COOLING PERFORMANCE DATA
CKF70-5*
MODEL: CKF70-5* / A60-00-2 COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115 118°F 125°F
Entering Indoor Wet Bulb Temperature
IDB*Airflow 596367715963677159636771596367 7159636771596367715953677159636771
MBh 61.0 62.3 66.6 71.2 59.5 60.9 65.0 69.5 58.1 59.4 63.5 67.8 56.7 58.0 61.9 66.2 53.9 55.1 58.8 62.9 49.9 51.0 54.5 58.2 46.7 47.8 51.0 54.5 45.4 46.4 49.5 52.9
S/T 0.85 0.80 0.65 0.5 0.88 0.82 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.87 0.71 0.5 0.97 0.91 0.74 0.6 0.97 0.91 0.74 0.6 0.99 0.94 0.76 0.6 1.00 0.95 0.77 0.6
DT 26 25 21 17 26 25 22 17 26 25 22 17 26 25 22 18 26 25 22 17 24 23 20 16.1 23 22 19 15.5 23 22 19 15.2
1844 KW 4.73 4.83 4.98 5.1 5.37 5.49 5.66 5.9 5.91 6.04 6.24 6.4 6.45 6.60 6.82 7.1 6.95 7.11 7.35 7.6 7.41 7.58 7.84 8.1 7.81 7.99 8.27 8.6 7.98 8.17 8.46 8.8
AMPS 11.2 11.4 11.7 12.1 11.9 12.2 12.5 12.9 12.8 13.0 13.4 13.8 13.5 13.8 14.2 14.6 14.2 14.5 15.0 15.4 15.0 15.3 15.7 16.2 15.4 15.8 16.2 16.8 15.6 16.0 16.417.0
HI PR 172 185 195 203.8 193 208 219 228.7 219 236 249 260.1 250 269 284 296.2 281 303 319 333.2 311 334 353 368.2 330 355 375 391.0 338 364 384 400.7
LO PR 53 56 61 65.1 56 59 65 68.8 58 61 67 71.5 61 65 70 75.1 64 68 74 78.7 66 70 76 81.4 67 71 78 82.7 67 72 78 83.3
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4 46.0 47.0 50.3 53.7 44.7 45.7 48.8 52.2
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5 0.96 0.90 0.73 0.5 0.97 0.91 0.74 0.6
DT 27 26 23 18 28 26 23 18 28 26 23 18 28 27 23 18 27 26 23 18 26 24 21 17.0 25 24 20 16.3 24 23 20 16.1
80 1650 KW 4.70 4.80 4.95 5.1 5.34 5.45 5.63 5.8 5.87 6.00 6.20 6.4 6.41 6.56 6.78 7.0 6.91 7.07 7.31 7.6 7.37 7.54 7.80 8.1 7.77 7.95 8.22 8.5 7.94 8.12 8.40 8.7
AMPS 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1 15.3 15.7 16.1 16.7 15.5 15.9 16.3 16.9
HI PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6 328 353 372 388.2 336 361 382 398.0
LO PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8 66 71 77 82.1 67 71 78 82.7
MBh 57.1 58.3 62.3 66.6 55.7 57.0 60.8 65.0 54.4 55.6 59.4 63.5 53.1 54.2 58.0 61.9 50.4 51.5 55.1 58.9 46.7 47.7 51.0 54.5 43.7 44.7 47.8 51.0 42.5 43.4 46.4 49.6
S/T 0.78 0.73 0.59 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.63 0.5 0.85 0.80 0.65 0.5 0.89 0.83 0.68 0.5 0.89 0.84 0.68 0.5 0.92 0.86 0.70 0.5 0.93 0.87 0.71 0.5
DT 28 27 23 19 28 27 24 19 28 27 24 19 29 27 24 19 28 27 23 19 26 25 22 18 25 24 21 16.9 25 24 21 16.6
1456 KW 4.63 4.73 4.87 5.0 5.25 5.37 5.54 5.7 5.77 5.90 6.10 6.3 6.31 6.45 6.66 6.9 6.79 6.95 7.18 7.4 7.24 7.40 7.66 7.9 7.63 7.81 8.08 8.4 7.80 7.98 8.26 8.5
AMPS 11.0 11.2 11.5 11.8 11.7 11.9 12.3 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9 15.1 15.4 15.9 16.4 15.3 15.6 16.116.6
HI PR 167 180 190 198.3 188 202 213 222.5 214 230 243 253.1 243 262 276 288.2 274 294 311 324.3 302 325 344 358.3 321 345 365 380.5 329 354 374 390.0
LO PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.6 59 63 69 73.1 62 66 72 76.6 64 68 74 79.2 65 69 76 80.5 66 70 76 81.0
MBh 62.0 63.2 66.2 70.7 60.6 61.8 64.7 69.0 59.1 60.3 63.1 67.4 57.7 58.8 61.6 65.7 54.8 55.9 58.5 62.4 50.8 51.8 54.2 57.8 47.5 48.5 50.8 54.2 46.2 47.1 49.3 52.6
S/T 0.89 0.86 0.77 0.6 0.92 0.89 0.80 0.7 0.94 0.91 0.82 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.88 0.7 1.00 0.98 0.89 0.7 1.00 1.00 0.91 0.7 1.00 1.00 0.92 0.7
DT 28 27 26 22 28 27 26 22 28 27 26 22 28 28 26 23 27 27 26 22 25 25 24 20.8 24 24 23 20.0 23 23 23 19.6
1844 KW 4.77 4.87 5.02 5.2 5.41 5.53 5.71 5.9 5.95 6.09 6.29 6.5 6.51 6.65 6.88 7.1 7.01 7.17 7.42 7.7 7.47 7.65 7.91 8.2 7.88 8.07 8.34 8.6 8.06 8.24 8.53 8.8
AMPS 11.3 11.5 11.8 12.2 12.0 12.3 12.6 13.0 12.9 13.1 13.5 13.9 13.6 13.9 14.3 14.7 14.4 14.7 15.1 15.6 15.1 15.4 15.8 16.4 15.6 15.9 16.4 16.9 15.8 16.1 16.617.1
HI PR 174 187 197 205.8 195 210 221 230.9 222 238 252 262.7 252 272 287 299.1 284 306 323 336.5 314 338 357 371.8 333 359 379 394.9 341 367 388 404.7
LO PR 53 57 62 65.7 56 60 65 69.5 58 62 68 72.2 61 65 71 75.8 64 68 75 79.5 66 71 77 82.2 68 72 78 83.5 68 72 79 84.1
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0 46.8 47.8 50.0 53.4 45.5 46.4 48.6 51.8
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7 0.99 0.97 0.87 0.7 1.00 0.98 0.88 0.7
DT 29 29 27 23 29 29 27 24 29 29 27 24 30 29 28 24 29 29 27 23 27 27 25 21.9 26 26 24 21.1 25 25 24 20.7
85 1650 KW 4.74 4.84 4.99 5.2 5.38 5.50 5.68 5.9 5.92 6.05 6.25 6.5 6.47 6.62 6.84 7.1 6.97 7.13 7.37 7.6 7.43 7.60 7.86 8.1 7.83 8.02 8.29 8.6 8.01 8.19 8.48 8.8
AMPS 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3 15.5 15.8 16.3 16.8 15.7 16.0 16.517.0
HI PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3 331 356 376 392.1 339 365 385 401.9
LO PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6 67 71 78 82.9 68 72 78 83.5
MBh 58.1 59.2 62.0 66.1 56.7 57.8 60.5 64.6 55.4 56.4 59.1 63.1 54.0 55.1 57.7 61.5 51.3 52.3 54.8 58.4 47.5 48.4 50.7 54.1 44.5 45.4 47.5 50.7 43.2 44.0 46.1 49.2
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.75 0.6 0.89 0.86 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.90 0.82 0.7 0.96 0.93 0.84 0.7 0.97 0.94 0.85 0.7
DT 30 29 28 24 30 30 28 24 30 30 28 24 31 30 28 25 30 30 28 24 28 28 26 22.6 27 27 25 21.7 27 26 25 21.4
1456 KW 4.66 4.76 4.91 5.1 5.29 5.41 5.58 5.8 5.82 5.95 6.15 6.4 6.36 6.50 6.72 7.0 6.85 7.01 7.24 7.5 7.30 7.47 7.73 8.0 7.70 7.88 8.15 8.4 7.87 8.05 8.33 8.6
AMPS 11.1 11.3 11.6 11.9 11.8 12.0 12.3 12.7 12.6 12.9 13.2 13.6 13.3 13.6 14.0 14.4 14.1 14.3 14.7 15.2 14.8 15.1 15.5 16.0 15.2 15.5 16.0 16.5 15.4 15.8 16.216.7
HI PR 169 182 192 200.3 190 204 215 224.7 216 232 245 255.6 246 264 279 291.1 276 297 314 327.5 305 329 347 361.9 324 349 368 384.3 332 358 378 393.9
LO PR 52 55 60 64.0 55 58 63 67.6 57 60 66 70.2 60 63 69 73.8 63 67 73 77.3 65 69 75 80.0 66 70 76 81.3 66 70 77 81.8
Shaded area is AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
EXPANDED PERFORMANCE DATA
