8 www.goodmanmfg.com SS-GPC14H
SS-GPC14H www.goodmanmfg.com 9
Product SPecificationS
Product SPecificationS
exPanded CoolinG data — GPC1430H41** (Cont.)
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
1145
MBh 28.8 29.4 31.4 33.6 28.1 28.7 30.7 32.8 27.5 28.1 30.0 32.1 26.8 27.4 29.3 31.3 25.5 26.0 27.8 29.7 23.6 24.1 25.7 27.5
S/T 0.92 0.87 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.92 0.75 0.56 1.00 0.95 0.77 0.58 1.00 1.00 0.80 0.60 1.00 1.00 0.81 0.61
∆ T 21 20 18 14 22 21 18 14 22 21 18 14 22 21 18 15 20 21 18 14 19 19 17 13
kW 1.78 1.81 1.87 1.94 1.92 1.96 2.03 2.09 2.04 2.09 2.16 2.23 2.15 2.20 2.28 2.36 2.25 2.30 2.38 2.46 2.33 2.38 2.46 2.55
Amps 8.0 8.2 8.4 8.7 8.6 8.8 9.0 9.3 9.2 9.4 9.7 10.0 9.8 10.0 10.3 10.6 10.3 10.6 10.9 11.2 10.9 11.1 11.4 11.8
HI PR 239 257 272 283 268 289 305 318 305 328 347 362 348 374 395 412 391 421 444 463 432 465 491 512
LO PR 110 117 128 136 116 124 135 144 121 129 140 150 127 135 147 157 133 142 155 165 138 146 160 170
1020
MBh 28.0 28.6 30.5 32.6 27.3 27.9 29.8 31.9 26.7 27.2 29.1 31.1 26.0 26.6 28.4 30.4 24.7 25.3 27.0 28.8 22.9 23.4 25.0 26.7
S/T 0.88 0.83 0.67 0.50 0.91 0.86 0.70 0.52 0.94 0.88 0.71 0.53 0.97 0.91 0.74 0.55 1.00 0.94 0.77 0.57 1.00 0.95 0.77 0.58
∆ T 22 21 19 15 22 22 19 15 23 22 19 15 23 22 19 15 22 21 19 15 21 20 17 14
kW 1.76 1.80 1.86 1.92 1.90 1.94 2.01 2.08 2.03 2.07 2.14 2.21 2.14 2.18 2.26 2.34 2.23 2.28 2.36 2.44 2.31 2.36 2.44 2.53
Amps 8.0 8.1 8.4 8.6 8.5 8.7 9.0 9.2 9.2 9.4 9.6 9.9 9.7 9.9 10.2 10.5 10.2 10.5 10.8 11.1 10.8 11.0 11.3 11.7
HI PR 237 255 269 281 266 286 302 315 302 325 343 358 344 370 391 408 387 417 440 459 428 460 486 507
LO PR 109 116 127 135 115 123 134 142 120 127 139 148 126 134 146 155 132 140 153 163 136 145 158 169
900
MBh 26.6 27.1 29.0 31.0 25.9 26.5 28.3 30.3 25.3 25.9 27.7
29.6 24.7 25.3 27.0 28.8 23.5 24.0 25.6 27.4 21.7 22.2 23.7 25.4
S/T 0.84 0.79 0.64 0.48 0.87 0.82 0.67 0.50 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.97 0.91 0.74 0.55
∆ T 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 16 23 22 19 15 22 21 18 14
kW 1.73 1.77 1.83 1.89 1.87 1.91 1.97 2.04 1.99 2.04 2.10 2.18 2.10 2.15 2.22 2.30 2.19 2.24 2.32 2.40 2.27 2.32 2.40 2.48
Amps 7.9
8.0 8.2 8.5 8.4 8.6 8.8 9.1 9.0 9.2 9.5 9.8 9.5 9.8 10.0 10.4 10.1 10.3 10.6 11.0 10.6 10.8 11.2 11.5
HI PR 232 250 264 275 260 280 296 309 296 319 336 351 337 363 383 400 379 408 431 450 419 451 476 497
LO PR 107 114 124 132 113 120 131 140 117 125 136 145 123 131 143 152 129 137 150 160 134 142 155 165
85
1145
MBh 29.3 29.9 31.3 33.4 28.6 29.2 30.6 32.6 27.9 28.5 29.8 31.8 27.3 27.8 29.1 31.1 25.9 26.4 27.7 29.5 24.0 24.5 25.6 27.3
S/T 0.97 0.93 0.84 0.68 1.00 0.97 0.87 0.71 1.00 0.99 0.90 0.73 1.00 1.00 0.93 0.75 1.00 1.00 0.96 0.78 1.00 1.00 0.97 0.79
∆ T 23 22 21 18 23 23 21 19 22 23 21 19 22 22 22 19 21 21 21 18 19 20 20 17
kW 1.79 1.83 1.89 1.95 1.93 1.98 2.04 2.11 2.06 2.11 2.18 2.25 2.17 2.22 2.30 2.38 2.27 2.32 2.40 2.48 2.35 2.40 2.49 2.57
Amps 8.1 8.3 8.5 8.8 8.7 8.8 9.1 9.4 9.3 9.5 9.8 10.1 9.9 10.1 10.4 10.7 10.4 10.6 11.0 11.3 11.0 11.2 11.5 11.9
HI PR 241 260 274 286 271 292 308 321 308 332 350 365 351 378 399 416 395 425 449 468 436 470 496 517
LO PR 111 118 129 138 117 125 136 145 122 130 142 151 128 136 149 159 134 143 156 166 139 148 161 172
1020
MBh 28.5 29.0 30.4 32.4 27.8 28.3 29.7 31.7 27.1 27.7 29.0 30.9 26.5 27.0 28.3 30.1 25.1 25.6 26.8 28.6 23.3 23.7 24.9 26.5
S/T 0.92 0.89 0.80 0.65 0.96 0.92 0.83 0.68 0.98 0.95 0.86 0.69 1.00 0.98 0.88 0.72 1.00 1.00 0.92 0.74 1.00 1.00 0.92 0.75
∆ T 24 23 22 19 24 24 22 19
24 24 22 19 24 24 22 19 23 23 22 19 21 21 21 18
kW 1.78 1.81 1.87 1.94 1.92 1.96 2.03 2.09 2.04 2.09 2.16 2.23 2.15 2.20 2.28 2.36 2.25 2.30 2.38 2.46 2.33 2.38 2.46 2.55
Amps 8.0
8.2 8.4 8.7 8.6 8.8 9.0 9.3 9.2 9.4 9.7 10.0 9.8 10.0 10.3 10.6 10.3 10.6 10.9 11.2 10.9 11.1 11.4 11.8
HI PR 239 257 272 283 268 289 305 318 305 328 347 362 348 374 395 412 391 421 444 463 432 465 491 512
LO PR 110 117 128 136 116 124 135 144 121 129 140 150 127 135 147 157 133 142 155 165 138 146 160 170
900
MBh 27.0 27.6 28.9 30.8 26.4 26.9 28.2 30.1 25.8 26.3 27.5 29.4 25.1 25.6 26.8 28.6 23.9 24.4 25.5 27.2 22.1 22.6 23.6 25.2
S/T 0.89 0.85 0.77 0.63 0.92 0.89 0.80 0.65 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.97 0.88 0.71 1.00 0.98 0.88 0.72
∆ T 24 24 23 20 25 24 23 20 25 24 23 20 25 25 23 20 24 24 23 20 23 23 21 18
kW 1.75 1.78 1.84 1.90 1.89 1.93 1.99 2.06 2.01 2.05 2.12 2.19 2.12 2.16 2.24 2.32 2.21 2.26 2.34 2.42 2.29 2.34 2.42 2.51
Amps 7.9 8.1 8.3 8.6 8.5 8.6 8.9 9.2 9.1 9.3 9.5 9.9 9.6 9.8 10.1 10.5 10.2 10.4 10.7 11.0 10.7 10.9 11.3 11.6
HI PR 234 252 266 278 263 283 299 312 299 322 340 354 341 367 387 404 383 412 435 454 423 456 481 502
LO PR 108 115 125 133 114 121 132 141 118 126 138 147 124 132 145 154 130 139 151 161 135 143 157 167
IDB = Entering Indoor Dry Bulb Temperature Shaded area reects AHRI (TVA) condions. kW = total system power
High and low pressures are measured at the liquid and sucon access ngs. Amps: Unit amps (comp.+ evaporator + condenser fan motors)
