COOLING PERFORMANCE DATA
CKF24-2*
MODEL: CKF24-2* / A24-00-2RA COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115 118°F 125°F
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367 71 59 63 67715963 67 71 59636771596367 71 59 53 67 71 59 63 67 71
MBh 24.4 25.0 26.7 28.5 23.9 24.4 26.1 27.9 23.3 23.8 25.5 27.2 22.3 22.8 24.4 26.0 20.8 21.2 22.7 24.2 19.2 19.6 20.9 22.4 17.9 18.3 19.6 20.9 17.4 17.8 19.0 20.3
S/T 0.86 0.80 0.65 0.5 0.89 0.83 0.68 0.5 0.91 0.85 0.69 0.5 0.96 0.90 0.73 0.5 1.00 0.95 0.78 0.6 1.00 0.96 0.78 0.6 1.00 0.99 0.80 0.6 1.00 1.00 0.81 0.6
DT 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 23 20 16 22 21 18 14.8 20 20 18 14.1 20 20 17 13.8
816 KW 2.07 2.11 2.18 2.3 2.24 2.29 2.36 2.4 2.39 2.44 2.52 2.6 2.54 2.60 2.69 2.8 2.65 2.71 2.81 2.9 2.75 2.81 2.91 3.0 2.79 2.85 2.95 3.1 2.80 2.87 2.97 3.1
AMPS 10.0 10.2 10.5 10.9 10.7 11.0 11.3 11.7 11.6 11.8 12.2 12.6 12.3 12.6 13.0 13.4 13.0 13.3 13.8 14.2 13.8 14.1 14.5 15.0 14.2 14.6 15.0 15.6 14.4 14.8 15.215.8
HI PR 159 171 180 187.9 178 191 202 210.8 202 218 230 239.8 230 248 262 273.1 259 279 295 307.2 286 308 325 339.4 304 327 346 360.5 312 335 354 369.5
LO PR 57 61 66 70.7 60 64 70 74.7 63 67 73 77.6 66 70 77 81.5 69 73 80 85.4 71 76 83 88.4 73 77 84 89.8 73 78 85 90.4
MBh 24.1 24.6 26.3 28.1 23.5 24.0 25.7 27.5 23.0 23.5 25.1 26.8 22.0 22.5 24.0 25.7 20.4 20.9 22.3 23.9 18.9 19.3 20.6 22.1 17.7 18.1 19.3 20.6 17.1 17.5 18.7 20.0
S/T 0.82 0.77 0.63 0.5 0.85 0.80 0.65 0.5 0.87 0.82 0.67 0.5 0.92 0.86 0.70 0.5 0.97 0.91 0.74 0.6 0.98 0.92 0.75 0.6 0.99 0.94 0.77 0.6 1.00 0.95 0.77 0.6
DT 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 25 24 21 17 23 22 19 15.6 22 21 19 14.8 22 21 18 14.5
80 730 KW 2.06 2.10 2.17 2.2 2.22 2.27 2.35 2.4 2.37 2.43 2.51 2.6 2.52 2.58 2.67 2.8 2.63 2.70 2.79 2.9 2.73 2.79 2.89 3.0 2.77 2.83 2.93 3.0 2.78 2.85 2.95 3.1
AMPS 10.0 10.2 10.5 10.8 10.7 10.9 11.2 11.6 11.5 11.8 12.1 12.5 12.2 12.5 12.9 13.4 13.0 13.3 13.7 14.2 13.7 14.0 14.4 14.9 14.1 14.5 14.9 15.5 14.3 14.7 15.1 15.7
HI PR 157 169 179 186.6 177 190 201 209.4 201 216 228 238.1 229 246 260 271.2 257 277 293 305.1 284 306 323 337.1 302 325 343 358.0 310 333 352 366.9
LO PR 57 60 66 70.2 60 64 70 74.1 62 66 72 77.1 65 70 76 80.9 69 73 80 84.8 71 75 82 87.7 72 77 84 89.2 73 77 84 89.8
MBh 22.9 23.4 25.0 26.7 22.3 22.8 24.4 26.1 21.8 22.3 23.8 25.5 20.9 21.3 22.8 24.4 19.4 19.8 21.2 22.7 18.0 18.4 19.6 21.0 16.8 17.2 18.3 19.6 16.3 16.6 17.8 19.0
S/T 0.79 0.74 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.88 0.82 0.67 0.5 0.93 0.87 0.71 0.5 0.94 0.88 0.72 0.5 0.96 0.90 0.73 0.5 0.97 0.91 0.74 0.6
DT 26 25 21 17 26 25 22 17 26 25 22 17 26 25 22 17 26 25 22 17 24 23 20 16 23 22 19 15.3 23 22 19 15.0
644 KW 2.02 2.07 2.13 2.2 2.19 2.24 2.31 2.4 2.33 2.38 2.46 2.5 2.48 2.54 2.62 2.7 2.59 2.65 2.74 2.8 2.68 2.74 2.84 2.9 2.72 2.78 2.88 3.0 2.74 2.80 2.90 3.0
AMPS 9.8 10.0 10.3 10.6 10.5 10.7 11.1 11.4 11.3 11.6 11.9 12.3 12.0 12.3 12.7 13.1 12.7 13.0 13.4 13.9 13.4 13.7 14.2 14.7 13.9 14.2 14.7 15.2 14.1 14.4 14.9 15.4
HI PR 154 166 175 182.8 173 186 197 205.2 197 212 224 233.3 224 241 255 265.8 252 271 287 299.0 279 300 317 330.3 296 319 336 350.8 303 326 345 359.6
LO PR 56 59 65 68.8 59 62 68 72.7 61 65 71 75.5 64 68 74 79.3 67 71 78 83.1 70 74 81 86.0 71 75 82 87.4 71 76 83 88.0
MBh 24.9 25.3 26.5 28.3 24.3 24.8 25.9 27.7 23.7 24.2 25.3 27.0 22.7 23.1 24.2 25.9 21.1 21.5 22.5 24.0 19.5 19.9 20.8 22.2 18.3 18.6 19.5 20.8 17.7 18.1 18.9 20.2
S/T 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.95 0.92 0.83 0.7 1.00 0.97 0.87 0.7 1.00 1.00 0.93 0.8 1.00 1.00 0.94 0.8 1.00 1.00 0.96 0.8 1.00 1.00 0.96 0.8
DT 25 25 23 20 25 25 24 21 26 25 24 21 26 25 24 21 24 24 24 20 22 22 22 19.0 21 21 21 18.2 20 20 21 17.8
816 KW 2.09 2.13 2.20 2.3 2.26 2.31 2.38 2.5 2.41 2.46 2.54 2.6 2.56 2.62 2.71 2.8 2.67 2.74 2.83 2.9 2.77 2.84 2.93 3.0 2.81 2.88 2.98 3.1 2.83 2.89 2.99 3.1
AMPS 10.1 10.3 10.6 11.0 10.8 11.1 11.4 11.8 11.7 11.9 12.3 12.7 12.4 12.7 13.1 13.5 13.2 13.5 13.9 14.4 13.9 14.2 14.6 15.2 14.4 14.7 15.2 15.7 14.6 14.9 15.415.9
HI PR 160 172 182 189.8 180 193 204 212.9 204 220 232 242.2 233 250 264 275.8 262 282 297 310.3 289 311 329 342.8 307 331 349 364.1 315 339 358 373.2
LO PR 58 61 67 71.4 61 65 71 75.4 63 67 74 78.4 67 71 77 82.3 70 74 81 86.3 72 77 84 89.2 73 78 85 90.7 74 79 86 91.3
MBh 24.5 25.0 26.1 27.9 23.9 24.4 25.6 27.3 23.4 23.8 25.0 26.6 22.4 22.8 23.9 25.5 20.8 21.2 22.2 23.7 19.2 19.6 20.5 21.9 18.0 18.3 19.2 20.5 17.4 17.8 18.6 19.9
S/T 0.86 0.83 0.75 0.6 0.89 0.86 0.78 0.6 0.91 0.88 0.80 0.6 0.96 0.93 0.84 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.90 0.7 1.00 1.00 0.92 0.7 1.00 1.00 0.92 0.7
DT 27 26 25 21 27 26 25 22 27 26 25 22 27 27 25 22 26 26 25 21 24 25 23 20.1 23 23 22 19.1 22 22 22 18.7
85 730 KW 2.07 2.12 2.19 2.3 2.24 2.29 2.37 2.5 2.39 2.45 2.53 2.6 2.55 2.60 2.69 2.8 2.66 2.72 2.81 2.9 2.75 2.82 2.92 3.0 2.79 2.86 2.96 3.1 2.81 2.87 2.97 3.1
AMPS 10.0 10.3 10.6 10.9 10.8 11.0 11.3 11.7 11.6 11.9 12.2 12.7 12.3 12.6 13.0 13.5 13.1 13.4 13.8 14.3 13.8 14.1 14.6 15.1 14.3 14.6 15.1 15.6 14.5 14.8 15.315.8
HI PR 159 171 181 188.4 178 192 203 211.4 203 218 231 240.5 231 249 263 273.9 260 280 295 308.1 287 309 326 340.4 305 328 347 361.5 313 336 355 370.6
LO PR 57 61 67 70.9 61 64 70 74.9 63 67 73 77.8 66 70 77 81.7 69 74 80 85.7 72 76 83 88.6 73 77 85 90.0 73 78 85 90.7
MBh 23.3 23.7 24.8 26.5 22.7 23.2 24.3 25.9 22.2 22.6 23.7 25.3 21.2 21.7 22.7 24.2 19.8 20.1 21.1 22.5 18.3 18.6 19.5 20.8 17.1 17.4 18.2 19.5 16.6 16.9 17.7 18.9
S/T 0.82 0.80 0.72 0.6 0.85 0.82 0.74 0.6 0.88 0.84 0.76 0.6 0.92 0.89 0.80 0.7 0.98 0.94 0.85 0.7 0.99 0.95 0.86 0.7 1.00 0.97 0.88 0.7 1.00 0.98 0.88 0.7
DT 27 27 25 22 28 27 26 22 28 27 26 22 28 27 26 22 28 27 26 22 26 25 24 20.7 24 24 23 19.7 24 24 22 19.3
644 KW 2.04 2.08 2.15 2.2 2.20 2.25 2.33 2.4 2.35 2.40 2.49 2.6 2.50 2.56 2.65 2.7 2.61 2.67 2.76 2.9 2.71 2.77 2.86 3.0 2.74 2.81 2.90 3.0 2.76 2.82 2.92 3.0
AMPS 9.9 10.1 10.4 10.7 10.6 10.8 11.1 11.5 11.4 11.7 12.0 12.4 12.1 12.4 12.8 13.2 12.9 13.1 13.5 14.0 13.6 13.9 14.3 14.8 14.0 14.3 14.8 15.3 14.2 14.6 15.0 15.5
HI PR 156 168 177 184.7 175 188 199 207.2 199 214 226 235.7 226 244 257 268.4 255 274 290 302.0 281 303 320 333.6 299 322 340 354.3 306 330 348 363.2
LO PR 56 60 65 69.5 59 63 69 73.4 62 66 72 76.3 65 69 75 80.1 68 72 79 84.0 70 75 82 86.8 71 76 83 88.2 72 76 83 88.8
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system pow er AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
