32.5 33.6 36.9 - 31.7 32.9 36.0 - 31.0 32.1 35.2 - 29.6 30.7 33.7 - 27.6 28.6 31.3 - 25.5 26.4 28.9 - 23.8 24.7 27.1 - 23.1 24.0 26.3 -
S/T 0.71 0.59 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.80 0.66 0.46 - 0.84 0.70 0.49 - 0.85 0.71 0.49 - 0.87 0.73 0.50 - 0.88 0.73 0.51 -
DT 17 15 11 - 17 15 11 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 - 15 13 10 - 15 13 10 -
1229 KW 2.67 2.73 2.83 - 2.90 2.97 3.07 - 3.10 3.18 3.29 - 3.31 3.39 3.51 - 3.46 3.54 3.67 - 3.59 3.68 3.81 - 3.64 3.73 3.86 - 3.66 3.75 3.89 -
AMPS 14.8 15.1 15.6 - 15.9 16.3 16.8 - 17.3 17.7 18.2 - 18.4 18.9 19.5 - 19.6 20.0 20.7 - 20.7 21.2 21.9 - 21.5 22.0 22.7 - 21.8 22.3 23.0 -
HI PR 161 174 183 - 181 195 206 - 206 222 234 - 234 252 266 - 264 284 300 - 291 314 331 - 310 333 352 - 317 341 361 -
LO PR 55 58 63 - 58 61 67 - 60 64 70 - 63 67 73 - 66 70 77 - 68 73 79 - 69 74 80 - 70 74 81 -
MBh 32.0 33.1 36.3 - 31.2 32.4 35.5 - 30.5 31.6 34.7 - 29.2 30.3 33.2 - 27.2 28.2 30.8 - 25.1 26.0 28.5 - 23.5 24.3 26.7 - 22.8 23.6 25.9 -
S/T 0.68 0.57 0.39 - 0.71 0.59 0.41 - 0.72 0.60 0.42 - 0.76 0.64 0.44 - 0.81 0.67 0.47 - 0.82 0.68 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -
DT 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 - 16 14 11 - 16 14 11 -
70 1100 KW 2.66 2.72 2.81 - 2.88 2.95 3.05 - 3.08 3.16 3.27 - 3.29 3.37 3.49 - 3.44 3.52 3.65 - 3.57 3.65 3.78 - 3.62 3.71 3.84 - 3.64 3.73 3.86 -
AMPS 14.7 15.0 15.5 - 15.8 16.2 16.7 - 17.1 17.6 18.1 - 18.3 18.7 19.3 - 19.4 19.9 20.6 - 20.6 21.1 21.8 - 21.3 21.8 22.6 - 21.6 22.2 22.9 -
HI PR 160 172 182 - 180 193 204 - 204 220 232 - 233 251 265 - 262 282 298 - 289 311 329 - 307 331 349 - 315 339 358 -
LO PR 54 58 63 - 57 61 66 - 59 63 69 - 62 66 73 - 65 70 76 - 68 72 79 - 69 73 80 - 69 74 80 -
MBh 30.4 31.5 34.5 - 29.7 30.8 33.7 - 29.0 30.1 32.9 - 27.7 28.8 31.5 - 25.8 26.7 29.3 - 23.9 24.7 27.1 - 22.3 23.1 25.3 - 21.6 22.4 24.6 -
S/T 0.65 0.55 0.38 - 0.68 0.57 0.39 - 0.69 0.58 0.40 - 0.73 0.61 0.42 - 0.77 0.65 0.45 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.80 0.67 0.47 -
DT 19 16 12 - 19 16 12 - 19 16 13 - 19 17 13 - 19 16 12 - 18 15 12 - 17 15 11 - 16 14 11 -
971 KW 2.61 2.67 2.76 - 2.83 2.90 3.00 - 3.03 3.10 3.21 - 3.23 3.31 3.42 - 3.38 3.46 3.58 - 3.50 3.59 3.72 - 3.55 3.64 3.77 - 3.58 3.66 3.79 -
AMPS 14.4 14.8 15.2 - 15.5 15.9 16.4 - 16.8 17.2 17.8 - 18.0 18.4 19.0 - 19.1 19.6 20.2 - 20.2 20.7 21.4 - 20.9 21.4 22.1 - 21.2 21.8 22.5 -
HI PR 157 169 178 - 176 190 200 - 200 216 228 - 228 246 259 - 257 276 292 - 284 305 322 - 301 324 342 - 309 332 351 -
LO PR 53 56 62 - 56 60 65 - 58 62 68 - 61 65 71 - 64 68 74 - 66 71 77 - 67 72 78 - 68 72 79 -
MBh 33.0 34.0 36.8 39.5 32.3 33.2 35.9 38.6 31.5 32.4 35.1 37.7 30.1 31.0 33.6 36.1 28.0 28.9 31.2 33.5 25.9 26.7 28.9 31.0 24.2 25.0 27.0 29.0 23.5 24.2 26.2 28.1
S/T 0.81 0.72 0.55 0.4 0.84 0.75 0.57 0.4 0.86 0.77 0.58 0.4 0.90 0.81 0.61 0.4 0.96 0.86 0.65 0.4 0.97 0.87 0.66 0.4 0.99 0.88 0.67 0.4 1.00 0.89 0.67 0.4
DT 20 18 15 10 20 19 15 11 20 19 15 11 20 19 15 11 20 19 15 10 19 17 14 9.8 18 16 14 9.3 18 16 13 9.1
1229 KW 2.70 2.76 2.85 3.0 2.93 3.00 3.10 3.2 3.13 3.20 3.32 3.4 3.34 3.42 3.54 3.7 3.49 3.58 3.70 3.8 3.62 3.71 3.84 4.0 3.68 3.76 3.90 4.0 3.70 3.79 3.92 4.1
AMPS 14.9 15.2 15.7 16.3 16.1 16.4 17.0 17.6 17.4 17.8 18.4 19.1 18.6 19.0 19.6 20.4 19.7 20.2 20.9 21.7 20.9 21.4 22.1 22.9 21.7 22.2 22.9 23.8 22.0 22.5 23.324.1
HI PR 163 175 185 193.2 183 197 208 216.7 208 224 236 246.5 237 255 269 280.7 266 287 303 315.8 294 317 335 349.0 313 336 355 370.6 320 345 364 379.8
LO PR 55 59 64 68.1 58 62 68 72.0 60 64 70 74.8 64 68 74 78.6 67 71 77 82.3 69 73 80 85.2 70 74 81 86.5 70 75 82 87.1
MBh 32.5 33.5 36.2 38.9 31.8 32.7 35.4 38.0 31.0 32.0 34.6 37.1 29.7 30.6 33.1 35.5 27.6 28.4 30.8 33.0 25.5 26.3 28.5 30.6 23.9 24.6 26.6 28.6 23.2 23.9 25.8 27.7
S/T 0.78 0.69 0.52 0.3 0.80 0.72 0.54 0.3 0.82 0.74 0.56 0.4 0.87 0.77 0.59 0.4 0.92 0.82 0.62 0.4 0.93 0.83 0.63 0.4 0.95 0.85 0.64 0.4 0.95 0.85 0.65 0.4
DT 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 20 16 11 20 18 15 10.3 19 17 14 9.8 18 17 14 9.6
75 1100 KW 2.68 2.74 2.84 2.9 2.91 2.98 3.08 3.2 3.11 3.18 3.30 3.4 3.32 3.40 3.52 3.6 3.47 3.55 3.68 3.8 3.60 3.69 3.82 4.0 3.65 3.74 3.87 4.0 3.67 3.76 3.90 4.0
AMPS 14.8 15.1 15.6 16.2 16.0 16.3 16.9 17.5 17.3 17.7 18.3 19.0 18.5 18.9 19.5 20.2 19.6 20.1 20.8 21.5 20.8 21.3 22.0 22.8 21.5 22.0 22.8 23.6 21.8 22.4 23.1 24.0
HI PR 162 174 184 191.8 182 195 206 215.2 207 222 235 244.8 235 253 267 278.8 265 285 301 313.6 292 315 332 346.5 310 334 353 368.0 318 342 362 377.2
LO PR 55 58 64 67.6 58 61 67 71.5 60 64 70 74.3 63 67 73 78.0 66 70 77 81.8 68 73 79 84.6 69 74 81 85.9 70 74 81 86.5
MBh 30.9 31.8 34.4 37.0 30.2 31.1 33.6 36.1 29.5 30.4 32.9 35.3 28.2 29.1 31.4 33.7 26.2 27.0 29.2 31.4 24.3 25.0 27.0 29.0 22.7 23.4 25.3 27.1 22.0 22.7 24.5 26.3
S/T 0.74 0.66 0.50 0.3 0.77 0.69 0.52 0.3 0.79 0.71 0.53 0.3 0.83 0.74 0.56 0.4 0.88 0.79 0.60 0.4 0.89 0.79 0.60 0.4 0.91 0.81 0.61 0.4 0.91 0.82 0.62 0.4
DT 22 20 16 11 22 20 17 11 22 20 17 11 22 20 17 12 22 20 16 11 20 19 15 10.6 19 18 15 10.1 19 18 14 9.9
971 KW 2.63 2.69 2.79 2.9 2.86 2.92 3.03 3.1 3.06 3.13 3.24 3.4 3.26 3.34 3.45 3.6 3.41 3.49 3.61 3.7 3.54 3.62 3.75 3.9 3.59 3.67 3.80 3.9 3.61 3.70 3.83 4.0
AMPS 14.5 14.9 15.4 15.9 15.7 16.0 16.6 17.2 17.0 17.4 18.0 18.6 18.1 18.6 19.2 19.9 19.3 19.7 20.4 21.1 20.4 20.9 21.6 22.4 21.1 21.6 22.4 23.2 21.4 22.0 22.723.5
HI PR 159 171 180 188.0 178 192 202 210.9 202 218 230 239.9 231 248 262 273.2 259 279 295 307.4 287 308 326 339.6 304 327 346 360.6 312 336 354 369.7
LO PR 54 57 62 66.3 57 60 66 70.0 59 63 68 72.8 62 66 72 76.5 65 69 75 80.1 67 71 78 82.9 68 72 79 84.2 69 73 80 84.8
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
